Multi Mill Dealers in Palghar, Mumbai

cGMP Multi Mill are mostly used for weting and drying granulation, pulverisations etc., in Pharmaceutical Industries, Chemical Industries, Cosmetic Industries, Ceramic Industries, Colour Industries Industries, Dyestuff Industries, Food product Industries etc. It also finds application in Pesticides, Fertilizers, Spices, Detergents, Insecticides, Plasitcs and Resins industries.Details : All contact parts are made out of SS 316 quality material. Machine rated for continous operation. High output with process uniformity. Various combinations of screens / speeds / number of blades / direction of rotation blade, can be selected. All contact parts can easily be dismantled and cleaned for change of product. Wide range of SS perforated and wire knitted screen available. Machine portable on castor wheels. Flame Proof electrical motor can be incorporated.

Multi Mill finds extensive usage in wet and dry granulation pulvensation of pharmaceutical, chemical, bulk drug. cosmetic, colors, dyestrutts and food products. All the parts of Multi Mill are made using stainless steel 304. It comes with electric motor, DOL Starter, 12 blades with knife & impact edges, 222 scraper blades and 1 SS sieve. One can obtain Multi Mill from us in small as well as bulk quantities.

• Suitable for Dry Granulation / Pulversing / Shredding & Chopping of Materials. • Multi Speed Drive for Various Product Grading. • Easy Dismantling & Cleaning. • Output 20kg To 400kg / HR Depend upon Machine Model, Characteristic of Product & the Screen Size. • Easy Maneuverability with the help of Castor Wheels. • Beaters 8 to 12 nos. with Knife / Impact Edge & 2 Scrapper Blades. • Rotor Speed - 750 / 1500 / 2100 / 3000 RPM Approx. MULTI MILL is designed to utilise the principle of variable force swing beaters having both knife and impact edges rotating within a selected screen to control the particle reduction. Material fed in to the processing chamber moves to the periphery and passes through the screen radially and tangentially. Finally the processed material gets collected in to the container kept below the processing chamber.     Technical Specifications Drive Motor : 3HP / 1440 rpm / 3 Phase / 440V / AC. D.O.L. starter provided with reversible switch. Rotor RPM : 750 / 1400 / 2200 / 2800 (approximate). Blades 12 Nos. with Knife & Impact Edges & 02 Nos. Scraper Blades. Output : Depending upon the products and the reduction required in sizes. Foundation not required. Castor wheel mounted base.

SUITABLE FOR DRY GRANULATION PULVERISING SHREDDING & CHOPPING OF MATERIALS MULTI SPEED DRIVE FOR VARIOUS PRODUCT GRADING EASY DISMANTLING AND CLEANING OUTPUT 100 TO 250 Kgshr DEPEND UPON CHARACTERISTIC OF PRODUCT & THE SCREEN SIZE EASY MANOUEVARABILITY WITH THE HELP OF CASTOR WHEELS MOC S.S. 304 316 316 L MOTOR - 3 HP 1440 RPM, ROTOR DIA - 250 MM APPROX BEATERS - 12 NOS WITH KNIFE IMPACT EDGE AND 2 SCRAPPER BLADES. ROTOR SPEED - 720 1500 2100 3000 RPM APPROX OVERALL DIA - 900 L x 800 W x 1700H (IN MM) CGMP MODEL WITH DOCUMENTATION (IQ, DQ, PQ, OQ) - AS OPTION
