Process Calibrator Dealers

FEATURES:4-20mA (1KΩ load, 24V Loop Supply)0-100.00mV, 0-1.000V, 0-12.000VK, J, E, T Thermocouple (° C and ° F)Frequency 1-62500 Hz0.025% Basic AccuracyEasy Keypad OperationEasy Step and Auto Ramp Functions0-20mA, 0-24mA selectable0-100% Input (mA, mV, V)Beeper warning when output is open (mA) or short (mV, V)

We are offering universal multifunction process calibrator. Universal multifunction calibrators are used for the simultaneaous simulation and measuring of programmable test points. thermometers, signals for thermocouple, rtd's, resistance, ma, mv, voltage, frequency is available in this multifunction calibrator.

19 FUNCTIONS 59 RANGESKM-CAL-905MULTIFUNCTION PROCESS CALIBRATOR ACCESSORIES :Test leads, Fuse, User’s Manual, Carrying Case. OPTIONAL ACCESSORIES :Pressure modules SKU: KMCAL905Category: CalibratorsTags: calibration instruments, instrument calibrator, km cal 905,Kusam meco calibrators, MULTIFUNCTION PROCESS CALIBRATOR

Fluke 754 Documenting Process Calibrator-HART You’re going to love what we’ve done with your calibrator. The 754 is everything you needed and wished for in the 744 and more! HART communication capability is combined to deliver an integrated communicating calibrator. This rugged, reliable tool is ideal for calibrating, maintaining, and troubleshooting HART and other instrumentation. The 754 does the work of several tools - sourcing, simulating and measuring pressure, temperature, and electrical signals in one rugged, hand-held device. You’ll fall in love with the new improved graphical screen, Li-on battery for longer life, USB port and new accessories to complete the package.  For documentation, the 754 automates calibration procedures and captures your data. And, of course, it helps you meet rigorous standards like ISO 9000, FDA, EPA and OSHA regulations. Supports popular instrumentation management software. The 753 and 754, 743 and 744 work with the Fluke DPC/TRACK2™ software, and with popular programs from Honeywell Meridium, Emerson, Cornerstone, Yokogawa, Prime Technologies, Intergraph and others. It allows you to create procedures, instructions, and action lists to deliver fast, easy documentation. The Fluke 754 Documenting Process Calibrator-HART: Work smarter. Work faster.   The 753 and 754, 743 and 744 work with the Fluke software, and with popular programs from Honeywell Meridium, Emerson, Cornerstone, Yokogawa, Prime Technologies, Intergraph and others. It allows you to create procedures, instructions, and action lists to deliver fast, easy documentation. FEATURES   Measure volts, mA, RTDs, thermocouples, frequency, and ohms to test sensors, transmitters and other instruments   Source/simulate volts, mA, thermocouples, RTDs, frequency, ohms, and pressure to calibrate transmitters   Power transmitters during test using loop supply with simultaneous mA measurement   Measure/source pressure using any of 29 Fluke 700Pxx Pressure Modules   Create and run automated as-found/as-left procedures to satisfy quality programs or regulations. Record and document results   Holds up to a full week of downloaded procedures and calibration results.   Use many features like autostep, custom units, user entered values during test, one-point and two-point switch testing, square root DP flow testing, programmable measurement delay etc.   Easy to use   Three year warranty   Bright white dual display. Read both sourced and measured parameters simultaneously.   Multi lingual interface   Rechargeable Li-Ion battery for 10 hour uninterrupted use. Includes gas gauge.   Handling of fast pulsed RTD transmitters and PLCs, with pulses as short as 1 ms.   Delivered with DPC/Track Sample software.   Compatible with many Asset Management software packages. HART Capabilities The 754 is designed to take on nearly all the day-to-day tasks you now perform with a separate communicator. In fact, it offers the communication capabilities of the 375 HART communicator.   Requires no external box or second tool for everyday HART calibration and maintenance.   Offers fast HART communication.   Supports popular models of HART transmitters, with more devise-specific command support than any other HART field calibrator.   Works with multiple masters, burst mode, and multi-drop configurations.   Is easy to update as additional instruments are added and new HART versions are released.   Interrogate to determine device type, manufacturer, model, tag.   Reconfigure the sensor mapping of dual sensor temperature transmitters.   Read HART PV function and smart transmitter digital output while measuring analog mA output.   Read and write HART configuration functions to make field adjustments to PV range points, damping, and other top-level configuration settings.   Re-label smart transmitters by reading and writing to the HART tag field.

Universal Process Calibrator    BTH, Universal Process Calibrator C9 is a very useful tool to calibrate many types of process control instruments which accept mV, mA and resistance inputs. This is designed to give highest stability and accuracy. The calibrator has a source & measure function & can be used for lab or field calibration of process control instruments, temperature & pressure transmitters, I/P convertors, field level transmitters, flow transmitters and a host of other instruments.     Technical Description:           Direct TC , mA & RTD output           Source & Measure Function           Back Light LCD           Direct Calibration possible           Automatic Power on/off function.           DC current .001mA resolution.           Power supply:6V batteries (4 no’s of 1.5 V)   Salient Features:   Direct TC & RTD Output, DC Current .001 mA Resolution,  Back Light L.C.D., Relative Range Selection 25% to 100% , Loop Power, Direct Calibration Possible, Automatic Power On/Off.

Mastech MS7282 Multi-Function Process Calibrator     Mastech MS7282 professional multi-function process calibrator multimeter, this series of process calibrator multimeter is designed with exact current, voltage calibrator function and digital multimeter function, it is used for detecting and debugging automatic control equipment in industry scene.

The Beamex MC4 is a documenting process calibrator. Instrument data can be sent from a computer to the MC4 and calibration results can be uploaded from the MC4 to a computer containing the Beamex CMX calibration software. Being a multifunctional calibrator, the MC4 is suitable for calibrating various process parameters, such as pressure, temperature and electrical signals. High accuracy is one of the important features of the MC4. A standard feature of the MC4 includes an accredited calibration certificate as proof of its accuracy. The correction coefficients of a PRT probe can be programmed into the MC4 to further improve temperature accuracy. The large graphical display, menu based multilingual user interface and full numerical keyboard Features Pressure Section Internal pressure module Connection for interchangeable external pressure modules Electrical Section Current measurement (with internal and external supply) Voltage measurement Frequency measurement Pulse counting Current generation (with internal and external supply) Voltage generation Frequency generation Pulse generation Switch sensing Internal HART® compatible 24 VDC loop supply mV measurement simulation Resistance measurement simulation RTD measurement simulation

4 - 20mA (1KΩ Load, 24V Loop Supply) with1mA Resolution 0 -100.00mV, 0-1.0000V, 0-12.000V K, J, E & T Thermocouples (°C and °F) Frequency : 1-62500 Hz DC Current Basic Accuracy : 0.025% Easy Key Pad Number Operation Easy Step and Auto Ramp Functions 0-20mA & 0-24mA Selectable 0-100% Output (mA, mV, V) Beeper Warning when Output is Open (mA) or Short (mV,V )

The company is well-known for the provision of high quality Process Calibrators. The range of Process Calibrators made available by us is manufactured using high quality materials and is hence, low on maintenance. We offer Process Calibrators at the best prices in the market. Our range of Process Calibrators is appreciated for its excellent finishing, easy maintenance and longer life. Features : Improved display resolution for current : The generation/measurement resolution has improved to 0.001 mA 24 V (20 mA)/Loop check function : Enables measurement of generated current signals while supplying loop power to two-wire transmitter. Load current: Max. DC22 A 20 mA SINK Function : Absorbs the voltage supplied from an external power supply to its H terminal and simulates a two-wire transmitter making it ideal for loop checks 4-20 mA and 1-5 V DC Step-up/down Function : The output level can be changed between 4-8-12-16-20 mA signals by one touch for the 4-20 mA DC output, and between 1-2-3-4-5V signals for the 1-5 V DC output, for efficient calibration work Sweep Function : Increases and decreases the output level to the preset level at a constant rate for the selected sweep time (16 or 32 seconds). The sweep function and sweep time are set by the internal dip switches Source and Measuring of Voltage and Current : Generates and measures voltages up to 30 V DC and currents up to 24 mA DC Options : CA11E-2 Includes rubber boot, strap and accessory case

FEATURES High Accuracy of 0.02% for source 6 digits display for source A dual Liquid Crystal Display White LED for backlight Temperature Coefficient: 0.1 times the applicable accuracy,specification per degree C for 5 to 18 and 28 to 50 The range of the internal temperature compensation sensor is from 0 to 40, Compensation error ≤±0.5 The accuracy of the temperature probe: ±0.2 The range of the measured temperature is form -20-100 Maximum voltage between any output terminal and earth: 30Vp-p Maximum output current: Approximately 25mA APPLICATIONS All technicians responsible for installing, commissioning, calibrating and maintaining process industry transmitters, RTD, thermocouple including Instrument and Electric Shop Technicians, Instrument and Control Shop Technicians, Maintenance Technicians.

Universal Multifunction Calibrators are used for the simultaneaous simulation and measuring of programmable test points. Thermometers, Signals for thermocouple, RTD's, Resistance, mA, mV, Voltage, Frequency is available in this Multifunction Calibrator.

We manufacture and supply Multifunction Process Calibrators. These handheld devices are battery operated and ideally designed for measurement of electrical and physical parameters. It is an all-in-one instrument that can serve as multimeter, thermocouple, and can also be used to measure volts, current, pressure, frequency, etc. It features a wide display screen that clearly shows all the readings. Rugged and compact body makes it perfect for demanding conditions.
