Thickness Meter Dealers

We are offering coating thickness meter.general information the ctg-01 coating thickness gauges work either on the magnetic induction principle or on the eddy current principle, depending on the type of probe used. you can select the type of probe via menu system, or it will work automatically. the gauges conform to the following industrial standards: gb/t 4956-1985 gb/t 4957-1985 jb-t 8393-1996 jjg 889-95 jjg 818-93 features • measured coatings: non-magnetic coatings(e.g. Paint, zinc) on steel; insulating coatings (e.g. Paint, anodizing coatings) no non –ferrous metals. • operating with menu easily. • two measuring mode: continue and single mode. • two working mode: direct and group mode (4 groups) • statistic display: avg, max, min, no.,s.dev • one point calibrating and two points calibrating independently for each working mode • zero calibrating easily • memory for 320 readings (80 for each group ) • delete single readings and all group readings easily • high alarm and low alarm for all working mode • low battery, error indication • usb interface for pc analysis software • disable auto-power-off function via menu setting. description of the gauge for measurement on steel substrates, the gauge works on the magnetic induction principle, for measurement on non-ferrous metal substrates; it works on the eddy current principle. measurement values and user information are shown on lcd; a display back ensures easy reading of screen date in dark conditions two different operating modes are available: direct mode and group mode. direct mode is recommended for simple, quick, occasional measurements. It provides statistical analysis. Single values are not saved. The statistical analysis program can evaluate 80 readings. groupe mode permits measurement and storage of readings in a free programmable memory. A maximum of 400 readings and 4 series of measurements can be analyzed according to various statistical criteria. standard accessories gauge with two 1.5v battery, plastics carrying case, operating instructions (english), steel and aluminum substrate. usb connecting cable program disc for windows 98/2000/xp/vista/7 probe the probe systems are spring-mounted in the probe sleeve. This ensures safe and stable positioning of the probe and constant contact pressure. A v-groove in the sleeve of the probes facilitates reliable readings on small cylindrical parts. The hemispherical tip of the probe is made of hard and durable material.

A Coating Thickness Gauge (also referred to as a Paint Meter) is used to measure Dry film thickness. Dry film thickness is probably the most critical measurement in the coatings industry because of its impact on the coating process, quality and cost. Dry film thickness measurements can be used to evaluate a coating’s expected life, the product’s appearance and performance, and ensure compliance with a host of International Standards.

We are offering coating thickness meter. Features: non-magnetic coatings (e.g. Paint, zinc) on steel insulating coatings (e.g. Paint) on no-ferrous metals no-ferrous metals coatings on insulating substrates menu operation system two measuring mode: continue and single mode two working mode:direct and group mode statistic display: avg, max, min, no., s.dev one point calibrating, two points calibrating and basic calibrating easily memory for 400 readings(80 direct and 320 group readings) delete single readings and all group readings easily high alarm and low alarm for all working mode low battery, error indication usb interface for pc software (windows 982000xpvista) specifications: sensor probe f n working principle- magnetic induction eddy current principle measuring range- 0~1250um 0~1250um guaranteed tolerance (of reading) (+- 3%+1)um (+- 3%+1.5)um low range precision 0.1um 0.1um minimum curvature radius- 1.5mm 3mm diameter of minimum area- 3mm 5mm basic critical thickness 0.5mm 0.3mm size (hxwxd) 113.5mm x 54mm x 27mm weight 110g

we are offering coating thickness meter etc. general information the ctg-01 coating thickness gauges work either on the magnetic induction principle or on the eddy current principle, depending on the type of probe used. you can select the type of probe via menu system, or it will work automatically. the gauges conform to the following industrial standards: gbt 4956-1985 gbt 4957-1985 jb-t 8393-1996 jjg 889-95 jjg 818-93 features • measured coatings: non-magnetic coatings(e.g. paint, zinc) on steel; insulating coatings (e.g. paint, anodizing coatings) no non –ferrous metals. • operating with menu easily. • two measuring mode: continue and single mode. • two working mode: direct and group mode (4 groups) • statistic display: avg, max, min, no.,s.dev • one point calibrating and two points calibrating independently for each working mode • zero calibrating easily • memory for 320 readings (80 for each group ) • delete single readings and all group readings easily • high alarm and low alarm for all working mode • low battery, error indication • usb interface for pc analysis software • disable auto-power-off function via menu setting. description of the gauge for measurement on steel substrates, the gauge works on the magnetic induction principle, for measurement on non-ferrous metal substrates; it works on the eddy current principle. measurement values and user information are shown on lcd; a display back ensures easy reading of screen date in dark conditions two different operating modes are available: direct mode and group mode. direct mode is recommended for simple, quick, occasional measurements. it provides statistical analysis. single values are not saved. the statistical analysis program can evaluate 80 readings. groupe mode permits measurement and storage of readings in a free programmable memory. a maximum of 400 readings and 4 series of measurements can be analyzed according to various statistical criteria. standard accessories gauge with two 1.5v battery, plastics carrying case, operating instructions (english), steel and aluminum substrate. usb connecting cable program disc for windows 982000xpvista7 probe the probe systems are spring-mounted in the probe sleeve. this ensures safe and stable positioning of the probe and constant contact pressure. a v-groove in the sleeve of the probes facilitates reliable readings on small cylindrical parts. the hemispherical tip of the probe is made of hard and durable material.

Used for measuring thickness and corrosion of pressure vessels, chmical equipment,boiler, oil storage tanks.etc. In Industries of petroleum, Shipbuilding, Power Station, and machine manufacturing.

We are an established Importer, Exporter and Supplier of Powder Coating Thickness Meter from Gurgaon, Haryana, India. The Powder Coating Thickness Meters, we offer, give 100% accurate results and are widely acclaimed for their reliability and longer functional life. Buyers can obtain these Powder Coating Thickness Meters in medium as well as bulk orders; they are ready for prompt delivery. Besides, we quote nominal prices.

PM200T is applicable for the manufacturers of fluorescent lamp. During the procedure of powdering tube, PM200T solves the problem efficiently how to control the phosphor thickness and uniformly of the tube. It becomes the important tool to reach best lumen output and save the phosphor. • Measure the relative phosphor thickness • Filament lamp • Auto range switch • Low zero drift, high accurancy
