Display Range0-99% for Relative Humidity and 0-99.9 ̊C for Temperature
Resolution1% for Relative Humidity and 0.1 ̊C for Temperature
Power Supply230V AC ± 15% at 50/60Hz
P.C. InterfaceRS-232 output available on extra cost.
Mounting TypePanel Type
Front Facia96mm x 96mm
Weight1.2 Kgs.
Digital Humidity/Temperature ControllerModel 7210 Features Direct, accurate display of Humidity and Temperature Uses the classical Dry/Wet temperature sensing technique Sensors are sealed Platinum PT100 type in S.S. immune to atmosphere gases etc. No need of any look-up table as the embedded software accesses the table from the micro controller memory. A sturdy sensor body has in-built water reservoir with facility to connect a water-drip to ensure the wick never dries up. 4 Control outputs for Humidifier, De-humidifier, heater and cooler. Specifications Display : 2 Digits 0.56” RED 7 Segment LED for Humidity. 3 Digits 0.56” RED 7 Segment LED for Temperature Display Range : 0-99% for Relative Humidity and 0-99.9 ̊C for Temperature Resolution : 1% for Relative Humidity and 0.1 ̊C for Temperature Control Range : 0 to 99% for Humidity (over temperature range 0 to 65 ̊C) and 0 to 99.9 ̊C temperature Accuracy : ± 2% ± 1 Least Significant Digit for Humidity. ± 0.2 ̊C ± 1 Least Significant Digit for Temperature Settings : By front panel membrane touch switches. Control Output : Humidifier ON for RH < SET HUMID – 1% De-humidifier ON for RH > SET HUMID + 1% Heater ON for Temp. < SET TEMP – 0.5% Cooler ON for Temp. > SET TEMP + 0.5 ̊C Control Relays : 4 sets of NO-P-NC of 5A/220V AC contact rating Power Supply : 230V AC ± 15% at 50/60Hz P.C. Interface : RS-232 output available on extra cost. Mounting Type : Panel Type Front Facia : 96mm x 96mm Weight : 1.2 Kgs.
