Measurement Gauge Dealers in Kolkata

Features Connection 3/8 B.S.P (Ballon) Case & Bezel – Aluminium Dial – 0 – 5 KG For Brake Cylinder, Brake Pipe (For Electric loco) Bourdon – phosphor bronze L.E.D. 110V D.C

From Kolkata(India), India, we delight our valuable patrons by providing quality-centralized products. We are immensely accredited for delivering the orders within the stipulated time frame as we have the latest transportation facilities.

We are offering capsule preesure gauge. Capsule pressure gauges are designed for measuring lowvery low pressures and vacuum. The pressure medium needs to be gaseous. The capsule consists of two diaphragms joined and sealed around their circumference. Several such capsules may be combined to enable measurement of very low pressures. Normally, pressure is applied to the inside of the capsule, which changes shape as a result. By means of a link and gear movement system, this deflection is converted into rotation of a concentric pointer indicating pressure on a dial.

Description : Product Name : BM-D-B Applications: Used for pneumatic systems, l:RL Units Compressors, compressed air systems & Other process Industries Suitable for fluid medium which docsnot clog connection port or Corrode copper alloy FEATURES Economy General Purpose

These gauges are suitable for low pressure measurement of non-corrosive gases, commercial heating, gas distribution and filtration. Measuring System of Brass or SS 304 Capsule. Case Material cast aluminium. Available in pressure range 0-50 mm WC upto 10000 mm WC in pressure, vacuum and compound ranges. Available in all standard process connections NPT, BSP etc. ; in dial sizes upto 150 mm Accuracy upto  ± 2percentage. APPLICATIONS Robust design and ingress protection IP 54 For gaseous, dry and non-aggressive media Medical, vacuum, environmental, laboratory technology, for contents measurement and filter monitoring SPECIAL FEATURES Zero adjustment through window Stainless steel case Special location of connection on request Low scale ranges from 0 … 6 mbar DESCRIPTIONS DesignEN 837-3 Nominal size in mm63, 100, 160 Accuracy class1.6 Scale rangesNS 63: 0 … 25 mbar to 0 … 600 mbarNS 100: 0 … 10 mbar to 0 … 600 mbarNS 160: 0 … 6 mbar to 0 … 600 mbaror all other equivalent vacuum or combined pressure and vacuum ranges Pressure limitationSteady: Full scale valueFluctuating: 0.9 x full scale value Permissible temperatureAmbient:-20 … +60 °CMedium: +100 °C maximum+ 80 °C maximum (with NS 100 and 160 back mount) Temperature effectWhen the temperature of the measuring system deviates from the reference temperature (+20 °C):Max. ±0.6 percentage/10 K of full scale value Ingress protectionIP 54 per EN 60529 / lEC 529

Suitable for liquid sumps, Floating Roof, Gas holding tank. Measuring Range : up to 15 Mtrs. Least Count : 5 mm. Max. Temp. : 150˚ C. Max. Pressure : Atm. OPTIONAL – Adjustable Switch,  Transmitter.

Witnessing the need for safer and more sophisticated pressure and temperature instruments, we, H.Guru industries have emerged as the best manufacturer, and supplier in this industry. Products manufactured by us have become the benchmark in pressure and temperature measurement. Our range includes Pressure Gauges & Accessories.

Improved ‘N MC’ Water Gauge comprise two no 6mm straight corning glass tubes terminating into a brass block with a connecting passage. One limb is open to atmosphere & other is connected to fan drift. A tap is provided to close the connection while taking reading. A scale with adjusting screw is mounted behind the glass tubes. A spirit level helps in keeping the instrument vertical.

The Gas Filled Dial Thermometer consists of a stem, capillary, and bourdon tube in a case filled with an inert gas such as nitrogen, as standard,under pressure & the deflection in the bourdon tube changes the movement in the pointer.

Portable hand held gauge for measuring the orifice size (inches) and air consumption (CPM @ 100 PSI) of an abrasive blasting nozzle.
