DC Electronic Loads Dealers

• CV CC MODES: CR CP modes optional

We are offering electronic load. Electronic load is used for testing dc power supply, batteries, fuel cells, solar panels panels, voltmeters,automotive parts testing

• temperatures: 25 °C.

DC electronic loads manufactured microchannel water-cooled heatsinks, the WRx Series addresses high power DC applications where exhaust heat control is essential. The WRx Series greatly increases power density compared air-cooled alternatives. An integrated solenoid controls the flow of water to avoid condensation. Full power can be achieved using conventional water, with water inlet temperatures up to 25 °C.

TH8215 Programmable DC Electronic Load Input Power: 1200W Input Voltage: 800V Input Current: 60A Dynamic Frequency: 50kHz Samping Speed: 100kHz Features ■ Constant current (CC), constant resistance (CR), constant power (CV), constant power (CP) operation mode ■ Current remote control monitoring function, external trigger function ■ 1mV/10μA high resolution, ripple measurement function ■ Dynamic current/voltage test, up to 50K dynamic frequency ■ Voltage and current measurement can achieve high precision while testing speed up to 100KHz ■ Programmable soft start function ■ CR-LED test, arbitrary I-V characteristics, battery test, dynamic scan test, load effect, list function and many other advanced functions ■ Overvoltage (programmable), low voltage, over current(programmable), overpower (programmable), overheating,anti-reverse protection, etc. ■ Remote voltage compensation input test function ■ Short circuit function simulation ■ The adoption of the Linux operating system makes the number of internal parameter file storages essentially unrestricted ■ Perfect U disk function (parameter file storage and loading,interface screenshot, system firmware upgrade) ■ Setting parameters support power-off memory function ■ Intelligent temperature control fan ■ RS232 (standard), USB (standard), Ethernet (standard), WIFI(optional) ■ Matching with upper-computer software to achieve remote operation and monitoring matching   Application ■ Power   Chargers, switching power supply, communication power, LED drivers, cell phone batteries, portable power source ■ New energy   Solar cells, new power cars, electric bicycles ■ Electronic power components   Fuse / Connector / Relay / Sensor ■ Automated equipment integration testing   Specifications Model TH8215 Input power 1200W Input voltage 10-800V Input current 60A Static mode Constant current(CC) constant resistance(CR) constant voltage(CV) constant power(CP)   10V@0.6A Minimum operating voltage 10V@6A   10V@60A Constant voltage (CV) Range 0-80V Resolution 5mV Range 0-800V Resolution 50mV Precision 0.05%+0.05%FS Constant current (CC) Range 0-0.6A Resolution 0.02mA Range 0-6A Resolution 0.2mA Range 0-60A Resolution 2mA Precision 0.1%+0.1%FS Constant resistance (CR) Range 0.15Ω-1.5kΩ Range 0.6Ω-6kΩ Range 15Ω-60kΩ Resolution   Precision Vin/Rset*0.2%+0.2%FS Constant power (CP) Range 0-12W Resolution 1.2mW Range 0-120W Resolution 12mW Range 0-1200W Resolution 120mW Precision 0.3%+0.3%FS Protection function: over power protection (OPP), over current protection (OCP), over voltage protection (OVP), over temperature protection (OTP), reverse voltage alarm (REV), under voltage protection (UVP) Short circuit function Interface: network port LAN, Handler port, USB Host, USB Device, parallel interface Power supply and safety Power supply 110/220VAC Power frequency 50/60Hz Safety certificate CE Environment and temperature Operating temperature 0-40°C Storage temperature -20-80°C Dimensions and weight Dimensions (mm) 215*129*479mm Weight (kg) 8.7kg-430*129*479mm

We are offering electronic load. Vel 2000 is an electric load with manual and programmable operation and respective maximum power ranges between 50 and 2000 w. They are used in various applications (e.g. Training, research, development, laboratories, inspection, production, test field, quality assurance) for fast and precise simulation of voltage loads. They are useful for e.g. Static and dynamic power supply and battery testing. These electronic loads easily simulate a multitude of load applications. Simple and clear operation of electronic loads is achieved via operation mode switch.

Product Description The DL3000 is a cost-effective programmable DC Electronic Loads with performance specifications that rival any instrument in its class. With a user-friendly interface including graphical charting, the DL3000 series provides various interfaces for remote communication to meet your diversified test requirements. Test power systems and batteries with configurable static, transient, and advanced application modes. Product Features Dynamic Load Performance and Visualization Up to 5 A/us slew rate and 30 KHz dynamic loading High resolution and accuracy on voltage and current load conditions 3 Built in application setups for battery testing or Current or Power optimization Free UltraLoad Software for remote operation and monitoring

This is a modular system which can be configured by the user to use for DC constant current loads up to 200 Amps at voltages up to 60 V. There are 2 modules of 10 Amp & 20 Amp each. Each one has a Potentiometer & an ammeter to set the load current. All of them can be cascaded to achieve the required load OR all can work independent. There is digital input to each load which will put ON or OFF the load. A PLC can be used ( which we can provide ) to program a ON / OFF cycle & a cycle count to ensure that the load current is ON & OFF for a given time & programmed number of cycles.   Typical application includes wiring harness testing for the automobiles, educational training, etc.We can also provide suitable Power source for your load. This together can make a complete system. All the products are industrial grade.

• Input: 24V DC

DC electronic loads Overload & Short circuit Protection.Switching Frequency 50 100 KHz.Operating Temperature Range: 0 to 55°C.

• Power: 200W, 250W, and 750W
• Voltage: 120V and 500V
• Application: Industry / Laboratory
• Brand: Keithley (Tektronix)
• Temperature: 0 to 50 degree Celsius

• Maximum Power: 15 kW
• Maximum Voltage: 200 Vdc

15 kW to 120 kW+ Water Cooled Active Resistance DC Electronic Load, MagnaLINK™ Distributed DSP Architecture, 16-bit digital programming and monitoring resolution, Many control modes, including: voltage, current, power, resistance, Integrated front and rear full control (host) USB ports, RS485, and dual MagnaLINK™ ports, with LXI TCPIP Ethernet and IEEE-488 GPIB available.Integrated arbitrary waveforms with up to 100 steps per stored function1

Sinetec DC electronic loads provide you with the flexibility to test a wide range of applications from power-supply test to simulation of high-intensity discharge (HID) headlamps. The 16-bit voltage, current and power-measurement system provides both accuracy and convenience, and eliminates the need for a DMM, external shunts and wiring.Contact us to request more information

The DL3000 is a cost-effective programmable DC Electronic Load with performance specifications that rival any instrument in its class. With a user-friendly interface including graphical charting, the DL3000 series provides various interfaces for remote communication to meet your diversified test requirements. Test power systems and batteries with configurable static, transient, and advanced application modes. Product Features Dynamic Load Performance and Visualization Up to 5 Aus slew rate and 30 KHz dynamic loading High resolution and accuracy on voltage and current load conditions 3 Built in application setups for battery testing or Current or Power optimization Free UltraLoad Software for remote operation and monitoring

• Application: Industrial
• Material: Stainless Steel
• Phase: Three Phase
• Color: Silver
• Usage/Application: Industrial
• Automation Type: Automatic
• Operating Voltage: 220 V

M9811 is applicated in production line(cell phone charger, cell phone battery, electric vehicle battery, switching power supplier, linear power supplier, LED driver), research insititutes, automotive electronics, aeronautics and astronautics, ships, solar cells fule cell, etc.B.

• Brand Name: SCIENTIFIC
• Application: Laboratory
• Model Name/Number: SCIENTIFIC SM6019
• Color: White
• I Deal In: New Only

• Features: VFD display, exquisite appearance, simple operation, 24-hour timing function, able to realize time measurement and control, Remote voltage test V-sense function,Protection functions: over input voltage, over current, over power and over heat protect

The 3260A Series is a 300V High power AC and DC Load in one unit, it provides an ideal testing solution for UPS, AVR, DA inverter, especially for step or square waveform UUT,each High power Series AC&DC Load has it own control and display panel, and with 5 states Recall Store memory which provides load set-up more efficiently,adjustable power factor setting (PF, Range: 1, 0.85 ~ -0.85) extends the simulation of test environment ,built-in GONG meter check function offers brief test result diagnosis for production, QC test throughput.

Nvis 726 AC/DC Load is an important device in all the Electrical laboratories. One can connect a load upto 1.2KW using this product. The device comes with On Board Switches, so that one can vary the load as required, in steps of 100W. The product is designed so as to provide load for various experiments of Transformer, Motors, Generators etc. Product Features Exclusive and rugged designed panel Stand alone operation Designed by considering all the safety precautions Online Product Tutotial

electronic load, Clamp Meter, Multimeter, high voltage probe

• M9711 Model: 150WATT, 0-30Amp
• M9712 Model: 300WATT, 0-30Amp
• M9712B Model: 300WATT, 0-15Amp
• M9712C Model: 300WATT, 0-60Amp
• M9713 Model: 600WATT, 0-120Amp
• M9714 Model: 1200WATT, 0-60Amp
• M9715 Model: 1800WATT, 0-240Amp
• M9716 Model: 2400WATT, 0-240Amp
• M9836 Model: 20000WATT, 0-500Amp
• M9836B Model: 20000WATT, 0-240Amp
