Precision Robotics & Automation Satyadev Nagar, Gwalior, Madhya Pradesh

Tumbler-index-apparatus ref. Standard - is : 6495 - 1994 precision tumbler index test apparatus for iron ore pellets determination of resistance of iron ore pellets to breakage or degradation by impact and abrasion. The precision's, ti01b tumbler tester for iron oxide lump cores, sinters, and pellets consists of a cylindrical drum constructed of mild steel plate. The two circular sides of the drum have two stub axles attached through two circular flanges. The axles are held in two double-row self-aligning ball bearings with the common axis of the axles located in a horizontal plane. The drum is rotated about its axis at the specified speed with the help of an electric motor, worm reduction gearbox, and vbelt pulley arrangement. A pre-set type digital counter is provided to record the number of rotations of the drum and to automatically stop the motor after a set number of rotations. The bearings on which the drum is pivoted are supported on a heavy-duty fabricated metal frame made from mild steel sections. The motor and worm reduction gearbox are also mounted on the same frame to give a single composite unit. A sheet metal hop- per is provided below the drum to collect the material coming out when the drum is rotated with the door removed. The hopper has a square opening to enable the collected material to be removed. A removable stainless steel tray is provided to collect the material from the drum.

We are offering pc based ccs testing machine. Ref. Standard - iso 4700, astm e 382 pc based cold crushing strength (ccs) testing machine determination of cold crushing strength (ccs) of iron ore pellet fired at different temperature determination of cold crushing strength (ccs) of iron ore pellet fired at different temperature. This machine is mainly used in crushing strength test for iron ore pellet, with functions of automatically statistical analysis of iron ore pellets test result as average crushing strength, cv% standard deviation (sd) and calculate ccs force. feature:- â�¢ fully computerised (pc based). Â�¢ max. Test force: 10kn. Â�¢ measuring range of test force: 0.1-10kn. Â�¢ accuracy of test force: â±0.25%. Â�¢ load indicator with facilities for displaying peak load value.. Â�¢ max loading frame strength 50 kn (5 ton). Â�¢ speed range 01 mmmin - 50 mmmin. With cross head speed indicator. Â�¢ precision ball screw drive system. Â�¢ designed for testing ccs strength according to international standards. Â�¢ 24 x 7 days operation, no pulley, no belt and chain sprocket. Â�¢ suitable for operation on 220v, 50hz, 1phase ac supply.

Material : Stainless Steel

Operating Temperature : -10 to +70 Degree C

We offer Draw wire displacement sensor. PDW Series Draw-wire displacement sensors measure linear movements using a highly flexible steel cable. It's provides digital position and speed information (up to 2500 mm measurement range) in a durable, easy-to-install package. Draw wire sensor is a simple solution to measure linear speed and position. PDW Series Draw-wire displacement sensors measure linear movements using a highly flexible steel cable. It's provides digital position and speed information (up to 2500 mm measurement range) in a durable, easy-to-install package. Draw wire sensor is a simple solution to measure linear speed and position. The sturdy measuring cable (also referred to as the string or wire) is made of special stainless steel for ultimate strength. The PDW Series's compact profile and IP66 rating makes this a perfect solution to a variety of industrial linear measurement challenges, whether involved in concrete cutting, controlling hydraulic cylinders, metal grinding, or having an awkward access area for measurement. One of the greatest advantages the Draw-wire displacement sensors offers is its simple and adaptable installation. Simply connect the wire to your moving equipment and secure the base to a fixed object. Hard to reach areas and worries about shaft misalignment are now not a problem, as the PDW Series's flexible design allows for versatile measurement setups with the various interface design as used for rotary axes. Measurements are performed with high accuracy and high dynamic response. The use of high quality components guarantees a long life cycle and high operational reliability. We offer a wide selection of draw-wire displacement sensors with various types of output signal( Analog, Digital, Calibrated output, pulse output, rs232 output, 4 to 20 ma output). This means that each customer has the opportunity of selecting the best sensor for his application.

We offer Heavy Duty CCS Testing Machine Ref. Standard - ISO 4700, ASTM E 382 Cold Crushing Strength (CCS) testing machine Determination of Cold Crushing Strength (CCS) of iron Ore pellet fired at different temperature Determination of Cold Crushing Strength (CCS) of iron Ore pellet fired at different temperature. This machine is mainly used in crushing strength test for iron ore pellet FEATURE:- • Max. test force: 10KN. • Measuring range of test force: 0.1-10KN. • Accuracy of test force: ±0.25%. • Load indicator with facilities for displaying peak load value.. • Max loading Frame Strength 60 kN (6 ton). • Speed Range 01 mmmin - 50 mmmin. with cross head speed indicator. • Precision Ball Screw drive system. • Designed for testing CCS strength according to international standards. • 24 X 7 Days operation, No Pulley, NO Belt and chain sprocket. • Suitable for operation on 220V, 50Hz, 1Phase AC supply. less
