Due to their excellent beam quality, fiber lasers are the first choice for diverse applications in the field of laser precision cutting and welding, as well as in micro-materials processing and laser marking. In precision laser welding, fiber lasers enable you to create slim seams and achieve narrow kerfs in laser precision cutting – even with wide working distances. In thin materials, the high level of irradiance on the workpiece can be converted directly into a high process speed.
Used in many scientific research and industrial applications such as:
Color Measurements
Lamp Measurement Photometry
Fluorescence Studies
Reflectance of specular or scattering samples
Laser & LED Measurements
Uniform Light Source
The LPKF ProtoMat S103 circuit board plotter for producing PCB prototypes and small batches is configured specifically for RF and microwave requirements. The touchless, pneumatic depth limiter further allows delicate surfaces, soft and flexible substrates to be processed. The ProtoMat S103 also carefully depanels irregular shaped flexible circuit boards from larger boards.
2.5-dimensional operation with Z-axis control
The sophisticated Z-axis drive makes the ProtoMat S103 perfect for finishing front panels and housings as well as depth milling microwave PCBs. Even machining populated PCBs is no problem at all.
100.000 rpm spindle motor
The ProtoMat S103 is extremely fast and accurate with a spindle speed of 100.000 rpm, a max. travel speed of 150 mms and a resolution of 0.5 μm. This ensures the accuracy required for drilling and milling ultra fine structures � especially for high-end applications in the RF- and microwave field.
Dispensing
CircuitPro turns raw CAD data into a dataset for populating the circuit board with soldering paste with no additional expense. The software wizard guides the user through the individual process steps. An internal computation accounts for the pad shape and size to ensure each pad has the right amount of soldering paste. This is further achieved through proven process parameters. The paste is applied with the built-in dispenser, all without having to convert the machine.
Can perform grooving and safety beveling in one operation, Unmatched finish – not achievable by hand or patterned edgers, Ideal for multiple shops or where daily jobs are more than 50 pairs a day, Good only for shops where 80% fittings are done in CR 39. Not good for more of Glass.
