FeatureBright And Shining, Low Consumption, Stable Performance, Suitable For Indoor Or Outdoor
Country of Origin230VAC
Number Of FlowerLed High Bay Light
Wattage200W
Total Carbohydrate2years
Beam Angle(°)120
Country of OriginIndia
IP RatingIP66
Light SourceLED
Protection ratingIP66
Maximum Lumens34000
CRI80
Driver6KV IP66 Isolated Driver
SPD10KV (As per requirement )
Lifetime50000 Hrs
GENERAL INFORMATION
Order Code
LT-200WHBL-PETRA
Make
Lightronix Technology
Country of Origin
INDIA
Lighting Source & Type
SMD 5050 LED
Number of LED
40
OPTICAL PARAMETERS
Led Beam Angle
120 Degree
CRI (Color Rendering Index)
>80
LED Life Span
>60000 Hours
Color
White/Warm White/Cool White (As Per Order)
Color Temperature
2700-6500K(As Per Order)
Led Voltage/Current
6.2V/750mA
LED Make
Bridge lux/Osram (As per Requirement)
Optical Lens
NA
Luminous Efficiency
170 Lm/W
Total Lumens
34000(±5%)
Optical Efficiency
>93%
Thermal Efficiency
>90%
ELECTRICAL PARAMETERS
Wide Input Voltage Range
90-310VAC(With Auto Cutoff)
Operating Frequency
50/60HZ
Power Consumption
200 Watt
Power Factor
>0.95
THD
90%
Supply Phase
Single Phase Supply
Over voltage Protection
440VAC Protection
Under voltage Protection
90VAC
Auto cutoff Voltage
Lower Side310VAC
PCB INFORMATION
PCB Thickness
1.6mm(±5% Tolerance)
PCB Material
Pure Aluminum-Copper
Copper Layer Thickness
Standard 0.35 Micron
Copper Conductivity
>1 Watt
PCB Size
250X250 mm
MECHANICAL PARAMETERS
Housing Material
Aluminum Pressure Die Casting
Housing Color Type
Metal Powder Coated
Housing Shape
Round
Total Luminaries Weight
5.1 Kg
Luminaries Size
Diameter - 370 mm
Height – 190 mm
Mounting Device
Bracket
Mounting Style
Ceiling/Roof/Hanging
Glass Type
4mm Toughened Glass
Cable Entry Option
PG7 Cable Gland with Rubber Washer
Screw Type
Stainless Steel Screw
Gasket Type
Silicone Rubber Gasket
IP Rating
IP65/IP66
Impact Rating
IK08/IK10
Marking Type
Laser Marking/Engraving
Our organization is graded amidst advanced traders of the product in Gandhinagar(India) as well as diverse marketplaces. Keeping it completely confidential, we make certain that the payments made by you are through the leading technology. Apart from the offline transactions, we also support options like credit card, debit card, smart card, e-money, thus, you can opt these options as well.
Use : Used in commercial and residential areas.
Features :
Excellent brightness
Superior finish
Unbreakable Glass
We offer a high-quality LED High Bay Light designed for indoor industrial lighting applications. Our 50W light features a durable aluminum housing with a hook mount for easy installation. Operating at 220V - 240V AC and 50Hz frequency, it provides high-intensity illumination with a cool white color temperature. The IP65 protection rating ensures reliability in warehouse environments. With a wide beam angle, this light is ideal for suppliers and traders looking to enhance their lighting solutions.
Being a client-centric organization, we are engaged in manufacturing and supplying High Bay Lights.. Use: Used in residential areas. Features: Bright illumination. Less power consumption. Precise design.
