Flap Valves Dealers

The raw material that is used for manufacturing superior grade products is sourced from the reliable places after complete quality confirmation. We are one of the respected names engaged in the process of supplying quality Motorised Double Flap Valve at nominal rates.

Foot valve is meant to stop water draining out of suction lines in pump applications. Whether you draw water from a lake, canal, pond or tank the foot valves act as a dual purpose by filtering of the water and also holding in the priming pump head. Though foot valves are for general application there are specially designed foot valves for specific applications like common wells, ponds, deep bore wells etc

UNICON provides a complete line of dump valves (also known as double dump valve, or double flap valves) suitable for air lock applications. Similar to the rotary airlock valve, the dump valve is used in pneumatic conveying systems, dust control equipment, and as volumetric feed-controls to maintain an even flow of material through processing systems. In a dump valve, however, the flow control is accomplished through two chambers.

Double Flap Valves, also known as Double Flap Valves or Double Flap Gates, are a type of airlock valve commonly used in industrial applications as a component in bulk material handling applications.   Double Dump Valves are primarily used to discharge chunky, pellets, granules or fibrous, bulk materials from hoppers, bins, and cyclones operating under positive or negative pressure.   Double dump valves are used to discharge a flow of material while at the same time serving as an airlock transition point to preserve the pressure differential above and below the valve.   This type of material handling valve is ideal for use with bulky or abrasive materials that would tend to jam or damage a Rotary Feeder   Double dump valves have two trap-door flap plates which open and close on an alternating cycle. The top gate opens to allow collected material to drop through onto the bottom gate. The top gate then re-closes to prevent air leakage above the valve. The bottom gate then opens to allow material to pass completely through the valve. The bottom gate then re-closes to prevent air leakage below the valve. This cycle is continuously repeated in order to maintain a steady discharge of material from the valve, while maintaining a positive seal on the system.   Each flap plate has its own pneumatically operated cylinder and solenoid valve. The timing of the valve is controlled by an electronic signal sent to the solenoid valves. This method of operation is design to provide first class automation with sequential controller for accurate timing of the desire functioning of the valve.

Whizz Engineering Services Pvt. Ltd. is one of the leading manufacturer and supplier of highly double flap valve in Pune. Double flap valves are a type of airlock valve commonly used in industrial applications as a component in bulk material handling applications. Double flap valves are primarily used to discharge chunky or fibrous, bulk materials from hoppers, bins, and cyclones operating under positive or negative pressure. Clients can avail this double flap valve at very reasonable rates.

Double Flap Valve allows material to flow, while preventing the back flow of air or gas that is critical in many conveying systems. These devices are commonly used wherever dry solids need to be moved between areas of differing air pressure, including ash handling. Typical Double Flap Valve equipment applications include drop-out box hoppers, Dust Collectors, Bag Houses, Precipitators and screw conveyors. Double Flap Valves can handle material like Fly Ash, Sawdust, Lime, Cement, Clinker, Sinter and sand. Other types of material can be collected as long as they are granular, not sticky and flow freely by gravity. This Flap Valve can be motorized, pneumatic & gravity operated.

Flap valves It is available with standard as well as customized configuration. The size ranges from 50 NB to 900 NB. Range also includes pressure rating,

Double flap valve is continuous material discharge equipment. Double Flap Valve has a two door flap plate which open and close alternatively. As the material falls on the top plate, during continuous operation the plate opens and discharges the material on the bottom plate. After discharging the material the top plate closes. This ensures that the DFV is sealed to prevent air leakage. The bottom plate then opens after the top plate is closed and allows material to fall onto onward collecting equipment. The cycle time is precisely adjusted such that after the bottom plate closes the top plate opens. Thus ensuring continuous air sealing across the DFV. The time for which both flap are in closed condition, is known as dwell time.

Double Cone Flap valves are used for controlled feeding as well as achieving air lock sealing. These valves consist of two independent Cone Flap valves mounted one upon other with their opening and closing alternated and synchronized to ensure that only one valve opens at a time. DEMECH manufacture these valves to suit the opening sizes and required through-put rate. The through-put of these valves depend on the holding volume of the upper valve chamber and the rate of operations. These are very slow operating valves as the operation cycle rate does not usually exceed beyond 6 cycles per minutes. Thus these valves have a batch feeding pattern rather than continuous feeding. Selection of Cone or Flap depends on the characteristics of material to be handled and system requirement like pressure sealing. Cone valve has a better sealing than the Flap valve. However, in smaller size valves the Cone can act as an obstruction in the flow resulting in clogging of the small opening. The Cone valves usually have round opening whereas the Flap valves can have square.

The Flap Type Gravity Diverter comprises of flap enclosed in body which is key component in supporting diversion of product. This arrangement is used when product coming from top of diverter is to be diverted in vertical direction and angle between diversions of valve is up to 30˚ and 60˚. In above case, only one diversion is in operation and other is closed. In other words, the material can be conveyed from inlet to straight position or inlet to diverted position of diverter at a time. The basic design is for diversion of product coming down due to gravity.

These flap type of foot valves are used to fit with flanged end products and are available with rubberleather flap as per the client requirements. C. I. 4 & 6 bolts foot valve heavy duty flanged sizes range: 2” to 12”

We are leading manufacturer and exporter of Flap Valves Manufacturers, Flap Valve, Flap Valve Manufacturer, Manufacturer and exporter of Flap Valve, Flap Valve Manufacturer In india.We are Offering Flap Valves, Bolt cover,structure of flip-chip balance able pressure and light onoff operation.An oil grove is set between valve body and seal surface,which may infuse the seal grease to increase the seal capability.

Avail from us the advanced Flap Valves that are precisely designed for flawless performance. Being one of the major Manufacturers and Suppliers in India, the company offers premium grade Flap Valves. Owing to their quality and reliable performance, these Flap Valves are largely used in diverse industrial applications. Furthermore, we offer these Flap Valves at market leading prices. Attributes Easy assemblySturdinessRust proofLonger life

Approvals from almost all the major government, semi-government & private sector customers, consultants & contractors in the power generation, water supply & sewage treatment, irrigation, plant water handling & a well spread marketing network all over the country ensure that we are accessible & approachable for nearly every requirement. Thousands of successful installations all over the country over the last three decades are a testimony to our dedication, commitment & expertise.Our valves have a reputation for quality and reliability. This long established reputation is maintained by modern design and manufacturing techniques.

Pendulum Flap Valve is widely used as a discharge valve below the bag filters. We are recognized as a renowned Manufacturer and Supplier of Pendulum Flap Valve from Gujarat, India. Our Pendulum Flap Valve is manufactured using qualitative raw material that is sourced from trusted vendors of the market. The Pendulum Flap Valve that we offer is suitable for high pressure applications.
