Pneumatic Wire Spooling Machine
260,000 Per Piece
1 Piece (MOQ)
Country of Origin : India
Automation Grade : Semi-Automatic
Types Of Metal : Copper, Aluminium
Voltage : 415V
Brand Name : Shiv
Condition : New
Power Consumption : 10 HP
Warranty : 1 Year
Capacity : 300 kg/hr
Frequency : 10 Hz
Power Source : Pneumatic
Finish : Color Coated
Orientation : Horizontal
Phase : Three Phase
spooling machine
Type : Vertical / Horizontal
Configuration : Coil to Bobbin / Bobbin to Bobbin
Bobbin Loading : Automatic / Manual
Bobbin Size : 400 mm – 700 mm
Brake : Pneumatic
Structure : Machined Heavy Duty Spooler
HMI + PLC : Available for easy line speed setting
Best Deals from Spooling Machine
spooling machine
We make use of user-friendly interface that enables us to network and control the sorting, loading and unloading of all the finished products from a single location. By this, we make sure that the voluminous consignments are kept safely till the final send off. We have hired only professional packaging personnel who have experience and expertise in this domain. They make use of the finest quality packing material to ensure zero damage during transit.Some features are : Durable Low maintenance Sturdy construction Resistance against corrosion
spooler machine
800,000 Per Piece
For making sure about the safety of the products during handling, transporting and warehousing, we make use of quality packaging material. And, this task is accomplished by our deft professionals. We make use of premium material for packaging the offered lot so as to ensure safe side deliveries. Features : Effective usage Low maintenance Resistance against corrosion
Pintal Type Wire Spooling Machine
As we take complete care of the products that we offer, we make excellent arrangements for their storage as well. Thus, there are minimal chances of damage at buyer's end. Buyers are free to place bulk as well as urgent orders with us and we ensure timely delivery of the same.
Wire Spooling Machine
Condition : New
Application : Industrial Use
Type : Vertical / Horizontal
Configuration : Coil to Bobbin / Bobbin to Bobbin
Bobbin Loading : Automatic / Manual
Bobbin Size : 400 mm – 700 mm
Brake : Pneumatic
Structure : Machined Heavy Duty Spooler
HMI + PLC : Available for easy line speed setting
Wire Spooler Machine
Placed in New Delhi(India), ours is an emerging company serving the clients with broad range of products. In order to ensure zero defects to the products, we have installed automated warehousing system in our spacious warehouse. The system is supervised by well-trained personnel only.Features : Precise dimensions Sturdy construction Excellent performance Approx Price : Rs 65 Lakh / Unit(s)
Fully Automatic Vertical Wire Spooling Machine up to 2 Ton Capacity
Condition : New
Application : Industrial Use
Configuration : Coil to Bobbin / Bobbin to Bobbin
Bobbin Loading : Automatic / Manual
Bobbin Size : 400 mm – 700 mm
Capacity : 1000Kg/per 8 Hours
Wire Size : 0.50 / 1.60 mm
With the help of our skillful professionals, we have come out as a proficient manufacturer and supplier of Fully Automatic Vertical Wire Spooling Machine up to 2 Ton Capacity from Indore, Madhya Pradesh, India. The unmatched features and fine quality along with durability have made our Fully Automatic Vertical Wire Spooling Machine up to 2 Ton Capacity the preferred choice among buyers.This machine is widely used for various purposes.Owing to our brilliant logistics network we are capable of delivering bulk orders of the product within the stipulated time.
spooling machine
Various models are available to suit customer requirement. :
Bobbin Flange Diameter : 100 mm to 1200 mm
Maximum filled weight of Bobbin : 1200 Kg
Spool holding options : Pintle type between head stock and tail stock / Cantilever shaft type with Pintle and lock nut
Tail Stock pintle movement options : Pneumatically operated / Screw type with handle
Traversing system : Rollring traverse system. Traverse pitch and stroke can be finely adjusted for compact winding.
Drive to traverse shaft is from the head stock to ensure automatic speed synchronization. :
Machine Construction : Fabricated construction with Head stock, Tail Stock, Traverse assembly and Motor mounted on common bed
Brake types : Pneumatic Disc brake / Electromagnetic brake
Drive types : AC motor with variable frequency drive / Torque motor
Tension Control : Automatic tension control maintaining line speed and winding tension constant through out winding. AC motor with variable frequency drive or Torque motor with voltage control.
Electronic length counter provided :
Wire Spooler Machine
Traverse Unit : Rolling Type Model HT - 4 Shaft Dia - 40 mm
Braking : Pneumatic Disc Brake
Capacity : 100 / 1000 kg.
Bobbin Fitted : Bobbin Clamp between Pintails with Pneumatic Cylinder
Pintle Movement : Pneumatic Cylinder Operated
Wire Size : 0.50 / 1.60 mm
Loading / Unloading : Manual
Guard : Provided
Electric Motor Required : 15 HP - 1 No. 1440 [Each Spooler] (A.C. Frequency Drive)
spooling machine
105,000 Per Units
1 Units (MOQ)
Automation Grade : Semi-Automatic
Voltage : 440V
Pay Mode Terms : T/T (Bank Transfer)
Power Consumption : 1.5HP
Capacity : 300 Kg/8Hours
Machine Type : Automatic
Power Source : Electric
spooling machine
We have designed Spooling Machine while keeping in mind emerging demands of metal wire making industry. Innovative concepts and remarkable performance are the characteristics that have trumped up popularity of Spooling Machine. We have made Spooling Machine in different specifications to meet divergent demands of the clients. Highlights : Longer service life Smooth operations Low noise Efficient performance
spooling machines
Vertical and horizontal Spooling Machines and a comprehensive range of coil winding machines that are used for layer winding of solenoids and bobbins. The range includes different types of machines having diversified specifications for winding speed, layer length, layer height, winding tension, pitch setting, coil weight etc. Collapsible bobbins for wire This bobbin is used to aid the coiling and packing of wire and strand. After winding the bobbin is dismantled for removal of the coil and packing. The bobbin is then easily reassembled with bolts to be reused. Removable parts allow for use with coils of varying width.B.B Block spooler Our organization specializes in offering a compact range of BB Block that is fabricated with calliper type pneumatically operated disc that helps to stop the machine once the breakage occurs. Qualified team members make sure to use qualitative raw material that is obtained from the credited vendors of the market. In addition to this, these blocks are available with us in diverse customized options as per their needs and demands.Some features are: Effective usage Low maintenance Resistance against corrosion Easy to install
Automatic Wire Spooling Machine
280,000 Per Piece
Application : Wire Spooling
Automation Grade : Automatic
Warranty : 1 Year
Voltage : 220V
Weight : 100kg
Capacity : 2 ton
Material : Mild Steel
spooler machine
Model No . : Capacity
No of wire : 50 kg To 200 Kg.
Wire Diameter Range(mm) : 201 Kg To 500 Kg.
we design and develop spooler machines that have been widely recognized for their faultless operations and energy efficiency. These precision engineered spooler machines are based on advanced technology and correct the damaged telescoped or rewound rolls with optimum speed. This facility helps in reducing the rate of rejection.
Pneumatic Wire Spooling Machines
290,000 Per Piece
2 Piece (MOQ)
Automation Grade : Semi-Automatic
Power : 10kW
Usage/Application : For Wires & Cables Making Industries
Body Material : Wire Spooler
Machine Weight : 1 Ton
Surface : Paint Coated
Wire Spooling Machine
Our organization is engaged in offering an extensive range of Wire Spooling Machine, which is designed as per DIN standards. It is available in various specifications ranging from 100 mm to 1100 mm bobbins and has weight from 10 kgs. to 100 kgs. Furthermore, our range is to be attached with various wire drawing machine or individual spooling use.
Wire Spooling Machine
Our organization is engaged in offering an extensive range of Wire Spooling Machine, which is designed as per DIN standards. It is available in various specifications ranging from 100 mm to 1100 mm bobbins and has weight from 10 kgs. to 100 kgs.
Vertical and horizontal Spooling Machines
Vertical and horizontal Spooling MachinesVertical and horizontal Spooling Machines and a comprehensive range of coil winding machines that are used for layer winding of solenoids and bobbins. The range includes different types of machines having diversified specifications for winding speed, layer length, layer height, winding tension, pitch setting, coil weight etc. Collapsible bobbins for wire This bobbin is used to aid the coiling and packing of wire and strand. After winding the bobbin is dismantled for removal of the coil and packing. The bobbin is then easily reassembled with bolts to be reused. Removable parts allow for use with coils of varying width.B.B Block spooler Our organization specializes in offering a compact range of BB Block that is fabricated with calliper type pneumatically operated disc that helps to stop the machine once the breakage occurs. Qualified team members make sure to use qualitative raw material that is obtained from the credited vendors of the market. In addition to this, these blocks are available with us in diverse customized options as per their needs and demands.Some features are: Effective usage Low maintenance Resistance against corrosion Easy to install
Spoolers
Spoolers work in combination with wire drawing machines and are used to take up drawn wires on to rigid or collapsible machine spools according to DIN or customer standards. We offer a comprehensive series of spoolers, in several sizes for various spools and wire ranges. The spool is taken up between two pintles, one is pneumatically operated.( Cantilever arrangement is provided for small spools ) A pneumatic lifting-device with the functions lift, lower is used for the loading and unloading of the spools. This allows a quick and troublefree exchange of spools. Speed control - depending on the wire diameter - is either torque controlled or by means of a dancer unit which is installed between the drawing machine and the spooler. All spooler functions are actuated from an operating console. Machine Features • For low, medium, high carbon or stainless steel wire• Horizontal or vertical spool axis version• Pneumatic pintles with safety locking device• Motorized traverse (optional)• Manual or pneumatic wire clamps• Emergency stop with pneumatic brake• Safety guards• Easy access for maintenance purposes
spooler machine
We are offering spooler machine. The final winding of wire is done on the spooler. This machine equipped with travers motion device with separate ac variable drive to wind wire precisely. Its main motor is also equipped with ac variable drive to synchronies the winding pattern. This machine is also equipped with length counter to reach exact wire length and stop the machine. The spool is provided with pneumatic operated tail stock to clamp the spool and it's also reduces the loading -unloading time for operator. Pneumatic cylinder is also provided to hold the wire during reloading operation of spool. The machine is provided with 9+9 vertical and horizontal killing rollers to set the better cast and helix.
wire spooling machines
We are offering Spooling machine with constant tension motor for wire sizes upto 5 mm and speeds upto 8 ms for ferrous and non-ferrous wires.
spooler machine
60,000 - 175,000 Per Unit
