Motion Sensor
Get Price Quote
Dual Element Pyroelectric sensor
Wall mounted
Latest Technology Digital Signal Processor (DSP)
Pet Immunity up to 25 kg.
Detection Range 15m
Detection angle 110�
Sealed optics
Excellent RFI and EMI Immunity
Selectable Pulse Count
Walk Test
Product Details:
Model: Platinum
Sensor: Dual Element Pyroelectric
Detection range: 15m, 110 �C
RFI Immunity: Ave. 20V/m (10~1000MHz)
Power Supply: 9 ~ 16V DC, 12V Typical
Current Consumption: 20mA, 12V DC
Alarm Output: NC/NO 30V DC, 0.2A max.
Alarm Duration: 2 seconds
Pulse Count: Single/Double
Tamper Switch: Cover Open activation
Operating Temperature: 0 �C to 50 �C
Walk Test LED: Red, can disable
Temperature: Automatic using
Compensation: NTC thermistor
Detection Speed: 0.3 to 1 m/s
Reverse Polarity Protection: Through Diode
Mounting Bracket: Multi- Rotational ball type
Dimensions: 85mm X 52mm X 39mm (without bracket)
Color: White
Housing: ABS
Accessories: Mounting bracket, screws and fillings.
