SHIVAM INSTRUMENTS Wazirpur, Delhi

  Double walled construction. Outer body made of mild steel painted with powder coating. Inner chamber made of thick S.Steel complete with concentric rings. Temperature controlled by hydraulic thermostat from ambient to 95ºC, +/-1ºC. Complete with heating & main indicator, cord & plug but without thermometer. To work on 220/230V AC.   Size (L x B x H) 300 x 250 x 100 mm                 (6 holes 75 mm dia) 330 x 300 x 100 mm                 (9 holes 75 mm dia) 425 x 325 x 100 mm                 (12 holes 75mm dia) Optional Accessories Hygrometer (Dial Type Humidity Indicator) Wet and Dry Thermometer Automatic Voltage Stabilizer 3-0 KVA (Triple Relay)

Vibrating Table Proper compaction of cement concrete while casting specimens for compression testing is essential to achieve a better and more consistent mixture. Suitable for operation with 220 V, 1 phase, 50 Hz, AC Supply. SCO-1086 Vibrating Table with load cap 140kg, variable frequency The table top is 1000 mm x 1000 mm size and has stops along its edges to prevent moulds from sliding off the table during operation. The maximum load capacity is 140 kg. The variable pitch pulley arrangement permits the frequency to be varied step lessly between 60 Cycles/sec and 43 Cycles/sec SCO-1087 Vibrating Table with 2mt x 2mt top SCO-1088 Vibrating Table with 0.6mt x 0.6mt top Needle Vibrator For setting up fresh concrete, it should vibrate while casting the structure. SCO-1089 Needle Vibrator Motor driven 1HP 1ph.with 25 mm 3 mtr. Needle SCO-1089001 Needle 60mm SCO-1089002 Needle 40mm SCO-1089003 Needle 25mm Curing It consists of sheet metal and fitted with heater having thermostatic controller to maintain the temperature. While conducting the compression test of concrete casting moulds. It should cure properly as per standard Curing tank SCO-1090 Curing tank suitable for 24 cube mould of 150 mm. Temperature range from ambient to 100 Degree Cent. Capping set for Cylindrical Mould IS: 516, BS: 1881, ASTM C31 ASTM C617While casting the cylindrical moulds both side of mould should be flat and parallel when conducting a compressive strength test. These capping sets are for use in the field and in the laboratory. SCO-1091 Capping Set, Vertical for Capping 100 mm dia x 200 mm high Cylinders SCO-1092 Capping Set, Vertical for Capping 150 mm dia x 300 mm high Cylinders SCO-1093 Capping Set, Vertical for Capping 100 mm dia x 200 mm high Cylinders SCO-1094 Capping Set, Vertical for Capping 150 mm dia x 300 mm high Cylinders Accessory SCO-1091001 Capping compound powder SCO-1091002 Melting pot for Capping compound, 1 Litre Capacity, Working Temp. 150 C

IS: 4031A specially designed Vibration Machine is used for vibrating the mix in moulds according to strictly controlled programmer at a frequency of 12,000 ± 400 cycles per minute. The Vibrator is mounted over coiled springs and the vibrations are developed by means of a revolving eccentric shaft. The center of gravity of the vibrator, including the cube and mould, is either at the center of the eccentric shaft or within 25 mm below it. The simple design of the machine facilitates easy assembly and dismantling of the cube moulds. The machine is suitable for operation on 230 V, 50 Hz, and single-phase, AC supply. Each machine is supplied with one cube mould.The following mould can be ordered, as optional extraMould M. Steel, for 70.6 cm cubeNote The machine can certified for its frequency by the National Council of Cement and Building Materials (NCCBM) at Extra Cost.

This apparatus is used for penetration on a wide variety of material such as greases petroleum, bitumen tar wax and polish. It consists of Timer (for setting the number of fall of needle ) head support mounted on a vertical rod, which can be adjusted for a height. Rack and pinion assemblies provide a fine adjustment of needle tip to a sample and incorporate a slipping clutch mechanism which make a reading of penetration and subsequent resetting of a sample and accurate operation. The dial is graduated from 0- 400 in one tenth millimeter sub division. It is supplied with on e container and one set of needle. SPP-1036 Bitumen Cone PenetrometerSame as SPP-1035 but without timer SPP-1037 Bitumen Penetration KitsConsists of one container and one set of needle SPP-1038 Red Wood Viscometer no1 electric heated with solid-state electronic regular without accThese viscometers are designed for viscosity tests of petroleum products. They confirm to recruitments of IP 70. Two adaption of red wood viscometer are available No.1 for liquids having red wood flow 20 seconds to 2000 seconds and No.II for liquids whose flow time exceeds 2000 seconds. The complete out fit comprises hammer finished stainless steel bath with electrical heating arrangements suitable to operate at 220 Volts AC mains with tap, silver plated oil cup with precision stainless steel jet, cup, cover ball, valve, thermometer-clip. Stirrer and M.S. sheet stand with leveling screwsRedwood Viscomet Er No.1 a.) Electrical heated with energy regulator control b) Same as above with digital indicator and controller

Double walled construction. Inner chamber made of stainless and outer Mild steel painted with white stoving enamel. A water drain cock & stainless steel tray is provided at the base of the chamber. Temperature can be controlled up to -20°C by electronics Digital temperature controller cum indicator. High grade puf insulation is provided between the walls to achieve set temperature in short time. A sealed condensing unit of Kirloskar / Techmshah fitted at the bottom below working chamber. Suitable to work on 220/230 V, 50 Hz. Single phase AC supply.

STI-1001 IS: 654, 1237,1706For clay roofing tiles (Mangalore Pattern) and Cement Concrete Flooring Tiles. This is a double lever (leverage 1:12) loading machine and the load is applied by flow of lead shots, which automatically stops when the sample breaks. The load is applied at rate of 450 to 550 N/minute (45 to 55 kg minute) or 2000 N/minute (200 Kg/minute) and the accuracy of load indication is ± 2%. The sample is mounted between rollers 40 mm dia or12 mm dia. Bearing Rollers can be placed at center distance of 150 mm, 200 mm, 250mm or 270mm as the case may be. Complete with 20 Kg lead shots Abrasion Testing MachineSTI-1002 IS: 1237, 1706The tile sample is pressed under a specified load against a grinding path, strewn evenly with an abrasive powder, revolving at the rate of 30 ± 1 rpm. At the end of 100 revolutions of the disc, the second parallel side of the tile is subjected to wear for an equal number of revolutions of the disc. The wear of the tile is measured using thickness-measuring device (which is supplied at extra cost). The abrasion-testing machine consists of a replaceable grinding path, fitted on to a disc rotating about its vertical axis. The rotating disc and the grinding path are enclosed by a circular tray. A bracket holds the specimen. The loading is by a counter-balanced lever. A funnel is provided to facilitate charging the grinding path with abrasive powder. Supplied complete with automatic preset revolution counter and one 7.5 kg weight, but without abrasive powder and thickness measuring device. Suitable for operation on 220V, 50 Hz, 1 phase, AC Supply. Optional ExtraThickness Measuring Device with Dial Gauge, having 25 mm travel and 0.01 mm least count

his is a double lever (leverage 1:12) loading machine and the load is applied by flow of lead shots, which automatically stops when the sample breaks. The load is applied at rate of 450 to 550 Nminute (45 to 55 kg minute) or 2000 Nminute (200 Kgminute) and the accuracy of load indication is �± 2%. The sample is mounted between rollers 40 mm dia or12 mm dia. Bearing Rollers can be placed at center distance of 150 mm, 200 mm, 250mm or 270mm as the case may be. Complete with 20 Kg lead shots

This is used for measuring the thickness of the geotextile. The thickness of the geosynthetic material can be measured with an accuracy of 0.002 mm for thickness up to 10 mm. Accuracy is 0.01 mm for thickness greater than 10 mm. Simple mechanism is provided to apply desired foot pressure varying from 1 to 10 kPa Surface plate is grounded and is rust free to enable reproducible results. SGE-1016 Puncture TestIn this test, developed by the Corps of Engineers, USA, the geotextile specimen is clamped to obtain an inside dia of 44.45 mm and force is applied through an 8 mm dia plunger till failure. The Modified ASTM D-3787 provides for a hemispherical plunger and accordingly has been developed. The puncture strength so obtained is felt to reflect the fabric's ability to withstand aggregate penetration. SpecificationsSpecimen diameter: 100 mmMould for compaction of soil : 10 cm dia x 11.2 cm high Head of water: Upto 37.5 cm OptionalOverhead Tank

Compressive Strength The failure loads of mortar cubes can vary considerably according to the type of cement and the period of curing. However, a capacity between 50 kN and 500 kN encompasses the majority of test conditions. A 500 KN Compression Testing Machine is suitable for testing mortar cubes, cement mortar and pozzolana cubes of 50 mm. For details see under SCO-1040. SCE-1003 Flexural Strength4 kN Flexure strength Testing Machine,Electrically Operated,IS: 1727, 4031For the Transverse test of pozzolana and cement mortar prisms (Rilem Cembureau test) by single point loading of a 60 mm long prism supported at 100 mm centers. Smaller loads, less than 10 N, can be applied and measured with an accuracy of 1% in the upper four-fifths of the range. The load is increased at the rate of 40- 60 N/sec. Supplied complete with: Proving ring of capacity 4KN and Flexure Test Attachment. Gauging TrowelIS: 4031, IS: 5515 SCE-1004 Gauging Trowel, IS: 5515,200 mm long blade Weight 210 ± 10 g SCE-1005 Gauging Trowel, IS: 4031, 150 mm long blade with straight edge. Weight 210 ± 10 g SCE-1006 Gillmore Needle ApparatusASTM C 91, C414, C266, AASHO T154 For determining setting time of hydraulic cement. The apparatus consist of a base plate with a vertical shaft and two horizontal arms, the lower arm being adjustable for height. Supplied complete with one initial needle, one final needle and a base plate. Replacement Parts SCE-1006001 Initial Needle 1/12-inch dia. ¼ lb. wt. SCE-1006002 Final Needle 1/24-inch dia. 1lb.wt. SCE-1006003 Glass base plateJaw Crusher Designed to speed-up crushing of aggregates, Ores, Mineral, Coal and similar materials Compact and rugged for laboratory and small production units Manganese steel jaws adjustable for 6 mm opening Supported with strong steel frame SCE-1007 Jaw Crusher of 12 SCE-1008 Jaw Crusher of 6The specification is as follows.1. Single Toggle Jaw crusher size 4" x 6".2. Motor 3 hp /3phase/415 volt/50 cycle. 3. Jaws Speed 350 rpm 4. Jaws 10-12 Mn steel. 5. Bearing Bush type 6. Feed size 25 - 30 mm 7. Product Size 6-20 mm 8. Capacity 200 - 250 kg /Hour SCE-1009 Jolting Apparatus IS: 10078, 1982The jolting apparatus consists of a rectangular table, rigidly connected by two support arms to spindle at a horizontal distance of 800 mm from the center of the table. The table can be raised and allowed to fall freely by a cam, which is connected to a motor. The cam rotates at a rate of 60 rpm. A stroke counter, fitted with micro switch, is provided, which stops the machine after 60 jolts. Locating pins are provided for mounting the mould compartments on the table. The mould, surrounded by the hopper, can be clamped rigidly to the table. Supplied complete with mould and hopper. Suitable for operation with 230 V, 50 cycles, single phase, AC Supply.

Standard Penetration Test is a powerful tool for measuring the penetration resistance of the ground and relating it to the degree of compactness of cohesion less soil and consistency of cohesive soil. The results can be used for design of foundations. SPT is widely used for measuring the undisturbed strength of the soil and for assessing its resistance to liquefaction due to ground vibrations caused by earthquakes or other dynamic forces. The Standard Penetration Resistance is measured as the number of blows 'N' required to drive a split spoon sampler to a depth of 300 mm using a 65 kg weight falling freely through a height of 750 mm. The equipment consists of the followingSplit Spoon Sampler with Brass Liner or without LinerDrive Weight Cast Iron, 65 kgGuide Pipe AssemblyTripod, with Pulley and built-in Ladder'A' Type Drill Rods10 rod having 1 meter length SSO-1061001 Split Spoon Sampler with Brass Liner SSO-1061002 Split Spoon Sampler without Brass Liner

IS: 2720 (Part 2) - 1973 IS: 12175-1987 Using a speedy moisture meter, the moisture content of soils, sand and other fine-grained material can be obtained quickly with reasonable accuracy. The test technique is based on the fact that water will react with calcium carbide to form acetylene gas and the quantity of gas formed is directly proportional to the water present, leaving a surplus of the chemical used in the test. The quantity of acetylene gas produced is indicated on a built-in pressure gauge, which is calibrated in percentage of moisture on wet weight basis.   SSO-1059 Speedy Moisture MeterRange 0 - 25%, Gauge Division: 1% SSO-1060 Speedy Moisture MeterRange 0 - 50%, Gauge Division: 1%Each instrument is supplied complete in a carrying case fitted with counterpoised balance for weighing the sample, SSOop for measuring carbide reagent, a set of steel balls and a cleaning brush.Extra SSO-1060001 Calcium Carbide Reagent in a container of 500 gm

Specific Gravity is the ratio of the weight in air of a given volume of a material at a standard temperature to the weight in air of an equal volume of distilled water at the same stated temperature. The equipment mentioned below can be used to test a wide range of materials from clay to sand and gravel smaller than 10 mm. SSO-1038 PycnometerIS: 2386 (Part 3)-1963Consists of a 1 kg Glass Jar with Brass Cone, Locking Ring and Rubber Seal) Sample Riffle Divider IS: 1607-1977, 2720, ASTM C 136, D271, D421, D422, D423, D424, D427, D451, D452, D457, D806, BS: 812, 1377, AASHO T27, T87.For the rapid collection of true representative samples from aggregates, sand and fillers, sample divider is required. Riffle Sample Divider consists of a metal box fitted with a series of chutes of equal width, which discharge the material alternatively in opposite directions into separate pans. The chutes of the riffle are steep enough to allow rapid flow of the material. Supplied complete with three containers. SSO-1039 Riffle Sample Divider, 13mm slot width, 14 slots and approx. 2.1dm3 SSO-1040 Riffle Sample Divider, 25mm slot width, 16 slots and approx. 4.4 dm3 SSO-1041 Riffle Sample Divider, 50mm slot width SSO-1042 Riffle Sample Divider, 75mm slot width

IS: 10050-1981 For determination of resistance offered by rock to weathering and disintegration when subjected to immersion in water Facility to test upto four sets of samples Quick couplings for assembly and removal of drums The apparatus consists of a motor on baseboard capable of driving two or more drums at a speed of 20 rpm. A suitable number of plastic water troughs, each designed to contain a test drum with quick release drive assemblies, permit 1 to 4 drums to be driven at one time. The test drums are supported on water lubricated bearings allowing 40 mm unobstructed clearance below the drum and a trough water level 20 mm below the axis of the drum. Drums are made of brass and comprise 2 mm wire mesh cylinders of 140 mm dia and 100 mm length. The equipment consists of Base Board with Motor Drive assembly with two drum and tank assemblies. Suitable for working at 220 V, Single phase, AC supply. Extra Pair of Drums and Tank Assemblies including coupling, to enable upto 4 test drums to be driven at a timeElectrical Timer 0-30 min Features SRO-1009 Rock Bolt Pull Out TestBS- 11309, ASTM D-4435 These are used to measure the working and ultimate capacities of rock bolt anchors. Further, our products comprises of a central hole jack, hand pump with load gauge, directional control valve and only for central hole jacks above the capacity of 500kN, flexible pipes, truss high tensile test rod with coupling. Moreover, the load cell can be used for the measuring of pull out load and arrangement is provided for fixing dial gauge for estimating deflection against the load. In addition to this, we provide different size of adopters with the high tensile test rod.

IS:2720 (Part 7), 10077, ASTM D 427, BS:1377, AASHO T 92 The Shrinkage Limit of a soil is defined as the moisture content at which any further reduction of moisture will not cause volume reduction. The shrinkage of clayey soil can be very significant. A fully saturated soil specimen is allowed to dry in free air and its volume is measured repeatedly by immersing in a mercury bath. From the data obtained from this test, Shrinkage Limit, Shrinkage Ratio, Shrinkage Index and Volumetric Shrinkage can be calculated. The choice of puddle clay materials is often governed by the results obtained from this test. SSO-1053 Shrinkage Limit SetIS:10077 - 1982It consist one each of Glass Cylinder, graduated25 ml x 0.5 ml Porcelain Evaporating DishShrinkage DishGlass CupPerspex Prong Platewith three Metal ProngsPerspex Plain PlateSpatula

  The machine is constructed to hold flasks from 100 ml to 1000 ml. conical or round bottom. The shaking speed action is variable & controlled by speed regulator fitted with fractional H.P. Motor. To work on 220 V AC 50 Hz. supplied with plug & cord.   Available in following option. To hold 4 flasks To hold 8 flasks To hold 4 flasks with 4 bottles holder To hold 8 flasks with 8 bottles holders

  Double walled inside made of stainless steel outer made of M.S. duly painted with backed enamel paint. Range 5ºC above ambient to 90°C & controlled by thermostat. Complete with mains indicator & perforated tray. Cover is provided at the top. .   Inside chamber size 300 x 250 x 175 mm (2 Racks) 325 x 300 x 175 mm (4 Racks) 450 x 300 x 175 mm (6 Racks) 600 x 300 x 175 mm (8 Racks) Optional AccessoriesDigital Indicator cum controller can be fitted Stirrer can be fitted

SSO-1052 Sensitive Volume Change GaugeThe Volume Change Gauge illustrated works on the principle of reversing the direction of flow when the limit of the volume change scale is reached. The number of cycles with the volume of fluid handled in each cycle provides the total volume change, whereas the sensitivity is governed by the dia of the polythene tube used. The sensitive volume change gauge has realized sensitivity of 0.003 ml/mm with the 6 ml volume of fluid per cycle. The apparatus consists of a volume measuring polythene tube running along both sides of a scale and connected at both ends to two mercury traps. These traps are connected to flow reversal valves through a manifold. The length of the polythene tube is enough to measure 6 ml volume of fluid per cycle. A small pallet of mercury is introduced in the circuit to be used as a cursor, and the movement of pallet is measured. The unit is tested to a pressure of 20bar (20 kg/cm2) and is designed for wall mounting.

Double walled germinator with interior walls made of Anodized Aluminum/Stainless Steel. The exterior is made of heavy mild steel finished with stoving enamel. The temperature & humidity is controlled by Digital Temperature cum humidity Controller cum indicator from 5-50°C, +/-2°C and humidity from 60-95%, +/-3% controlled by imported Humidistat. Temp below ambient is controlled by hermetically sealed KIRLOSKER / Tecumseh condensing unit/compressor. The complete unit is fitted below the chamber on the heavy angel base. Complete with Aluminum/Stainless Trays (14 Nos.) Stainless steel water tank with heating element/Humidifier to create humidity inside chamber to work on 220/230V, Single phase AC supply. Chamber Size (W x H x D) 555 x 910 x 605 mm SHI-126 Optional Accessories: for SHI-124, SHI-125 & SHI-126 Provision for Exterior Lighting Arrangement. Provision for Inner illumination by fluorescent tubes. 0-24 Hrs. timer for regulating cyclic illumination condition. Voltage Stabilizer (3 steps Automatic).

SHI-124   Double walled Chamber with interior walls made of Stainless Steel. The exterior is made of heavy Mild Steel finished with stoving white enamel. The temperature is controlled by Digital Temperature Controller cum indicator from ambient +5 to 50°C, +/-2°C and humidity from 60-95%, +/-3% Controlled by Digital temperature & humidity controller cum indicator with aluminum/S.Steel Trays (14 nos.) S.Steel water reservoir provided inside the chamber with heating element to create humidity inside chamber. To work on 220/230 V, Single phase AC supply. Chamber Size               555 x 910 x 605 mm

Double walled Chambers with interior walls made of Anodized Aluminum/Stainless steel. The exterior is made of heavy mild steel finished with stoving white enamel. Both chambers have the facility to maintain the temperature from 5º-50º. Temperature in the chamber is controlled by 2 individual digital temperature &Humidity controller cum indicator in variation of +/- 1°C or better. Each chamber has a stainless steel water tank with heating elements, low water cutoff device with alarm to create humidity. Humidity is controlled by Humidistat. Each chamber has 14 trays inside it. Works on 220/230 V, single phase AC supply. Size (W x H x D) 555 x 910 x 605 mm SHI-127 Optional Accessories: Provision for Exterior Lighting Arrangement Provision for inner illumination by fluorescent tubes 0-24 Hrs. times for regulating cyclic illumination conditions. Voltage Stabilizer (3 step Automatic)

The apparatus consists of a 1mm dia hemispherical stainless steel needle, fixed to a platform of a counter- balanced rod, which is assembled on a grooved platform. A rack moves through the groove, to which a painted panel can be clamped. An indicator lamp is provided to indicate the metal contact if the Needle penetrates the paint surface to make contact with the metal. Complete with 1 kg weight. Suitable for operation of 230 V, 50 Hz, single phase, AC supply

SPP-1019 Scratch Hardness Tester IS: 101For determining the scratch hardness of ready mixed paints and enamels, which is the minimum load required to produce a scratch showing the bare metal surface of the painted panel. The apparatus consists of a 1mm dia hemispherical stainless steel needle, fixed to a platform of a counter- balanced rod, which is assembled on a grooved platform. A rack moves through the groove, to which a painted panel can be clamped. An indicator lamp is provided to indicate the metal contact if the Needle penetrates the paint surface to make contact with the metal. Complete with 1 kg weight. Suitable for operation of 230 V, 50 Hz, single phase, AC supplyOptional ExtrasNeedleWeight, 2 kg SPP-1020 Film Stripping Device The Film Stripping device consists of a disc of which four bottles are mounted. The disc rotated at the rate of approximately 100 rpm A time switch is provided. Suitable for operation on 230 volts, Single phase, A.C. Supply.

  Sand Pouring Cylinder Apparatus, IS: 2720 (Part 28) This Apparatus is used for determination of the dry density of compact, fine, medium grained soils and for layers not exceeding 50 cm thickness. A circular hole is dug into the ground, all the soil from within it collected, weighed and dried, and the hole back-filled with a standard uniform sand or fine gravel, poured from a calibrated container for calculating the volume of hole. The apparatus consists of the following:Sand Pouring Cylinder fitted with Conical Funnel and ShutterSHIVAM offers following modals of sand pouring cylinder   SSO-1049 Sand Pouring Cylinder Apparatus 100mm Dia. SSO-1050 Sand Pouring Cylinder Apparatus 150mm Dia. SSO-1051 Sand Pouring Cylinder Apparatus 200mm Dia. It consist of Cylindrical Calibration ContainerMetal Tray, with central holeOptional ExtraMetal Tray, without central hole.

Modern test procedures require specimens of cements, limes and related materials when formed into mortar, to be cast in certain standard shapes and sizes for determining the mechanical properties with a view to have a proper control on the quality of materials used. Mortar is prepared by mixing 185 g cement, 555 g standard sand and 74 g water separately for each cube of 70.6 mm. The homogeneous mixing is done using a mortar mixer and compacted using a vibration machine. Mortar Mixer IS: 10890-1984This apparatus has specially been designed to prepare cement mortar for strength determination as specified in IS: 4031. It can also be used in mixing lime with pozzolonic materials for determination of lime reactivity (as per IS: 1727) and for uniform mixing of soils with additives such as lime, cement, etc. The stainless steel mixing bowl has a capacity of 4.75 litres. The paddle, also made of stainless steel, can have both planetary and revolving motion for uniform mixing. It can be electrically driven at two speeds: CRUSHING AND GRINDING SCE-1021Pulveriser Designed for grinding materials to produce fine mesh samples. Ideal for use in cement and chemical industries Self contained grinder with a rotating disc having planetary movement in vertical plane. Reduces about 450g quartz type material to 100 mesh in one minute. Suitable for operation with 440 V, three phase, AC supply.

We are offering a wide range of soil testing equipments from India.
