Number Of FlowerHV4 Rotary Table ( Table Diameter -110 Mm)
Brand NameASSORTS
MaterialAlloy Steel
Diameter100mm
Country of OriginIndia
A Precision Small Rotary Table for Milling operation withTable Diameter - 3 Inches (75 mm) with 3 slots.
Height - 47 mm
Worm- Gear Ratio - 36:1, which basically means that 1 handle rotation shall turn the table by 10 Degrees.
Table graduated in 360 Degrees & the scale calibrated in 5 degree increement.
Centre Height in Vertical position is 52 mm.
Can be used in both horizontal & vertical position.
Round Vice Specifications:-
Made of high grade close grain caste Iron.
Fits our 3" (75 mm) Rotary Tables perfectly.
The moving jaw has V-grooves to hold Round objects.
Again these vices are drilled in a manner that these can fit to a 3 as well 4 slot table.
The Drills are counter bored to ensure that the fixing screws sets perfectly ensure perfect movement.
