Separating Machines Dealers in Thane

High Speed, Noiseless maintenance and durability are some of the attributes of our Vibro Sifter. We make available sifter inn different capacities, screen sizes and other specifications to suit the varied requirement of buyers. Vibro Sifter that we offer is manufactured as per the set industry standards to ensure superior quality. We believe in delivering Vibro Sifter within stipulated time frame. Our sifter is portable and compact. Highlights : MOC : SS 304, SS 316, SS 316L Capacity : 12", 18", 24", 30", 36 " & 48" Double and triple deck unit with different screen size Portable and Compact Wide Range of Screen Sizes Noiseless Maintenance Free & High Speed

Hydro Cyclone separators are designed specifically to improve the quality of process fluids where space requirements are limited. These separators provide an excellent method for removing dirt, sand, silt, precipitates and suspended solids from a variety of process fluids. Equipped with a removable dome the interior of the separator can easily be accessed for inspection. A separator has a simple and reliable design which offers long lasting trouble free service. Separators have no moving part to wear out or replace, eliminating malfunction or breakdown.  Separators can be applied to a variety of applications ranging from single pass/full flow to multiple pass/side stream systems. Optional configurations can be engineered to meet specific requirements. FEATURES Available in flow rates from 220 to 12,000  Particulate removal efficiency of 98% at 74 microns and larger expected  150 psi working pressure. Fusion bonded polyester coated carbon steel vessel. Accumulation chamber clean-out standard.  True tangential Industrial grade manual purge valve. 1/4" manual air bleed valve. 0-160 psi gauges on inlet/outlet. Options: Auto purge, higher pressure ratings, ASME code stamp and stainless steel construction MSSIPL is a authorised representative of Puroflux in India.

With our rich industry experience and knowledge, we are engaged in offering high quality Vibro Shifter. This Shifter is manufactured using supreme grade raw materials with the help of latest tools and technology. In order to ensure its quality, this Shifter is stringently tested on various parameters. We offer this product in various specifications as per the requirements of clients.   Features : Corrosion resistance Compact design High durability Specifications: Model : 24/ 30/ 40" Drive Motor : 0.5/0.75/1.0 HP Screen diameter : 600/750/990 mm All contact parts are made out of SS304 quality material Output : 24 up to 150 Kgs./Hr, 30 : up to 200 Kgs./Hr, 40 : up to 300 Kgs./Hr Wide range of seats available in sizes from 4 mesh to 150 mesh

Vibro Sifter is widely used for sieving, sifting, grading of powders & granules. It is ideal for obtaining uniformly sized particles in a batch. It has variety of applications in Food, Pharma-Chem industries etc.   Optional : Available in STD/GMP models Construction SS 304 / 316 / 316L Flame proof motor, push button station and limit switch. Provide option of inline sifting with Various Mills, Rapid Mixer Granulator etc Variety of interchangeable screens for differing applications Flexible design to meet individual process requirements Optional magnetic arrangement to remove iron particles.   Applications : Widely Used in Pharmaceutical, Chemical, food, plastic, sugar, confectionary, etc.

  We are a prominent firm engaged in supplying a wide range of Air Dryers / Moisture Seperators. These products are also checked stringently by quality analysts to ensure that defect free and best quality products to our honoured clients. We fabricated these using top quality materials and available in various dimensions. Clients can avail these from us at competitive prices in the market.Features: Optimum performance Long service life Provides cleaner, drier steam to heat exchangers Application : Compressed Air Exchangers Turbines

[Unimax Multicyclone are a matrix of small cyclones] with common inlet, outlet and dust discharge. [They are available in] a range of 6" to 10" diameter, our multi cyclones are known for their efficiency which is up to 8 microns. We have designed our product in a unique way with respect to Inlet/Outlet proportions, collection cyclones spacing and discharge silos to facilitate uniform gas distribution and proper flow to each individual collecting cyclone for maximum design efficiency. The inlet guide vanes are specifically designed to ensure maximum centrifugal action for the gas entering the cyclone on its spiraling path down the cyclone towards the dust discharge points resulting in an increase in the collection efficiency of the Multi Cyclones. Unimax also specializes in customizing design features to suit specific customer demands.

The top weight on the motor shaft rotates in a plane close to the center of the mass of assembly. Rotation of the top eccentric weights creates vibration on the horizontal plane which causes material to move across the screen cloth to periphery increasing the horizontal throw, causing oversize material to discharge at a faster rate. The bottom eccentric weight rotates below the center of mass creating tilt on the screen giving vibration in verticals and tangential plane. Increasing the verticals component of motion, this promotes turnover of material on the screen surface helping maximum quantity of undersize material to pass through the screen. Rugged springs placed over the circular motor base amplifies the vibration.     Salient Features   Double Decker arrangement can be provided Easy dismantling and cleaning Reputed make vibratory motor

We offer high quality range of vibro sifter. These are circular unitary gyratory screens used to separate mass composition of solids from solids, liquid from solid and for gradation of materials as per particle size, having a very wide range applications. This is accomplished by vibrating the screens in three different planes along the vertical axis by means of a specially designed vibratory motor having off centered weights at the top and bottom end of the motor shaft. the top weight causes vibration in the horizontal plane which causes the material to move across the screen towards the periphery. The lower weight acts to tilt the machine which causes vibration in the vertical tangential axis. The angle of lead of the lower weight with relation to the upper weight provides variable control of the screening pattern. Thus the material moves across the screens and also in the vertical and tangential planes enabling maximum screening. These are available with a wide range of possible screen sizes (mesh) option for multiple deck separation is also possible.

Vats & Vessels. Vibro separators are circular gyratory screens used to separate solids from solids and liquid from solidVibro Sifter consists of Specially Designed Motor mounted vertically at the center of the base plate of the Screen. The Screen is in between feeding hopper and bowl. The material is fed on to the centre of top screen. The undersize material passes rapidly through the screen during its travel to the periphery. The over size material get continuously discharged through a tangential outlet. This is achieved by specially designed Vibratory Motor along with eccentric Top and Bottom Weights.   Working Principle The top weight on the motor shaft rotates in a plane close to the centre of the mass of assembly. Rotation of the top eccentric weights creates vibration in the horizontal plane which causes material to move across the screen cloth to periphery increasing the horizontal throw, causing oversize material to discharge at a faster rate. The bottom eccentric weight rotates below the centre of mass creating tilt on the screen giving vibration in vertical and tangential plane. Increasing the vertical component of motion, this promotes turn over of material on the screen surface helping maximum quantity of undersize material to pass through the screen. Rugged Springs placed over the circular motor base amplifies the vibration   Special Features of Vats & Vessels Vibro Sifter Faster Separation due to springs Multi deck models available Same sieve as used in Mechanical sifter. Lesser Maintenance and Power Consumption than the Conventional Sifter. Simple & Compact construction.

Vibro sifters are circular gyratory screens used to separate Mass composition of solids, liquid form solid and for Gradation of materials as per particle sizes. Vibration is generated in three different planes along the Vertical axis by means of a specially designed vibratory Motor having off centered weights at the top and bottom End of the motor shaft.

We produce the entire range of products by making use of quality-approved raw materials sourced from the trusted vendors present in the market. Also, the inputs are cross checked by our quality experts. Our entire range of products is produced as per international quality standards. Therefore, they are dependable and worth the price.Salient Features : Available in cgmp model with contact parts fabricated from stainless steel (304 / 316) Portable unit for easy operation and higher output. Double and triple deck unit with different screens can be provided. Dust-free arrangement, lead free sieves, noiseless, maintenance free unit. Less power consumption, variable flow pattern. Low operating and maintenance cost, long screen life. Easy to dismantle for cleaning screens. Capacity 12"/ 20"/ 30"/ 36"/ 48"

In Vibro Sifter the material to be screened is fed on to the centre of top screen. The undersize material passes rapidly though the screen during its travel to the periphery. The over size material is continuously discharged through a tangential outlet. Vibro Sifter sare equipped to handle multiple screens one on top of the other with feed trays in between to give several precise sized fractions in a single screening operation. Special designs with up to seven screens are also available for grading. The top weight on the motor shaft rotates in a plane close to the centre of mass of the assembly. Rotation of the top eccentric weights create vibration in the horizontal plane which causes the material to move across the screen cloth to the periphery. Increasing the top eccentric mass increases the horizontal throw causing oversize material to discharge at a faster rate. The bottom eccentric weights rotate below the centre of the vibrating mass creating tilt on the screens giving vibration in vertical and tangential planes. Increasing the vertical component of motion promotes turn over of material on the screen surface helping maximum quantity of undersize material to pass through the screen. The effective vertical motion helps in minimizing blinding of screen. The tangential component of motion is controlled by the angle of lead given to bottom weights with relation to top weights. Variation in lead angle controls the spiral pattern of material travel over the screen cloth. Speed and Flow pattern of material travel over the screen cloth can be set by the operator for maximum through-put and screening efficiency.

Each product in our range is made using reliable materials procured from leading vendors. Thus, our products are trustworthy. We have achieved great heights of success by providing top-notch array of air separators.

  Our Parts have following features :   • High Quality • Cost Effective • More than 5000 different items in ex stock available which can be dispatched at short notice. • We provide solutions others just provide spares.   We deal in following machines spare parts.   • MAB - 103,104,204,205,206,207,209 • MIB - 303 • MMB - 203,304,305 • WSB - 104,203,204,305 • MAPX - 204,205,207,209,210,309,313 • MOPX - 205, 207, 209,210,213, 309 • WHPX - 405,407,409,410,413,505,507,508,510,513 • FOPX - 605,607,609,610,611,613,614 • LOPX - 705,707,709,710,713,719 • WSPX - 204,207,213,303,307 • Also SU and PU purifier spares.   Quick action, Quality service, and low price are always our key principles to win customer trust.
