Optical Microscopes Dealers

We are offering deluxe projection microscope. The instrument is being used satisfactorily in various educational institutes, pathological and research laboratories. It is also being used in textile industries by fixing micrometer eyepiece.

We are offering kx 2000 binocular compound microscope. Kx 2000, c shaped sturdy stand siedentopf binocular tube, 30° inclined, 360° rotatable, ipd 48-75 mm, with dioptric adjustment on left ocular wide field eyepiece wf 10x18mm paired with eye guards quintuple nosepiece (ball bearing type) fp series din plan achromatic objectives 4x, 10x, 40x (spring loaded) and 100x (spring loaded, oil immersion) stage rectangular size 142 x 133mm double plate with mechanical stage cross travel 75 x 50mm on ball bearing with co-axial control, spring clip double slide holder sub-stage abbe condenser na 1.25 with aspheric lens. Iris diaphragm and special day light blue filter co-axial coarse and fine focusing mechanism with tension control illumination system 6v-20w halogen with intensity control. Power input 220v ac

Medical Projection Microscope – IT is an advanced versatile projection equipment for measurement of specimen, equipped with bright halogen bulb 12 volts, 100 watts solid state variable light control arrangement workable on 200 volts AC mains inter locked with electronic fuse system, Quadruple revolving nose piece, 125mm dia graduated screen rotatable through 360o built in fresnel lens, mechanical stage. Built in adjustable compensating eye piece connected with magnification correction knob to provide magnification from 125x to 1000x with following optical combination supplied with one stage micrometer for measuring one spare fuse and cover in sturdy card board box objectives: 5x, 10x, 20x and 40x.

stand -rigid & heavy single mold aluminum die-cast stand. observation head- binocular head inclined at 45o and rotatable in 360o.  eyepiece -10x wf (paired) anti-fungal eyepiece. H6x (paired) extra.  nosepiece - quadruple ball bearing revolving nose piece  objectives- 4x/0.10, 10x/na 0.25, 40x/na 0.65(sl) & 100x/na 1.25(sl) oil imm. stage - circular rotatable stage 360o. polarizing attachment-  full wave & ¼ wave compensating plates, bertrand lens, sliding type removable analyzer from optical path and 360° swing out polarizer. focusing - separate coarse and fine knobs reading up to 0.002mm.  condenser- na 1.25 fitted with iris diaphragm and blue filter holder.  illumination- halogen 6v-20w with variable intensity control.  power- ac input 100v-240v, 50/60 hz iso 9001, ce approved. packaging contents- styrofoam molded, nylon dust cover,

Backed by the team of experienced professionals, we are manufacturing and supplying an extensive array of microscope. Our offered range includes high magnification microscope, stereo microscope, and zoom scope, which is available with related accessories. In order to manufacture this range, we use quality tested material and advanced technology in compliance with international quality standards. this range is widely used in academic institutions, educational centers and research institutes. In addition, our range is highly appreciated due to its easy installation, low maintenance and durability.

We Offer Research Polarizing Microscope. Large Rectangular Heavy Base Having Electrical Fittings Concealed Inside. Body microscopes are Available with Monocular, Binocular & Trinocular Heads with 45º Inclined Observation Tubes. Interpupillary Distance & Dioptric Adjsutments are Provided in Binocular & Trinocular Heads. Nosepiece centrable Precise Ball Bearing Quadruple Having Objective Mounts & Ribbed Grip for Easy Rotation. Stage compact Ball Bearing Rotating Stage, 140mm Dia., Graduation with Vernier, Lock & Stage Specimen Clips. Focusing coaxial Focusing is Provided with Coarse Tension Adjustment Ring and Graduated Slow Motion Knobs. Adjustable Safety Lock is Attached to Prevent the Breakage of Specimen Slides. Illuminator koehler's Illuminator with Pre-centered 20w Tungsten Halogen Source & Integral Electric Transformer with Intensity Control. Input Voltage 220 or 110v. Intermediate Tube built-in Focusable Bertrand Lens with Center Adjustment. Built-in Analyzer Removable from Optical Part. Analyzer Can Be Rotated 90º with Vernier Reading to 6'. Compensator 1 Lambda, 14 Lambda & Quartz Wedge Can Be Inserted in the Tube as per Requirement. Compensator gypsum (1st. Order Red Compensating Plate, 560nm). Mica (145nm) & Quartz Wedge (i-iv Order). Objectives stress Less Flat Achromatic Din Objectives pf4x0.10, Pf10x0.25 & Pf40x0.65 Sl eyepieces hkw10x Paired & Wf 10x Cross polarizer fully Rotatable Polarizer On a Strain Free N.a 1.25 Abbe Condenser with Iris Diaphragm. Accessories vinyl Dust Cover, Duster, Cleaning Brush, Filters, Spare Bulb & Fuse with Operating Instructions Manual. Packing in Full Mould Styrofoam Container. Optional Accessories detachable Mechanical Stage, Objectives Pf20x & Pf60x, Micrometer Eyepiece Wf10x, Microphotographic Equipment, 30º Inclined Siedentopf Heads. Wooden Storing Cabinet Etc.

We are actively known for providing Projection Microscope to the clients. Our Projection Microscope is a result of the sophisticated technology and high-grade components that we put in for its manufacturing. Our Projection Microscope provides easy adjustments without causing any strain to the eyes. Offering reliable Microscopes, we are known as prominent Projection Microscope Manufacturer, Exporter and Supplier. Specifications : Microscope Body is heavy duty, inclined monocular type with sturdy baseEquipped with Coarse & Fine Focusing systems with Quadruple revolving Nose PiecePlain stage (120x120mm) with graduated Mechanical Stage for X-Y movements of specimen slideBuilt in light by 6V-20W halogen lamp with continuously variable light intensity controlThe whole system of condenser & light arrangement is moveable up & down by rack & pinion to get the optimum resultsProjection Doom of screen size 150 mm is rotatable through 360oObjectives : Achromatic 10x & 20x/40x (SL)Projection Eye Piece : 10x (Huy)Packed in a thick and attractive plywood box

A microscope for visualizing objects in transmitted ray as well as incident ray microscopy under polarized light. We have an expertise in manufacturing and exporting a versatile range of transmitted & incident light polarizing microscope which is an ideal equipment for diverse industrial applications. It is designed for the study & research in Mineralogy, Petrology, Crystallography and Geology. Provided with Binocular / Trinocular Head, Ergonomic location of coaxial coarse and fine motion. Provided with two Polarizers, Analyser Achromatic Strain free objectives Imported / Indigenous 5x, 10x & 40x, corrected for incident light and Two Paired Eyepieces WF10x (One Cross hair) and H15x, Built-in 6V 20W halogen lamp Illuminator with variable transformer built in the base. Provided with iris diaphragm in the incident light illumination, Optional attachable mechanical stage and Accessory plates Mica quarter wave and Red Ist order, Quartz Wedge. A 35mm SLR or Digital camera can also be attached to the Trinocular Tube. It is available in three models that are Binocular Transmitted & Incident Light Polarizing Microscope, Trinocular Transmitted & Incident light Polarizing Microscope and Trinocular Transmitted & Incident light Polarizing Microscope with 35mm Camera & Digital Camera. A wide spectrum of Transmitted & Incident Light Polarizing Microscope manufactured by us are available at highly competitive prices.
