We are offering current transformers. The basic application of current transformers are: lowering the very high primary current passing through bus bars, cables, or wires to 5a or 1a, a measurable quantity by measuring instruments. isolating the measuring instrument and protective devices from mains. reproducing proportionate primary current on its secondary side, as required for extending the range of the instruments.

SERIES SCT, ENCLOSED MEASUREMENT CTS The Current Transformers (Cts) are designed for ease of mounting and access, as well as to minimise space requirements. The standard frames, which include overlapping current ratios, permit selection for any cable or busbar system. Enclosed, Tape Wound and Resin Cast Measurement Cts and Tape Wound and Resin Cast Protection Cts for DIN Rail, Busbar and Bracket Mounting are offered but CTs beyond the range specified in this catalogue, also can be offered on request. MEASUREMENT CTS Measurement CTs are required to transform the primary current, at various classes of accuracy, as specified by the class designation, over a current range from 5% to 120% of its rated primary current. The design of this type of CT requires the inclusion of a core and winding which will, when connected to its rated burden, perform within the limits of error as indicated by the standards specifications. It is an advantage for a measurement CT to saturate above this range, which provides a protection against damage to instrument by limiting the secondary current, when surge current or faults appear in the primary circuit.

ABS (Acrylonitrile Butadiene Styrene):ABS use has grown over the last 50 years as more and more molders and OEMs take advantage of the it'sprocessing and property versatility. ABS Applications run from automotive interiors and exteriors, boat hulls and appliances to, Low tension electrical/ electronic components, and industrial equipment.In general, ABS has high impact strength and rigidity, stands up well to chemicals and weather, and it can easily be processed with good as-molded surfaces.Following are the Physical , Mechanical , Thermal , Electrical properties of ABS FR grade .

The Capacitor In-rush Limiting reactors are used in series with capacitor bank to control the in-rush current and to suppress the harmonics. Normally reactors with 0.2% rating are used for in-rush current limiting on neutral side and 6% for line side. Specific ratings between 0.8% to 13% are used for harmonic suppression.

We provide our valued clients highly effectual Neutral Current Transformer which is a long lasting and low maintenance product. Equipped with proper regulation and overload capacity, our Neutral Current Transformer serves the requirement of diverse industries. We have the most competitive price range and provide a quick delivery to our valued clients. Features : Advanced technology Superior qualityOverload capacityLow maintenanceLong lasting

The basic application of current transformers are: Lowering the very high primary current passing through bus bars, cables, or wires to 5A or 1A, a measurable quantity by measuring instruments. Isolating the measuring instrument and protective devices from mains. Reproducing proportionate primary current on its secondary side, as required for extending the range of the instruments. Basically CTS are of different types: BAR PRIMARY CURRENT TRANSFORMER (BPCT) For Currents of 100A and above the bus bars or cables are quite thick and it is easier to measure the currents without breaking the bus bars or cable by means of a Bar Primary current transformer which can be slipped over the bus bar or cable. These CTs are most commonly used as they are sturdy, compact and more economical. WOUND PRIMARY CURRENT TRANSFORMER (WPCT) For currents below 100A, it is uneconomical to achieve the desired accuracy by employing Bar primary type CTs and the solution is Wound Primary C.T., where both primary and secondary are Wound over the core. CLAMP ON CT'S NIPPEN clamp-on CT's enable quick and accurate current measurements on live circuits without disconnecting loads. Precision phase shift characteristics ensure accurate power or energy measurements conveniently. These are one of the accessories in our energy audit system.

Energy meter CT’s made using hybrid cores are DC immune current transformers for energy meters meeting IS 13779 / IEC 62053. The CT is small in size with customized casing and metal shield, (optional) for protection against external magnetic field. The wound CT is epoxy potted for durable and long life performance. Number of turns can be wound/adjusted as per customer requirements. CTs can be provided with or without metal shield in custom casings.

We are offering current transformers. Key features: high quality material, flame retarding and self extinguishing. Apertures accepting a wide range of busbar size. High quality material, flame retarding and self extinguishing. Easy busbar mounting. High quality material, flame retarding and self extinguishing. Cts are ultrasonically welded and are unbreakable. Terminals are finger proof touch as per iec class i.e. It is not possible to touch live terminals with the fingers since they have a protection flap.

Current transformers are used for monitoring load current in networks or great loads. They transform currents in the kA range to e.g. 0-1 A or 0-5 A. Thus large load currents can be evaluated and monitored by downstream automation devices. The new “PACT” analog current transformer portfolio offers a complete range of tubular bar, plug-on and wire-wrap transformers for measuring large currents of 1 A to 4000 A. Depending on the application requirements, almost 3000 different versions of different accuracy classes, capacities and sizes are available. Different mounting positions allow for use even in applications where space is critical. Besides non-calibratable current X’mers, calibratable X’mers are offered, which become calibrated current X’mers after an additional calibrating process. On customer’ request, the calibration of the measuring transducers including the creation and handling over of all certificates can be processed by Phoenix Contact.         Control systems or display elements Like e.g. digital display require standard signals of e. g. 0…20mA as an input signal. As in the current application path to be measured, large currents of upto 4000 A can occur, you need current X’mers that convert these high current to 1 A AC or 5 A AC. Then downstream current transducers uses this current to create typical standards signals that can be processed by e.g. control system. Current Monitoring: With the help of monitoring relays (IF monitoring), currents can be monitored and over currents can be can be signaled via a switching output. As typical monitoring relays only have a measuring input of up to 10 A maximum, a current X’mers the high currents into smaller ones. Motor Management : The electronic motor managers (EMMs), among other things, serve for motoring a drive system or a 3 – phase load. For this, 3 currents have to be measured and monitored. Currents of more than 5 A cannot be processed by the EMM current measuring input. Therefore, separate current X’mers has to be installed before the current measuring input so that the primary current is transformed into 5 A maximum. Test Circuits : Test disconnect terminal blocks and slide terminal blocks were developed especially for the use in current X’mer secondary circuits. The terminals can be fitted on both sides with fixed and switchable jumpers as well as test sockets.

We are offering current transformer. Bar primary ring type current transformers are secondary coil wounded on a toroidal core if high permeability silicon steel. The conductor through which the current is to be measured is passed through the hole of the current transformer. This conductor acts as primary winding and generates proportionate low current in the winding wound on the ring of the current transformer. The windings of the current transformer provides lower proportional current which can be easily measured by the measuring instruments.

  The Capacitor In-rush Limiting reactors are used in series with capacitor bank to control the in-rush current and to suppress the harmonics. Normally reactors with 0.2% rating are used for in-rush current limiting on neutral side and 6% for line side. Specific ratings between 0.8% to 13% are used for harmonic suppression.

DESCRIPTION:- Direct measurement of current in high voltage system is not possible because of insulation problem of measuring instruments. It is also not possible to use current flowing through the system directly, for protection purpose due to its high value & high insulation problem. In such conditions Current Transformers are used. BASIC FUNCTIONS OF VOLTAGE TRANSFORMERS ARE . . . To reduce the line current to a value which is suitable for standard measuring instruments, relays etc. To isolate the Measuring Instruments, Meters, Relays etc. from high voltage side of an installation. To protect Measuring Instruments against short circuit currents. To sense abnormalities in current & give current signals to protective relays to isolate the defective system.

A current transformer (CT) is used for measurement of alternating electric current. Current transformers, together with voltage (or potential) transformers (VT or PT), are known as instrument transformers. When current in a circuit is too high to apply directly to measuring instruments, a current transformer produces a reduced current accurately proportional to the current in the circuit, which can be conveniently connected to measuring and recording instruments. A current transformer isolates the measuring instruments from what may be very high voltage in the monitored circuit. Current transformers are commonly used in metering and protective relays in the electrical power industry. Application Measuring purposes (the CT lowers the current to be suitable for metering instrument) or, Protection of the power circuit (input current for protection relays).
