KRISHNAA DRIVES Arasur, Coimbatore, Tamil Nadu

Specification Flow Rate: Up to 3250 LPH Head Range: 6 mtrs to 45 mtrs Limits Of Suction h Suction head lift up to: 6 mtrs Handling: Clear Fresh Water Construction Characteristics: Pump Body: Fe 200 Cast Iron Motor Body: Extruded Aluminium / Aluminium Die cast body) Impeller: Forged Brass Shaft: SS 410 / EN 8 Motor: Single phase 230 V–50 Hz CSR, TEFC motor with Thermal Overload Protection Insulation: Class B Bearing: 6202 ZZ / 6201 ZZ Winding: Enamelled copper wire winding Stamping: CRCA - LC Steel Salient Features Imported motor protector High self priming suction. Wide voltage design 180 V-240 V. Permanent Split capacitor (CSR). Double shielded bearings (ZZ). Non corrosive brass forged impeller. High quality aluminium extruded body. Applications Water lifting for bunglows and villas. Gardening and lawn sprinklers. Car washing. Pressure boosting. Water circulation.

Specification Flow Rate: Up to 3000 LPH   Head Range: 6 mtrs to 40 mtrs   Limits Of Suction Suction lift up to: 9 mtrs   Handling: Clear Fresh Water   Construction Characteristics: Pump Body: Fe 200 Cast Iron Motor Body: Extruded Aluminium / Aluminium Die cast body) Impeller: Forged Brass Shaft: SS 410 / EN 8 Motor: Single phase 230 V–50 Hz CSR, TEFC motor with Thermal Overload Protection Insulation: Class B Bearing: 6202 ZZ / 6201 ZZ Winding: Enamelled copper wire winding Stamping: CRCA - LC Steel Salient Features Imported motor protector High self priming suction. Wide voltage design 180 V-240 V. Permanent Split capacitor (CSR). Double shielded bearings (ZZ). Non corrosive brass forged impeller. High quality aluminium extruded body. Applications Water lifting for bunglows and villas. Gardening and lawn sprinklers. Car washing. Pressure boosting. Water circulation.

Specification Flow Rate: Up to 3000 LPH   Head Range: 6 mtrs to 40 mtrs   Limits Of Suction Suction lift up to: 6 mtrs (5 mtrs recommended)   Handling: Clear Fresh Water   Construction Characteristics: Pump Body: Fe 200 Cast Iron Motor Body: Extruded Aluminium / Aluminium Die cast body) Impeller: Forged Brass Shaft: SS 410 / EN 8 Motor: Single phase 230 V–50 Hz CSR, TEFC motor with Thermal Overload Protection Insulation: Class B Bearing: 6202 ZZ /6201 ZZ Winding: Enamelled copper wire winding Stamping: CRCA - LC Steel Salient Features Imported motor protector High self priming suction. Wide voltage design 180 V-240 V. Permanent Split capacitor (CSR). Double shielded bearings (ZZ). Non corrosive brass forged impeller. High quality aluminium extruded body. Applications Water lifting for bunglows and villas. Gardening and lawn sprinklers. Car washing. Pressure boosting. Water circulation.

Specification Flow Rate: Up to 8400 LPH Head Range: 6 mtrs to 45 mtrs Construction Characteristics: Pump Body: Fe 200 Cast Iron Motor Body: SS 410 Impeller: SS 304 Shaft: SS 410 Motor: Single phase 230 V – 50 Hz CSR, TEFC motor Insulation: Class B Bearing: Carbon / GM Bush Winding: Polywrab wires Salient Features Stainless steel / Bronze impeller options. Permanent Split capacitor Trouble free operation. Wide voltage design 180 V-240 V. Corrosion Resistant motor body. High Head and discharge. Totally immersed and noise free. Applications Water lifting from sumps to tanks. small farms. High raise buildings. Industries.

Specification Flow Rate: Up to 2100 LPH Head Range: Up to to 100 mtrs Applications RO Plants

Specification Flow Rate: 2500 LPH Head Range: Up to 60 mtrs Construction Characteristics: Motor Body: Fe 200 Cast Iron / Extruded Aluminium Pump Body: Fe 200 Cast Iron Impeller: Cast Iron – Powder coated / ERP coat Shaft: SS 410 / EN 8 Motor: Single phase 230 V–50 Hz CSR, TEFC motor with Thermal Overload Protection Insulation: Class B Bearing: 6203 ZZ / 6204 ZZ Stamping: M47 / CRCA - LC Winding: Enamelled copper wire winding Salient Features Imported motor protector High self priming suction. Wide voltage design 180 V-240 V. Permanent Split capacitor (CSR). Double shielded bearings (ZZ). Non corrosive brass forged impeller. High quality aluminium extruded body. Applications Water lifting for bunglows, hotels and industries. Agricultual Irrigation. Gardening. Industrial clean water pumping. Water circulation. Water lifting from bore wells. Home, Offices and small farms. High raise buildings. Car washing / Service centres. Pressure boosting. Industries.

Specification Range of Performance: Flow Rate: Up to 8000 LPH Head Range: 6 mtrs to 25 mtrs Limits Of Suction Suction head lift up to: 6 mtrs Handling: Clear Fresh Water Construction Characteristics: Motor Body: Fe 200 Cast Iron / Extruded Aluminium Pump Body: Fe 200 Cast Iron Impeller: Cast Iron – Powder coated/ERP coat Shaft: SS 410 / EN 8 Motor: Single phase 230 V–50 Hz CSR, TEFC motor with Thermal Overload Protection Insulation: Class B Bearing: 6203 ZZ / 6204 ZZ Stamping: M47 / CRCA - LC Winding: Enamelled copper wire winding Salient Features Imported motor protector High self priming suction. Wide voltage design 180 V-240 V. Permanent Split capacitor (CSR). Double shielded bearings (ZZ). Non corrosive brass forged impeller. High quality aluminium extruded body. Applications Water lifting for bunglows, hotels and industries. Agricultual Irrigation. Gardening. Industrial clean water pumping. Water circulation.
