Polarimeter Dealers

We are a quality driven and make sure that the offered lot is prepared using the premium grade raw material. Also, we make sure that it is sourced from the certified vendors. We are capable of handling both automated inbound and outbound consignments, we have excellent warehousing solutions available. We keep the extensive array of products sorted to make sure that the delivery commences thoroughly. Analyser brass scale graduated from 0-360 deg. or 0-180 deg. with vernier reading 6" and accomodates a 200 mm glass tube. It is packed in a card board box

Consist of a imported half shade nicol polariser, analyser, 100mm. Diameter circular scale divided in degrees 0-360 Deg. x 1 Deg. And a sugar scale divided –30 Deg. To + 130 Deg. X 1 Deg. ISS, a divided micrometer drum is given to read 0.05 Deg. (3 minutes) and 0.1 Deg. ISS, the scale is properly illuminated for taking readings, the body is very sturdy and separate sodium lamp is stand is provided. Complete with polarimeter tube, bubble traps at the center, 200mm. Sodium lamp with stand and transformer

Available as single, dual and multiple wavelength derivatives not only covering the visible spectrum, the ADP600 Series of Peltier temperature controlled polarimeters are capable of measuring optical rotation to four decimal places in the highly sensitive ultra-violet region. This capability makes the instrument particularly suited for use by scientists wishing to measure chiral compounds and other optically active substances in the chemical, pharmaceutical and food sectors as well as for use in academic research. Sample Tubes & Peltier ControlPeltier technology is intelligently applied to the sample chamber of the new polarimeters so that measurement can be accurately made without the need of an external device such as a waterbath to control sample temperature. The ADP600 Series Polarimeters have two preset operating temperatures being 20 and 25 °C in accordance with European and United States Pharmacopoeia respectively and other user temperatures between 20 and 30°C may be configured via the instrument user interface.ADP600 Series Polarimeters accept standard glass or special low volume leur taper polarimeter tubes facilitating measurement across optical path lengths between 5 and 200m with tube diameters from 3 to 8mm being readable. Optional lids may be easily be fitted to the ADP600 Series Polarimeters, facilitating sample tube entry and exit.

Polarimeter is an instrument to find out Optical Rotation. From Optical Rotation one can derive the value of Specific Rotation of a liquid sample. The biggest application for this system is in the field of Pharma. Also other Industries like Sugar, Food, Flavours & Fragrances, Chemicals, Intermediates use Polarimeters in their Labs. In a Polarimeter the concept is as follows: There would be a light-source. The light which travels in all directions is polarised with a Polariser. When the polarised light travels through the sample, due to the nature of the sample, the light turns to the left or the right. Then with an analyser Polariser we find out (angel) whether the light has turned to the right or the left & (beer) how many degrees. The result thus expressed in Degress is Optical Rotation. From this other results like Specific Optical Rotation, Deg Z, Deg ISS are calculated. Rudolph manufactures various models of Digital Polarimeters depending on the no of wavelengths, accuracy, resolution, capability to maintain the temperature of the sample through Peltier, ability to withstand acidic samples, adherence to 21 CFR Part 11 etc.. While the Autopol I is the entry-level model the Autopol VI is for cutting edge of Research. Rudolph is the only company offering NVLAP certified NIST traceable QCPs. These are available in different kinds for Positive rotation, Negative rotation, Low rotation and so on. Autopol is the single largest selling Polarimeter in the brand and all the models have the following features: Microprocessor controlled with touch-sensitive keypad and colour display It displays Optical Rotation, Specific Rotation, Deg Z & Deg ISS The "TempTrol" models are capable of maintaining temperature through electronic heating and cooling Peltier technology. It can take sample cells of upto 200mm path length The Data storage is through 8GB non-removable Compact Flash USB Ports, RS232 & Ethernet ports are built-in

Technical Specification The overall improvement in its optical design ensures permanent and undisturbed focus. Highly accurate glass scale is divided to read angular degrees and also carries sugar scale in I.S.S. units. The angular scale from 0 to 360 degree is sub divided to 1 degree to enable direct reading to 0.05 degree and by estimation to 0.02 degree. The sugar scale from 30 degree to 120 degrees I.S.S. unit enable direct reading to 0.1 and by estimation to 0.05 sugar degrees. Supplied complete with polarimeter tube. Pipe fitting with sodium vapour lamp, holder and leak proof transformer are supplied as a standard accessory. Tube Size 220 mm with Rotating Half Shadow. Tube Size 400 mm with Rotating Half Shadow

Suitable For Education & Training in Physics, Chemistry, Pharmacy Institutions to find out relation between specific rotation and concentration per cm or per mm thick / path of various solutions. Standard Specifications Workable tube length : 200mm Shade system : Bi-quartz device which is workable on both Sodium light and ordinary light source. Measuring Scale : 0º to 360º Circular scale divided in single degrees, every 10th line numbered and every 5th line extended. Vernier reading : 1/10º = 6 minutes Stand : Heavy CI casted stand adjustable in height Standard Accessories One 200 tube, Dust cover, Instruction manual, thick cardboard box packing   Spare AccessoriesPolarimeter Tubes Polarimeter tubes made from Borosilicate Glass with bulb in center, packed in velvet case. (A) 100mm (B) 200mm(B) 400mm

We are offering Polarimeter 1280. for the Measurement of Angle of Rotation of Optically Active Substance in Solution I.e. Angle Through Which the Plane of Polarised Light is Rotated On Passing Through a Specified Length of Solution of Known Concentration. Specific Rotation May Then Be Determined. the Circular Head is Attached Near the Analyser and Vernier Movement On the Scale Enables the Reading of Optical Rotation Accurate Up-to the Accuracy of 0.10. Soleil's Bi-quartz Laurents Half Shade Device Which Makes the Instrument Accurate and Simple for Use with White Light (day Light) or Sodium Light. the Polarimeter Tubes Made from Borosilicate Glass with Fittings At Both Ends. the Tube End Covers with Glass Round Disc, Optically True with Rubber Washers to Make It Leakproof. Complete with a Set of Two Polarimeter Tubes (100mm and 200mm) in Wooden Case, Nicely Polished.
