BRITISH ELECTRICALS Malad West, Mumbai, Maharashtra

Make connections with any style connector, flat to round, miniature to standard.

Thermocouple wire available from 10SWG to 36 SWG in Type J & Type K with Class-1 accuracy & manufacturer's test certificate, other sizes on specific request.

Specially designed for High Temp. Sensor Calibration suitable for upto 1100°C Temp. All in one compact unit consist of following features : Upto 7 Thermocouple + 1 Master can be calibrated at a time. Master PID controller for Accurate heating & controlling Optional : Computer Interface for remote setting of parameters + monitoring: Profile control for multi-point calibration 8 Channel scanner with RS 232 Interface to log result with programable duration from 1 minute to 99 minutes. On-line logging options. Built-in Mini 18 column printer. External 80 column printer interface with dedicated data interface to store upto 450 data of 16 channel with RTC with customised header and footer for direct printing or storing, printing later. Computer Interface with software to monitor & store data as well export to EXCEL format. Isothermal Inconel-600 block with 8 pockets of diff sizes for diff diameters of High Temp thermal insulation to minimoze outer case temp. max 5°C above ambient.

Find a variety of standard sized thermocouple connectors and the accessories to go with them.

  Signal Cable is available in various sizes and nos. of Cores / Pairs Trade with PVC / FRLS / Zero Halogen Fire Retardant (ZHFR) Rodent & Termite Resistance / LDPE/ XLPE / FEP / PTFE and various types of sheath materials with individuals or overall shielding by A1 mylar or copper wire braiding with GI wire / GI strip armoring as per customer's requirement as per BS 5308 & other specifications.

Panel systems keep your thermocouple readings in order, choose from a variety of jacks and accessories designed to fit perfectly together.

Miniature connectors are ideal for even the most demanding temperature measurement applications. Accessories include panels, adapters, and more.

Ferrite core connectors designed for suppression of electromagnetic interference.

Mico® is Europa Metalli's mineral insulated cable manufac­tured according to BS 6207 (or A53013) and comprises:   an outer sheath, consisting of a continuous seamless copper tube with a melting point of 1083°C, a magnesium oxide insulant, with a melting point of 2800°C, 99.9% electrolytic copper conductors, with a melting point of 1083 °C.   Mico® consists of absolutely inert materials with a mineral base with main properties as follows: an extremely high melting point, much higher than tem­peratures recorded in the presence of fire, an extremely high durability due to the fact that the elec­trical and mechanical properties of the materials used remain perfectly stable in the course of time.   Mico® may also be supplied with an additional outer L.S.F. (low smoke and fume material) self-extinguishing sheath (available in orange, red, white and black colour) following the requirements of IEC 332, halogen free, useful for areas where chemical agents may damage the copper sheath. Mico® is manufactured in two ranges: Light duty: L (classified rated 500 V or 0.6kV according to different national standards) ideal for low power lighting and motive power systems, waterproof and fire resistant. Heavy duty: H (classified rated 750 V or l.OkV according to different national standards) ideal for electrical power plants, waterproof and fire resistant. Europa Metalli is one of the few manufacturers all over the world able to supply the full range of mineral insulated cables: either Ligth Duty or Heavy Duty up to 19 cores or up 400 mm2 one core. The commercial coil lengths are designed to the maximum possible, often avoiding the necessity of many joints: saving material, time and money. Please enquire for the actual lengths in the centre pages of this publication. Mico® follows relevant standards, the certification for the manufacturing process and for final product has been issued by many certification bodies, furthermore many tests have been carried out on cable behaviour under fire, water and critical conditions: for a list of certification refer to last page.

Compact Bottom Loading Lab Furnace for 1200oC ideal for R & D application & ceramic industries like Dis integration, Test & Analysis of Advance Ceramic Sample, Glass melting, Refractory porosity, Long term temperature test, Firing & Sintering, Semi conductor Industries for Annealing silicon, Silicon carbide & Nitride samples. Furnace have electrically operated elevator for ease of loading / unloading operation furnace uses latest medium wave infrared technology controlled by Micro Processor Based, fuzzy logic PID control with programmable profile for 2 Pattern of 8 Step each for programming rate of Temp rise & hold time (Ramp / Soak), RS-232 Communication port is provided for on-line monitoring / controlling & Data logging with software provided, multiple using can be monitor using same software ( upto 30 diff. Furncacesmodbus RS-485 interface in place of RS-232 fully insulated for Electrical & Heat.

Power : 230 VAC + 10% 50 Hz, 2000W.

Availability : 26Kgs. Apx.

Various connectors designed to withstand extremely high temperatures and high vacuum applications.

High Temperature Wire Suitable For 600°C / 600 Volts "High Temp." is designed for use in high temperature applications as a single conductor lead wire. It is recommended for use in areas that are exposed to high temperature with a minimum of flexing after installation.   Features Superior mechanical performance. High temperature resistant to 600°C Short time 850°C Fire retardant. Resistant to radiation. Good performance at cryogenic temperatures. Maintains circuit integrity even when exposed to conditions of high ambient temperature and flame. Multiconductor constructions are available.   Applications Motor lead wire. Wiring for ovens, kilns and industrial heating Products and leads for heating elements. Missile lead wire. Constructions Nickel coated copper, solid or stranded. Also available in "A" Nickel. High silica Fiberglass outer braid coated with a high temperature finish. Outer braid may be color coded, natural (tan) is standard.

Recommended for most applications requiring three-wire circuits, including shielded thermocouples, thermistors, and RTD's, negative prongs and inserts are larger than positives to insure proper polarity upon connection.
