The company has carved a niche for itself as one of the major Manufacturers and Suppliers of Vibrator Screen Machines in Muzaffarnagar (India). The Vibrator Screen Machines, offered by the company, can be availed in a wide range that comprises of numerous models. The high quality range of Vibrator Screen Machines is fabricated using the best grade raw materials. Why Our Vibrator Screen Machines?
Highly durable and reliable
Excellent performance
Long service life
Low maintenance
ApplicationVibrating The Mix In Moulds At A Frequency Of 12,000 ± 400 Cycles Per Minute.
MaterialMould Steel, Springs, Endless Belt
PackagingEach Machine Is Supplied With AIM 414 One Cube Mould With ISI Certification Mark And Poking Rod.
Power Supply220V, 50Hz, Single Phase, AC Supply
Optional AccessoriesTop Attachment Of Vibration Machine Suitable For 50 Mm Mould
Ref. StandardIS:4031, IS:10080, EN 196-1:413-2, EN 13454-2
Replaceable PartsMould Steel, For 70.6 Mm Cube With ISI Certification Mark As Per IS:10080,Side Spring,Supporting Springs (Set Of Four),Springs For Fitting Mould (Set Of Two),Endless Belt,Belt Guard,Eccentric Shafts With Bearing
Vibration Machine\\nAIM 418-2 & AIM 418-3\\nRef. Standard: IS:4031, IS:10080, EN 196-1:413-2, EN 13454-2\\nA specially designed Vibration Machine is used for vibrating the mix in moulds at a frequency of 12,000 ± 400 cycles per minute, as per specifications.\\nThe Vibrator is mounted over coiled springs and the vibrations are developed by means of a revolving eccentric shaft. The centre of gravity of the vibrator, including the cube and mould, is either at the centre of the eccentric shaft or within 25 mm below it. The simple design of the machine facilitates easy assembly and dismantling of the cube moulds. Each machine is supplied with AIM 414 one cube mould with ISI Certification Mark and poking rod.\\nSuitable for operation on 220V, 50Hz, Single Phase, AC supply.\\n \\nThe equipment consists of the following replaceable parts:\\n\\n\\nAIM 414 – Mould Steel, for 70.6 mm Cube with ISI Certification Mark as per IS:10080\\n\\n\\nAIM 41801 – Side Spring\\n\\n\\nAIM 41802 – Supporting Springs (Set of four)\\n\\n\\nAIM 41803 – Springs for Fitting Mould (Set of two)\\n\\n\\nAIM 41804 – Endless Belt\\n\\n\\nAIM 41805 – Belt Guard\\n\\n\\nAIM 41807 – Eccentric Shafts with bearing\\n\\n\\n \\nOrdering Information:\\n\\n\\nAIM 418-2 – Vibration Machine with built-in Digital Timer, NABL Calibrated\\n\\n\\nAIM 418-3 – Vibration Machine with built-in Digital Timer, without Calibration\\n\\n\\n \\nOptional Accessories:\\n\\n\\nAIM 41855-S1 – Top attachment of vibration machine suitable for 50 mm mould\\n\\n\\nNote: CE mark available on request
