conventional rotator
89,000 - 139,000 Per Set
1 Set(s) (MOQ)
1 TON CONVENTIONAL WELDING TANK ROTATOR. PU WHEEL. VFD DRIVE. SPEED RANGE: 250 mm/min to 1250 mm/min SHE'LL DIAMETER: 300 TO 1000 mm.
conventional rotator
Get Price Quote
conventional rotator These comprise basically two sets of rollers (1 drive + 1 idler) which are adjustable either manually( connecting shafts) across the frames or through lead-screw ( with motorized or through ratchet) when changing from one diameter to another.
Best Deals from Conventional Rotator
Conventional Welding Rotator
Get Price Quote
Conventional Rotator:
Get Price Quote
The Conventional Welding rotator capacity ranges up to 1500 tons for larger loads and larger diameter range, provided with all Polyurethane wheels with overload disc and all steel wheels according to the capacity. The frame and rotator base is fabricated vigorously to ensure perfect alignment to carry the weight of the vessel Job. Both the drive and the idler frames are provided with robust fabricated and machined wheel brackets which support the axles and bearings of the rollers
Conventional Type Rotators
Get Price Quote
These type of Rotators are similar to Self Centering Type Rotators. The only difference between the two is that in Conventional type Rotators we use single motor and provide adjustable connecting shafts between the gearboxes as per job diameter settings while in Self centering types we use twin motors in both ends. The Specifications for Conventional Rotators are same as that for Self Centering Rotators…
conventional rotator
Get Price Quote
Conventional Rotators are built in capacities from 1T to 2000 tonnes. The frame is of robust fabricated construction and is machinened on the top and underneath to ensure perfect alignment. Both the drive and the idler frames are provided with robust fabricated and machined wheel brackets which support the axles and bearings of the rollers. According to capacity the Rotators are provided with all rubber tyres, or Polyurethane tyres and separate all steel overload wheels, or can be of course be supplied with cast steel wheels. The Rotator base fabrication, or chassis, is designed and fabricated to carry the weight of the vessel / Job and incorporates a contingency for shock loading. It is important that the design eliminates any distortion which can lead to misalignment of the rollers. The drive section comes under the biggest strain when the vessel /Job is being loaded. It is physically impossible for a crane operator to position the vessel so that it contacts with both sets of rollers at the same time. If the work-piece one roller before being supported on all the rollers, the first roller will receive a full shock load which puts a considerable force on to the drive. We have endeavored to incorporate a good overload margin to absorb this shock load.
Conventional Rotators
Get Price Quote
Conventional Rotators are built in capacities from 1T To 2000 Tonnes. The frame is of robust fabricated construction and is machinened on the top and underneath to ensure perfect alignment. Both the drive and the idler frames are provided with robust fabricated and machined wheel brackets which support the axles and bearings of the rollers. According to capacity the Rotators are provided with all Polyurethane wheels with overload disc and all steel wheels. The Rotator base fabrication, or chassis, is designed and fabricated to carry the weight of the vessel / Job and incorporates a contingency for shock loading. It is important that the design eliminates any distortion which can lead to misalignment of the rollers. The drive section comes under the biggest strain when the vessel /Job is being loaded. It is physically impossible for a crane operator to position the vessel so that it contacts with both sets of rollers at the same time. If the work-piece one roller before being supported on all the rollers, the first roller will receive a full shock load which puts a considerable force on to the drive. We have endeavored to incorporate a good overload margin to absorb this shock load.
conventional rotator
Get Price Quote
Conventional Rotator : The conventional rotator are having One power unit and One Idler unit with combined load capacity of set, as per the rated load of Set. The vessel or job will be supported on one set of rotator and job will be manipulated for the need. V-Weld Design quality conventional rotators having various salient features. Conventional welding rotator ranges includes up to 1500 tons and can be enhance up to 3000 Tons. However, it is futile to make a single conventional rotator with such high load, as more effective and better solutions are available to cater higher capacity for Nuclear, Generator, ship building and other requirements. The constant center line ( CCL) design is effective method of center adjustment of rollers, so that job center always remain unchanged. The adjustment between two rollers will be done by manual drag and clamp method, which is more practical, less maintenance and user friendly. Manual or motorized adjustment of rollers can be provided on request. Yes, various roller material optional like Urethane, Cast Steel or Steel wheel, as per the model selections are available. Anti drifting system and fit up type rotators are available. Rotators can be used for multi-applications like Application : Pressure Vessels, Heat Exchanges, Boilers, Tanks, Pipe welding, Generators etc. Benefits of Welding Rotator : Fast production and quality improvements Reduce fatigue for welder No need to use crane of job handling Conventional Welding rotator capacity range upto 1500 tons. For larger loads and larger diameter range, consult factory for solutions..
Conventional Rotators
Get Price Quote
Construction of the machine is similar to that conventional type Rotators. However, the Roller Housing Brackets in this are supported directly on the machine bed and are attached to the bed only with an L.H. T.H. Lead Screw and nuts. When the lead Screw is rotated with the ratchet handle, the Roller Brackets move simultaneously towards each other or away from each other. In this series there will be twin drive arrangement. This type of design provides simultaneous and step less adjustment of Roller housings, and keet the axis always at the same position irrespective of diameter setting.
welding conventional rotators
Get Price Quote
welding conventional rotators, Welding Equipment, Welding Positioners
conventional rotator
Get Price Quote
conventional rotator, Engineering Goods, welding automation equipments
conventional tank rotator
Get Price Quote
conventional tank rotator, Welding Machine, air cooled welding transformer
Conventional Rotators
Get Price Quote
Conventional Rotators, air hoists, LFree Standing Workstation Cranes
Conventional Rotators
Get Price Quote
Conventional Rotators, fettling equipment, Transfer Molding Press
conventional rotator
Get Price Quote
conventional rotator
