Separating Machines Dealers in Jaipur

Separator is a machine used primarily for grain cleaning in the milling of wheat, durum wheat, corn (maize), rye, soybeans, oats, buckwheat, spelt, millet and rice as well as in storage elevators. It separates coarse and fine impurities from grain via screening and classifies a broad range of materials according to size. In addition to its main field of application, Separator is also employed successfully in feed mills, seed cleaning plants, oilseed cleaning and cocoa bean grading plants. APPLICATIONS OF VIBRO SEPRATOR  Flour and semolina mills  Seed cleaning plants  Cereal cleaning mills  Malt factories  Feed mills  Cereal storage silos STRUCTURE OF VIBRO SEPRATOR  Vibrating structure supported by elastic shock-absorbing elements, containing the sifting body with two rows of sieves pairs.  Self adjusting grain feed.  Self cleaning of the sieve covers by means of rubber balls, Transparent plexiglass panels for checking the cereal strata.  Steel or wooden made sieve frames equipped with easily replaceable perforated plates.  The vibrator motors, which provides the oscillation for the separator.  To top it all the best quality vibrating motors are equipped which provides the oscillation for the Aspirator Separator. WORKING PRINCIPLE OF VIBRO SEPRATOR Vibrating process is maintained by means of vibro-motors, which are placed in the center of gravity of the machine. The grain feeding chamber and body which are mounted on the rubber shock absorbers by vibrating together and driven by vibro-motors convey the product into mid-section of inlet. The grain is separated uniformly on the entire surface of the screen by means of an adjustable regulating gate. If it is necessary, for better product flow another adjustable regulating gate can be fixed to the inlet of thescreen. When the grain passes through from the first screen to the second one, larger size impurities or foreign particles are kept by the first screen and directed to coarse offal discharge line. The remained smaller size impurities or foreign particles, which pass through the second screen, are transferred to fine offal discharge line. Then, the cleaned product is transported to an air canal or tarar. FEATURES & ADVANTAGES OF VIBRO SEPRATOR  Low energy consumption, high capacity and operating efficiency.  Easy and minimum maintenance, hassle free operation by using vibro-motors.  Adjustable inclination (angle) of mesh - grades range 2 - 12. Due to this unique feature, the Aspirator Separator can be used for any kind of cereals at maximum efficiency.  Durability and long lifetime.  Quick and easy replacement of mesh and practical cleaning possible.  Noiseless working.

Maximum operating pressure: 16 bar g (232 psi g) Maximum recommended operating temperature: 66°C (150°F) Minimum recommended operating temperature: 1.5°C (35°F) Typical pressure differential at rated flow: 20 – 60 m bar (0.3 – 0.9 psi)

Oil Gas Separator, Engineering Services, Oil Bath Indirect Heate

Grain Sorting Machine, Agriculture Equipment, Grain Cleaning Machin

Note Sorting Machine, Industrial Shredders, Note Counte

Vibro Separator, Flour Machines, Plan Shifte

Suitable For Sepration upto Mesh. Adjustable Mesh and Yield. Seprates According to Bulk Density and Partical Size.

Grain Sorting Machine, Grain Processing Machine, Indian Spice

Dust Separator Machine, Tractor Model Chaff Cutte
