Saybolt Viscometer Dealers (27 products available)

• Country of Origin: India
• Type: Saybolt
• Certification: CE Certified
• Color: Grey
• Voltage: 220V
• Warranty: 1 Year
• Application: Viscosity Measuring

We are one of the well reckoned Saybolt Viscometer manufacturer and supplier based in Ambala Cant, Haryana. We manufacture and provide world class Saybolt Viscometer that is made from high grae stainless steel. Used For :-For determining the Viscosity of fuel oil and lubricating oil both thin & thick Package Includes :- Stainless steel bath with oil cupBath lidWater cooling tubeTwo handle with two stirrer bladesThermometer socketStraight heater Power Consumption :- Operates on 220 Volts AC mains Optional Accessories :- IMC-567 Saybolt Viscometer gas heated(without burner)IMC-568 Saybolt Viscometer electric heated without controlIMC-569 Saybolt Viscometer electric heated with separate energy regulator.IMC-570 Saybolt Viscometer electric heated with solid state electronic control (Voltage varric).IMC-570C Same as above with copper coil tupe voltage varric.IMC-570D Same as above with digital temperature controller cum indicator.IMC-570A Two Saybolt tubes Viscometer electric heated with double walled with control.IMC-570B Same as above with 4 Saybolt tubes.

• Condition: New
• Power Source: Electric
• Usage: Household, industrial, Laboratory
• Material: Steel
• Finish: Polished

SAYBOLT VISCOMETER(ASTM-D-88.) Used for determining the Viscosity of fuel oil and lubricating oil both thin & thick. The apparatus consists of Stainless Steel bath with oil cup which is centrally placed in a water bath. The bath has a lid which contains a water cooling tube, two handle with two stirrer blades, thermometer socket and a straight heater, stirring is done by turntable arrangement. A thermometer can also be inserted into the cup cover. The jets one universal and one Furol can be screwed to the cup by a handle(without strainer, withdrawal tube and glasswares). can operate on 220 Volts AC mains. about Optional Accessories: 567 Saybolt Viscometer gas heated(without burner) 568 Saybolt Viscometer electric heated without control 569 Saybolt Viscometer electric heated with separate energy regulator. 570 Saybolt Viscometer electric heated with solid state electronic control (Voltage varric). 570C Same as above with copper coil tupe voltage varric. 570D Same as above with digital temperature controller cum indicator. 570A Two Saybolt tubes Viscometer electric heated with double walled with control. 570B Same as above with 4 Saybolt tubes.

• Voltage: 220V
• Application: Laboratory
• Brand Name: Steco
• Frequency: 50 Hz
• Material: Steel
• Power Source: Electric
• Phase: Single Phase
• Weight: 65 Kg (Approx)

We are engaged in manufacturing, supplying and exporting a very high quality Saybolt Viscometer, which is electrically heated. The Saybolt Viscometer provided by us has ASTM D88, D244, and AASHTO T72 for the empirical measurement of Say bolt Viscosity of petroleum products. We provide Saybolt Viscometer for measurement at specified temperatures between 70oF and 210oF. Our range of Saybolt Viscometer is highly economical to use. Highlights : Economical operation Easy installation High productivity Low maintenance

saybolt viscosity of petroleum products at specified temperatures between 70of and 210 f. This is also used for determining the saybolt furol viscosity of bituminous materials at temperatures of 250, 275, 300, 350, 400 and 450°f. It comprises one each of cylindrical oil cup, universal tip, furol tip, bath fitted with immersion heater mounted on a stand, dimmerstat for temperature control, stirrer with shield. Apparatus is supplied complete with insulated handle and thermometer support, receiving flask, withdrawal tube, filter funnel, thermometer support for cup and circular spirit level.   application for the empirical measurement of saybolt viscosity of petroleum products industry civil infrastructure asphalt / petroleum/ bitumen testing dams & tunnels real estate roads, highways & bridges traffic monitoring education building technology civil department geotechnical science colleges traffic & transportation roads, highways & bridges

We deal in Saybolt Viscometer. It operates with an electrically heated, ASTM D 88, D244, AASHTO T 72, used for the empirical measurement of Saybolt Viscosity of petroleum products at specified temperature ranging from 70oF and 210oF. Saybolt Viscometer is of utmost significance for determining the Saybolt Furol viscosity of bituminous materials at temperature of 250, 275, 300, 350, 400 and 450oF. Saybolt Viscometer is most suitable for operation on 220 V. 50 Hz, single phase. Components One each Cylindrical Oil Cup, Universal Tip, Furol Tip, Bath Fitted with immersion heater mounted on a stand. Dimmer stat for temperature control, Stirrer with shield. An insulated handle and thermometer support, receiving flask, withdrawal tube, filter funnel, thermometer support for cup and circular spirit level. Additional Components On Special Demand Brass oil tubeReceiving Flask, 60mlUniversal and flurol tup (set of 2)Filter FunnelThermometer SupportHeating CoilASTM Thermometer Type 17F, Range : 66oF to 80oFASTM Thermometer Type 18F, Range : 94oF to 80oFASTM Thermometer Type 19F, Range : 120oF to 134oFASTM Thermometer Type 20F, Range : 134oF to 148oFASTM Thermometer Type 21F, Range : 174oF to 188oFASTM Thermometer Type 22F, Range : 204oF to 218oFASTM Thermometer Type 77F, Range : 245oF to 265oFASTM Thermometer Type 78F, Range : 295oF to 315oFASTM Thermometer Type 79F, Range : 345oF to 365oFASTM Thermometer Type 80F, Range : 395oF to 415oFASTM Thermometer Type 81F, Range : 445oF to 4650oF

Suitable for operation on 220 V, 50 Hz, Single Phase, AC Supply.   Suitable for operation on 220 V, 50 Hz, Single Phase, AC Supply.      Optional Extras   a Brass oil tube   b Receiving Flask, 60ml   c Universal and flurol tip (set of 2)   d Filter Funnel   e Thermometer Support   f Heating Coil   g ASTM Thermometer Type 17F Range: 66° F to 80° F   h ASTM Thermometer Type 18F Range: 94° F to 108° F   i ASTM Thermometer Type 19F Range: 120° F to 134° F   j ASTM Thermometer Type 20F Range: 134° F to 148° F   k ASTM Thermometer Type 21F Range: 174° F to 188° F   l ASTM Thermometer Type 22F Range: 204° F to 218° F   m ASTM Thermometer Type 77F Range: 245° F to 265° F   n ASTM Thermometer Type 78F Range: 295° F to 315° F   o ASTM Thermometer Type 79F Range: 345° F to 364° F   p ASTM Thermometer Type 80F Range: 395° F to 415° F   q ASTM Thermometer Type 81F Range: 445° F to 465° F

Used for determining the Viscosity of fuel oil and lubricating oil both thin & thick. The apparatus consists of Stainless Steel bath with oil cup which is centrally placed in a water bath. The bath has a lid which contains a water cooling tube, two handle with two stirrer blades, thermometer socket and a straight heater, stirring is done by turntable arrangement. A thermometer can also be inserted into the cup cover. The jets one universal and one Furol can be screwed to the cup by a handle(without strainer, withdrawal tube and glasswares). can operate on 220 Volts AC mains

• Brand Name: Rajdhani
• Viscosity(cP) Range: 1 to 100,000 cp
• Model: RSPT-25
• Controller Type: On/Off Control
• nput Sensor: Thermocouple

Product Code: EKE 529Standrad: ASTMD 88, D 244, AASHTO T 72 EKE 52901 Brass oil tubeEKE 52902 Receiving Flask, 60 mlEKE 52903 Universal and flurol tip (set of 2)EKE 52904 Filter FunnelEKE 52905 Thermometer SupportEKE 52906 Heating coilEKE 52910 ASTM Thermometer Type 17F, Range: 66º F to 80ºFEKE 52911 ASTM Thermometer Type 18F, Range: 94º F to 108º FEKE 52912 ASTM Thermometer Type 19F, Range: 120º F to 134º FEKE 52913 ASTM Thermometer Type 20F, Range: 134º F to 148º FEKE 52914 ASTM Thermometer Type 21F, Range: 174º F to 188º FEKE 52915 ASTM Thermometer Type 22F, Range: 204º F to 218º FEKE 52916 ASTM Thermometer Type 77F, Range: 245º F to 265º FEKE 52917 ASTM Thermometer Type 78F, Range: 295º F to 315º FEKE 52918 ASTM Thermometer Type 79F, Range: 345º F to 365º FEKE 52919 ASTM Thermometer Type 80F, Range: 395º F to 415º FEKE 52920 ASTM Thermometer Type 81F, Range: 445º F to 465º F   For the empirical measurement of Saybolt Viscosity of petroleum products at specified temperatures between 70º F and 210º F. This is also used for determining the Saybolt Furol viscosity of bituminous materials at temperatures of 250, 275, 300, 350, 400 and 450ºF. It comprises one each of Cylindrical Oil Cup, Universal Tip, Furol Tip, Bath fitted with immersion heater mounted on a stand, Dimmerstat for temperature control, Stirrer with shield. Complete with insulated handle and thermometer support, receiving flask, withdrawal tube, filter funnel, thermometer support for cup and circular spirit level. Suitable for operation on, 220 V, 50 Hz, Single Phase, AC Supply.

Used for determining the viscosity of petroleum products and lubricants. Viscosity is measured by determining the time taken by 60 cc of the material to flow through a specified orifice. The apparatus consists of stainless steel bath with oil cup which is centrally placed in awater bath. The bath has a lid which contains a water cooling tube, two handles with two stirring blades, thermometer socket and a straight heater. Stirring is done by turntable arrangement. A thermometer can also be inserted into the cup cover. Two jets one universal and one furol can be screwed to the cup by a handle (without strainer, withdrawal tube and glassware) The temperature is controlled by energy regulator or voltage varrier.(extra cost) Suitable to work on 220V,50 Hz, AC single phase.. The following accessories and consumables are not part of the standard supply and are mandatory for the testing work. Strainer for Filtering Oil. Withdrawal tube. Say bolt Viscosity Flask 60 cc. Glass Thermometer ASTM 17C/18C/19C/20C/21C/22C. CommonRangeThermometer 0-1000C. Universal Orifice. Furol Orifice.  The Say bolt Viscometer is also available for multiple test – fitted with Digital Temperature indicator cum controller and FHP electric stirrer. Complete with two Say bolt tubes and electrical control panel with accessories.

• Standard: ASTM D-88, E-102
• Model: VSLIC-B119
• Origin: Indian

For determining the hardness number of Mastic Asphalt for flooring. It consist of an internally insulated cabinet to the base of which is fitted a water bath having two taps. The bath is heated by an immersion heater and the temperature is controlled with the thermostat at 35° +/- 0.5° C. A 6.5mm dia pin is loaded on the specimen by means of a lever to give a 31.7 Kg weight. A dial gauge 0.01 x 25 mm is provided to record the penetration of pin into the specimen.

We are offering Saybolt Viscometer. as per astm d 88, suitable for determining the viscosity of fuel oil and lubricating oil- both thin & thick. complete with universal & furol jets made of 18/ 8 stainless steel , saybolt flask. stirring is done by hand with turn table arrangements

compacting factor apparatus, Ultrasonic Pulse Velocity Tester

Used for determining the Viscosity of fuel oil and lubricating oil both thin & thick. The apparatus consists of Stainless Steel bath with oil cup which is centrally placed in a water bath. The bath has a lid which contains a water cooling tube, two handle with two stirrer blades, thermometer socket and a straight heater, stirring is done by turntable arrangement. A thermometer can also be inserted into the cup cover. The jets one universal and one Furol can be screwed to the cup by a handle(without strainer, withdrawal tube and glasswares). can operate on 220 Volts AC mains.
