We are offering single stage high pressure regulator - brass.
Stainless steel diaphragm
standard 10 μm sintered bronze filter at inlet of main valve assembly
1.6 μm internal surface finish as standard
cleaned for oxygen service
bubble tight shut-off
inlet pressure: 210 bar (3000 psi)
outlet range: 0 to 35 bar (500 psi)
flow coefficient: cv 0.06
design pressure: 1.5 times working pr.
all connections: ¼” npt (f)
seat: ptfe pctfe
max. Operating temperature: ptfe - 66º c pctfe - 80 º c
inlet end connection: ¼” npt (f)
outlet end connection: ¼” npt (f)
Maximum Inlet Pressure400, 3500 psig / 27.6, 241 bar
Outlet Pressure Range0 to 10 bar (150 psi)
Inlet pressure40 bar (580 psi)
Flow CoefficientCv 0.05
Design Pressure1.5 times working pr.
All connectionsNPT (F)
SeatPTFE
Max. Operating TemperaturePTFE – 66° C
Inlet end connection½
Outlet end connection½
Point Of Use Regulator manufactured from high quality stainless steel is designed for use with high purity corrosive gases where precise gas delivery system requires high leak integrity and lower dead volume which is necessary for corrosive and toxic gases. This gas prssure regulator are installed at the point of use of any application offering a very stable outlet pressure and handles any pressure changes that may be caused in the system. Details :
Stainless Steel Diaphragm
Standard 10 µm stainless steel filter at inlet of main valve assembly having Bubble tight shut-off.
1.6 µm internal surface finish as standard
Cleaned for Oxygen service
Stainless steel diaphragm0.01% pressure control accuracy under decaying supply pressure
Inlet pressure: 210 bar (3000 psi)Outlet range: 0 to 20 bar (300 psi)
Flow coefficient: Cv 0.05Design pressure: 1.5 times working pressure
All connections: ¼” NPT (F)Simple 270 turn operation
Cylinder changing possible during operationCleaned for oxygen service
Seat: PTFE/PCTFEMax. operating temperature -PTFE - 66° C
Bracket mounted for easy installationAvailable in Stainless steel, brass & monel
The auto changeover regulator system manufactured of stainless steel is a two stage gas delivery system that used two diaphragm sensed pressure regulators into a single body to create a compact auto changeover regulator system. This SS auto changeover regulator System ensures continuous flow of gases in critical applications unaffected by supply source depletion. It is highly recommended in laser gas systems, purging systems and leak testing.
