Alternator Voltage Regulator
Get Price Quote
We are offering alternator voltage regulator (avr) for brushless alternator.
pentacon dp 201 avr is half wave thyrister controlled associated with free wheeling diode for brush-less type alternators. Dp 201 is designed a spacial relay-less electronic circuit, compatible with all in-range excitation ratings brush-less type alternators. Pentacon dp 201 avr is a repairable unit, a thin coating of epoxy is applied to prevent damage from vibration, moister. Pentacon dp 201 avr is provides under-speed excitation protection, by reducing the output voltage proportionally with speed bellow a preset threshold. Use of high efficient and sensitive semiconductors, positive voltage build-up is ensured from lower residual voltage.
specifications:
input voltage : up to 475 ac, two phase &neutral at u,v &n
input frequency : 50 hz & 60 hz , adjustable through trim-pot
output voltage : up to 110 vdcatf+&f-
output current :5 amps continuous/ 11. 5 amps transient for 10 sees.
regulation :+/- 1%
avr response :20 ms
build-up voltage :5 volts at avr terminals
under frequency
protection :47 hz (resettable) at factory setting
protection fuse :4 amps fast blowing glass fuse 19mm x 5 mm.
...more
