Vacuum Casting Machine Dealers (58 products available)

This is a standard floor model metal melting, investment mixing and vaccum casting machine. Some of the salient features of the machines are as under:- Sturdy low voltage melting unit with precise temp controller having max temp of 1200 degree C.- Vaccum suction : 760 mm Hg & 300 LPM- Buffer chamber for uniform air displacement- Mobile Chasis- Crucible Capacity 2.5 kgs- Air Pressure : 5 Bar

• Material: M.S. or S.S. Body.
• Type: Heavy Duty Vacuum Pump.
• Electrical: 230V;50Hz;1phase.
• Power: 2500Watts
• Melting: 1kg Gold 24crt.
• Temperature: 30ºC to 1180ºC.
• Vacuum: 325lpm
• Dimensions: 26”X23”X38” (LXWXH in Inches) approx
• Weight: 95kg. with pump.

The fully automatic casting machine vc 450 this machine is designed for: • casting of jewellery and other filigree parts • for permanent use • for certified production processes constructed on base of the vc 400, the vc 450 is equipped with a completely new generator and a program control system with full read out lcd display. With help of the step-by-step display information and many automatic functions the handling of the machine is very easy even for less experienced users. The program control for 25 different casting cycles allow reproducible and consistent casting results. new program control system : new control panel with full text lcd display, all programs & parameters are very easy & convenient to set. 100 casting programs guarantee fast operation and consistent casting results. Parameters are pre programmed for all major alloys, e.g. For ags, aplha plus, heraeus, legor, and pandora alloys. In practice this mean: from the first flask, you can expect good casting results without carrying out expensive pretests. the comfortable lcd display and control system: 20 casting programs allow for the individual setting of relevant process parameters before casting and their storage for recurrent castings – which is important for quality certified processes, high process reproducibility and for an economical production with fast casting cycles. Performance power max. electrical connection maximum temperature capacity crucible volume for use of flasks up to handling+control maximum pressure program control dual temperature control automatic flask & chamber lift turbulence reduction software. quality management rs232, diagnostic system, remote service data printer gsm modern accessories sinrering kit (for dissusion bonding) granulation tank

• Brand Name: Shakti Enterprise

We offer vaccum casting machine. 4’’ casting tank 8’’ deep the entire body/housing is manufactured by 304 ss. Material two tank system to provide high vacuum pressure for lesser porosity casting casting chamber with flask size 2" to 5" dia. Wide/up to 9" height capacity 100% shock proof metal melting furnace with digital temp. Control

Manual Pouring Vacuum Casting Machine With Furnace - 3 in 1  Manual Pouring Vacuum Casting Machine With Furnace - 3 in 1 with S. S. Chamber & Vibration System Available Capacity 1 Kg. & 2 Kg.

• Brand Name: GOLD TOOL

this is use for gold & silver casting .

Vaccum Casting 3 in 1 Machine: 3 in 1 Vaccum Casting Machine with Gold Melting and Debubbliser attachment in floor model design for ease of operation. This is a standard floor model gold metal melting, investment mixing and vaccum casting machine suitable for gold rings and gold jewelry casting. The machine is provided with Dual chamber for vaccum casting with twin dial gauge for excellent casting result. It is fitted with programmable digital controller for metal melting and is supplied complete with a 1.0 HP 220 volt single phase AC electric motor with vaccum pump. Standard accessories include Acrylic Bell jar, rubber sheet, crucible holder, 3 pieces crucibles, 3 pieces stainless steel adapter for different size, 25 pieces silicon rubber rings, 5 pieces various size Stainless Steel perforated flasks, 5 pieces rubber base for wax tree making, electric wax welder etc. It is a sturdy easy to use machine for years of trouble free service. Kindly ask for more details.

• Voltage: 230 V AC
• Highlights: Ideal for Investment, Melting & Casting- 3 application in a single device. Multi purpose use of investment chamber. Soft Power Triggering System. 350 Lpm vacuum pump. All Safety Precautions Provided.
• Power Supplier: Single Phase
• Absorbed Power: 3.5 KW
• Capacity of Crucible: 1 kg (24 Carat Gold)
• Maximum Temperature: 1200° C
• Melting Time: 10 minutes
• Temperature Measurement: Automatic
• Vacuum Capacity: 350 LPM

• Country of Origin: India
• Type: Vacuum Casting Machine
• Certification: ISO 9001:2008, CE Certified
• Condition: New
• Automatic Grade: Semi Automatic, Manual, Fully Automatic, Automatic
• Warrenty: 1year
• Voltage: 380V
• Brand Name: CEE DEE VACUUM

Our resin casting plant is manufactured using quality components and spare parts to ensure optimum performance and long functional life. Resin casting plant is integrated with mixing chamber, which is designed with heating system with temperature controlling arrangement.

• Type: Casting Machines
• Certification: ISO 9001:2008
• Weight: 100-500kg
• Color: Black
• Voltage: 440V
• Condition: New
• Automatic Grade: Automatic, Fully Automatic, Manual, Semi Automatic
• Power: 1-3kw, 3-5kw, 5-7kw
• Power Source: Elecric, Hydraulic, Penaumatic
• Country of Origin: India
• Brand Name: OMB
• Material: STEEL
• After-Sales Service Provided: YES

We are engaged in offering our clients a range of 2 in 1 Vacuum & Casting that is available in gold,silver and other alloy vacuum casting. These products are known for their investment powder vacuum with high vacuum capacity. The striking features of these products are durability, sturdy construction and compact design.

• Weight: 42kg
• Model: Cascom SE
• Power requirement: Single phase AC220V-240V ±10% 50/60Hz
• Power consumption: Max. 3.5kVA
• Overall dimension: 560(W)×490(H)×490(D)mm
• Output frequency: 30–50Hz
• Cooling System: Optional chiller or Direct connect water
• Melting time: Within 3 min. for 60 g of Co-Cr Alloy.
• Casting method: Chamber inverting Vacuum and Pressure Casting. (Automatic)
• Pressure: Air or Argon gas (0.35 MPa)

• Type: Vacuum Casting Machine
• Weight: 100-500kg, 1000-2000kg
• Color: Black, Brown, Grey, Light White
• Voltage: 110V, 220V, 380V, 440V
• Condition: New, Used
• Automatic Grade: Automatic, Fully Automatic, Manual, Semi Automatic
• Power: 1-3kw, 3-5kw, 5-7kw, 7-9kw
• Power Source: Elecric, Hydraulic, Penaumatic
• Warrenty: 1year

• Automatic Grade: Automatic
• Power Source: Electric
• Voltage: 200-380V
• Feature: Less Maintenance,Easy to install
• Frequency: 50-60 Hz

• Voltage: 220V
• Automatic Grade: Automatic
• Power Source: Elecric
• Material: Stainless Steel
• Frequency: 50-60 Hz
• Max Bending Radius: 0-50 mm

• Capacity: 4 KG
• Power: 2 HP
• Material: 4 KG
• Dimension: 24 INCH X 30 INCH X 36 INCH
• Automation Grade: Semi-Automatic
• Vacuum Pump: 300 LTR
• Bottle Of Pump Oil: 5 LTR
• Motor: 2 HP

Casting chamber made of stainless Steel.   High quality vacuum pump is used for better results in De-bubbling as well as casting.   Two tank system to generate high vacuum pressure for minimum porosity casting.   Excellent dense casting provided and it matches international quality standards.   300 liter vacuum pump with 6 liter oil capacity.   Pressure Per Inch (PSI) - 10   Litter Per Minuet (LPM)-= 300

FEATURES Casting machine made up of Induction Heating Technology saves precious time and Power. Latest IGBT technology. It gives uniform mixing of metal. Continuous work is possible at high temperature. Low Maintenance and High efficiency is possible. Digital PID temperature controller. Interlocks : Over Heat; Over Current; Water Fail. Inert Gas pressure at top and High Vacuum ensures complet casting for Pressure Cast. TECHNICAL SPECIFICATION Casting machine made up of Induction Heating Technology saves precious time and Power. Latest IGBT technology. It gives uniform mixing of metal. Continuous work is possible at high temperature. Low Maintenance and High efficiency is possible. Digital PID temperature controller. Interlocks : Over Heat; Over Current; Water Fail. Inert Gas pressure at top and High Vacuum ensures complet casting for Pressure Cast.

• Combining advanced technology: 2 kg.
• l P M: 180
• C F M: 6
• Oil capacity: 3 - 3. 5 ltrs
• capacity coil: 1 kg
• Voltage of Machine: 230 V, 8-10 amp
• Automation Grade: Automatic

The 3 in 1 is an exceptional Vacuum Casting Machine combining advanced technology with 2 kg. Melting furnace, vacuum investing and casting. It gives bottom vacuum lines for investing, an automatically self vibrating investment table. The heavy-duty design and construction, using best available components offers outstanding reliability.   Vacuum Pump Motor – ½ hp l. P. M. – 180 C. F. M – 6 Oil capacity – 3 – 3. 5 ltrs   Heating Element 1 kg capacity coil 1 kw   Voltage of Machine – 230 V, 8-10 amp
