Direct Shear
Get Price Quote
Used to determine the resistance to shearing of all types of soil specimens both consolidated and drained, undisturbed or remolded samples. Meets:- IS: 2720 (Part 13), ASTM D 3080, IS: 2720 (Section 1 - Part 39),IS: 11593-1986, IS: 11229 - 1985, 2720 (Part 13) - 1986 MILESTONE INSTRUMENTS offers the following models:
Direct Shear apparatus, 2 KN Manual Specimen Size: 60 x 60 x 25 mm
Direct Shear apparatus, 2 KN Motorised Rates of Strain (mm/min): 1.25, Specimen Size: 60 x 60 x 25 mm Power Specifications: 230 V, 50 Hz, Single Phase, AC supply
Direct Shear apparatus, 2 KN, Motorised with Digital Readout Read Out: Digital Rates of Strain (mm/min): 1.25, Specimen Size: 60 x 60 x 25 mm Power Specifications: 230 V, 50 Hz, Single Phase, AC supply
Direct Shear apparatus, 2 KN, Type of Shear Measurement: Direct/Residual Operation: By stepper motor Rates of Strain: 0.00001 to 9.99999 mm/min Specimen Size: 60 x 60 x 25 mm Digital Display: Displacement and Speed with 0.00001 mm resolution Provided RS232 for PC connection Max vertical direct load: 3 kg/cm2 Power Specifications: 230 V, 50 Hz, Single Phase, AC supply
Pneumatic Direct Shear apparatus, 2KN Direct/Residual Shear Apparatus utilizes the pneumatic loading concept for applying the vertical load to the sample. It eliminates the need of loading weights used in dead weight-type systems. Type of Shear Measurement: Direct/Residual Operation: By stepper motor Vertical Load is applied by the pneumatic loading concept. Rates of Strain: 0.00001 to 9.99999 mm/min Specimen Size: 60 x 60 x 25 mm Digital Display: Displacement and Speed with 0.00001 mm resolution Provided RS232 for PC connection Max vertical direct load: 3 kg/cm2 Power Specifications: 230 V, 50 Hz, Single Phase, AC supply
Large Direct Shear Apparatus, Motorised, 50 KN (5,000 kgf) IS: 2720 (Section 1 - Part 39), IS: 11593-1986 For testing sands, gravel, gravely clays and clay gravels for use in rolled fill embankments. Type of Shear Measurement:
Direct Operation: Motorised Rates of Strain (mm/min): 72 speeds Ranging from 0.0014 to 10.16mm/min Specimen Size: 30 x 30 x 15 cm Change gears: 12 Shear Load capacity: 50 kN Vertical load capacity: 500 kN/m2 Net weight: 990 kg Power Specifications: 220 V, 50 Hz, 1 phase, AC supply
