KARATR VALVES PVT.LTD. Kapurthala Road, Jalandhar, Punjab

Type 2 way, 3 way and 4 way design standards is 904 material available body : bronze (gun metal) cast iron check valve : bronze (gun metal) stainless steel size 2 way has 80mm flanged inlet and 4 way has 100mm flanged inlets. Also supplied with byepass gate valve

Product Features: . Strictly conforming to International Standards . Available in integrally moulded rubber seating . Wafer type sleek design to allow maximum flow . Epoxy coating imparts finish and resistance Test Pressure (Hydraulic) : Body : 2.4 MPa Seat : 1.6 MPa 1 Bar = 0.1 MPa = 1.019 Kgcm² = 14.50 PSI Application Water, Oil

Product Features: Upright, Pendant, Side wall & Concealed Bulb Nominal Dia & Response Standard Response : 5 mm, Quick Response : 3 mm Thread Size (optional) NPT 12 or R 12 Nominal Orifice Size 12? Nominal K-factor 5.6 (U.S.) 80 (metric) Max. Working Pressure 175 psig 1.2 Mpa (12 bar) Factory Hydrostatic Test 100% @ 500 Psig 3.4 Mpa (34 bar) Min. Operating Pressure 7 Psig 0.048 Mpa (0.48) Sprinkler Finish (optional) Natural Brass, Stainless Steel, Chrome Plated, White Color Coated

We offer the best and most competitive distribution of Sluice Valves in India.

Design standard is 636 certification isi material available cotton hose with rubber pvc coating inside. Size 63mm in 15 mts and 30 mts length.

Product Features: . Generally in non rising stem design . Available in outside yoke type rising stem . Flanged ends . Handwheel, cap or gear operated . Available in PN10 & PN16 . ISI Marked as per IS:14846 . Available in CL125 as per BS:5163 . Available in reselient seating as well as metal seating Working & Test Pressure : . Sluice Valve PN 1.0 Sluice Valve PN 1.0 Gate Valve CI 150 . Hydrostatic Test (Mpa) Body Shell 1.5, 2.4, 3.0 . Hydrostatic Test (Mpa) Seat 1.0, 1.6, 2.2 . Pneumatic Test (Mpa) Seat NA, NA, 0.7 Application Water, Oil, Air, Fire fighting applications, Marine applications

Type single and double outlet. Design standard is 5290 certification isi mark material available bronze (gun metal) and stainless steel. Size single hydrant (k-901) : 80 mm inlet and 65 mm outlet double hydrant (k-901d) : 100 mm inlet and 2 x 65 mm outlets.

Type Fixed and Swing Arm Type Material Available MS frame with rubber plastic hose Size ¾” (20mm) x 30 mts length and 1” (25mm) x 30 mts length.

Type Push Type Design Standard IS 909 Certification ISI mark Material Available Bronze (Gun Metal) and Stainless Steel Size Suitable for 65mm fire hose

We offer the best and most competitive distribution of fire fighting valves in india.

Product Features: Permits flow in one direction and closes automatically if the flow reverses Strictly conforming to International Standards Available in rubber seating & metal seating Wafer type sleek design to allow maximum flow Test Pressure (Hydraulic) : Body : 1.5 MPa Seat : 1.0 MPa 1 Bar = 0.1 MPa = 1.019 Kgcm² = 14.50 PSI

Product Features: . Indigenously manufactured stainless steel mirror finished balls with 100% accuracy . Blowout proof stem . Gland packing can be replaced under pressure . Design reference IS:9890 & ANSI B16.1 . Mounting flange for actuator as per ISO:5211 can also be provided . Available in Cast Iron, Ductile, Cast Steel & Stainless Steel

Product Features: Self operative swing type design Flanged ends Designed to allow maximum flow of water Available in PN10 & PN16 ISI Marked as per IS:5312 Bye pass arrangement can be provided Working & Test pressure Type of Valve – PN 0.6, PN 1.0, PN 1.6 Hydrostatic Test (Mpa) Body – 0.9, 1.5, 2.4 Shell – 0.6, 1.0, 1.6

Product Features: . Strictly Conforming to IS : 4038 . Available in rubber seating . Available in swing type & lift type design . Swing type Screwed 15mm to 150mm . Swing type Flanged 50mm to 300mm . Lift type Screwed & Flanged 25mm to 100mm . Valves upto 150mm have single circular door . Valves above 150mm have two semi circular doors . Valve designed for almost full flow rate Test Pressure (Hydraulic) : Body : 1.5 MPa Seat : 1.0 MPa 1 Bar = 0.1 MPa = 1.019 Kgcm² = 14.50 PSI

Product Features: . Indigenously manufactured stainless steel mirror finished balls with 100% accuracy . Blowout proof stem . Gland packing can be replaced under pressure . Design reference IS:9890 & ANSI B16.1 . Mounting flange for actuator as per ISO:5211 can also be provided . Available in Cast Iron, Ductile, Cast Steel & Stainless Steel . Available in Full Bore & Reduced Bore

Product Features: . Temprature Range 34°C to 150°C . No part in contact with fluid except disc and liner . Self lubricated bushes . Neck flange according to ISO:5211 . Direct Actuator mountable design . Design reference IS:13095 & BS:5155 . Neck height to accommodate insulation . Lugs on body make them suitable for using at the end of line . Suitable for actuator & gear mountings . 100% leak tight design . Available in lever type and clutch type handles

Product Features: . Can be installed upto 200 degrees centigrade temperature & 35 bar pressure . Indigenously manufactured stainless steel mirror finished balls with 100% accuracy . Blowout proof stem . Gland packing can be replaced under pressure . Mounting flange for actuator as per ISO:5211 can also be provided . Available in Cast Bronze, Cast Brass & Forged Brass . Available in Full Bore & Reduced Bore . Available in Natural Finish, Chrome Plating, Nickel Plating etc.

Product Features: Releases air during charging and admits air during emptying of water main lines Available in double orifice and single orifice Single orifice are available from 15mm to 50mm in screwed and flanged type Double orifice are available from 40mm to 150mm in flanged type only Rubber coated timber balls are dynamically balanced to give trouble free working Isolating valves if required are available optionally Test Pressure (Hydraulic) : Body : 1.5 MPa Seat : 1.0 MPa 1 Bar = 0.1 MPa = 1.019 Kgcm² = 14.50 PSI

Karatr Valves Pvt.Ltd. is an emerging supplier that provides different types of Swing Check Valves in India.

Karatr valves pvt.ltd. Is an emerging supplier that provides different types of hvac pump in india.

Product Features: . Generally in non rising stem design . Available in outside yoke type rising stem . Flanged ends . Handwheel, cap or gear operated . Available in PN10 & PN16 . ISI Marked as per IS:14846 . Available in CL125 as per BS:5163 . Available in reselient seating as well as metal seating Working & Test Pressure : . Sluice Valve PN 1.0 Sluice Valve PN 1.0 Gate Valve CI 150 . Hydrostatic Test (Mpa) Body Shell 1.5, 2.4, 3.0 . Hydrostatic Test (Mpa) Seat 1.0, 1.6, 2.2 . Pneumatic Test (Mpa) Seat NA, NA, 0.7 Application: Water, Oil, Air, Fire fighting applications, Marine applications
