Copper Wires Dealers in Mumbai

Polyester Enamelled : IS 13730 : Cross Sectional area 3 to 75 Sqmm Rectangular Copper Wire : IEC 60317 : Width 3 to 20 mm Class 155 : Part - 16 : Thick 1 to 5 mm

Tin Coated Copper wire is complex shape wire and cable. Tin coated copper wire is use as overhead power source for subways, light and heavy transit systems, electrically powered mine trains, buses, and industrial cranes. Tin coated copper wire likely also touches conduit, and other similar things etc. Tin coated copper wire is manufactured in three stages. In the first stage, the wire is drawn in a specific size with electrolyte copper. After the drawing process, the wire goes to second stage in which annealing is done. In the third process, tin plating is done through either of following 2 ways : Hot Dip Process In this process the Tin is being melted in Electric Pot and the Electrolytic Copper Wire is made dip through this melted Tin which results in Tin Coated Copper wire Electroplating Process In this process the wire is gone through a chemical tray and with the help of rectifier and electric current to DC current is passed which results in electroplating, this process is used for house wiring, control panel cable & other electric & electronic wire as well as cable too.

Earth Braids manufactures best quality Copper Wire Braided Strips and Other Metal Wire Braided Strips. Number of strands of bright annealed Copper Wire bunched together & then braided into tubular hollow form and then flattened immediately on same machine to get required width & thickness. These Flexible Copper Flat Braids are available in Bare Copper and With Tin or Silver Plating. Single Wire Gauge option is 27 SWG to 45 SWG.

We can manufacture the full range of copper and tin plated copper wires, from single annealed wires to stranded wires upto 70 smm.We produce cables used for applications as per the needs of the customer, which require most stringent tests including fatigue, dynamic load and fire retardance.

We are offering s.e.copper wire. gage no imperial standared wire gauge copper wire I .s.g.w ft per kg inches mm 9 .144 3.658 35.04 10 .128 3.251 44.44 11 .116 2.946 54.15 12 .104 2.642 67.26 13 .092 2.337 85.96 14 0.80 2.032 113.63 15 0.72 1.892 140.84 16 0.64 1.626 177.51 17 0.56 1.422 282.95 18 0.48 1.219 315.78 19 0.40 1.016 454.54 20 0.36 .914 506 21 0.32 .813 715 22 0.28 .711 937 23 0.24 .610 1250 24 0.22 .559 1500 25 0.20 .508 1875 26 0.18 .457 2300 27 0.164 .4166 2700 28 0.148 .3759 3300 29 0.136 .3454 3900 30 0.124 .3150 4700 31 0.116 .2946 5450 32 .0108 .2743 6250 33 .0100 .2540 7300 34 .0092 .2337 8570 35 .0084 .2134 10350 36 .0076 .1930 12500 37 .0068 .1727 15800
