Cosben Equipments TTC Industrial Area, Navi Mumbai, Maharashtra

unique umbrella shape provides dual advantage of cleaning side walls of silo and fluidizes the material simultaneously, guaranteeing uninterrupted flow of material through silo cone. salient features made out of specially developed heat resistant, high tenacity silicon rubber with stainless steel strut for inert gas purging. Suitable to withstand temp. From -70 to 170 degree celsius. easy interchangeability. Ex-stock delivery. cosben is proud to launch another variant in the vibrating bin aerator range which can be installed from outside the silo which is called vibrating bin aerator external.

We specialize in design, manufacture and supply of high efficiency Screw Feeders & Conveyors for conveying/feeding various powders like Cement, Fly Ash, Micro Silica, Ice flakes and other dry powders. The Vertical Screw Assembly consists of the Horizontal Screw Feeder which is installed below a silo or a hopper and as the name appropriately suggests it takes the feed from it. This Horizontal Screw Feeder feeds the powder to a Vertical Screw Conveyor. The Vertical Screw Conveyor is a tubular screw mounted at 90 deg to the Horizontal Screw Feeder to convey & elevate/ load the powder to the required height for filling into a weigh hopper and/ or one or multiple silos with a Distribution Screw (which is another Horizontal Screw Feeder installed at the top of the Vertical Screw Conveyor). The Vertical Screw Assembly system is a mechanical powder loading system which is preferred & recommended over the Pneumatic Loading systems and or Bucket Elevators due to its ease of use, lesser maintenance & compact size. Also in a lot of rural parts of India where the raw material is sourced in HDPE bags and the facilities are not equipped for Pneumatic Loading our efficient & compact sized mechanical loading system which consists of the Vertical Screw Assembly & the Automatic Bag Slitting Machine serves as the perfect solution! For more information on our Automatic Bag Slitting Machine. Salient Features Continuous flight welded on center pipe with variety of pitch, anti-wear coating (For special applications) Choice of tubular or troughs for Horizontal Screw Feeders. Available in different diameters to match the required capacities & lengths. Our screws are equipped with hanger bearings (can have multiple hanger bearings depending upon the total screw conveyor height), end bearings with application specific sealing protection, in line drive mechanism with single or double stage flange mounted reduction gear box and TEFC 4 pole sq. cage induction motors which can be mounted either on inlet or outlet side of the Horizontal Screw Feeder and outlet side of the Vertical Screw Conveyor.

Stainless steel screw Available in tubular & trough version with wide range of diameter & length Available with option of coarse & fine feeding Mirror or matt finish WAS version (without intermediate support) for handling tricky & abrasive powders of chemical Industry Safety features such as limit switch, zero speed switch provided Also available with jacketinsulation option for conveying hot & cold material.

The Spreader Screw is a specially developed Screw Conveyors for the Spreader Screw Assembly used to spread/ sprinkle cement powder over the road in a uniform manner. As seen in the picture of the Spreader Screw above, there are slits provided at the bottom of the screw (Ventral side of the Screw Conveyor) to enable the powder to be spread across evenly. The setup or assembly of the Spreader Screw includes: Set of Screw Conveyors {Cosben Make} Butterfly Valves {Cosben Make} Vibrators {Cosben Make} Storage Hopper Control Panel Diesel Generator An Open Truck The entire assembly/ setup of equipment is mounted on an open truck. The objective is to mount the spreader screw assembly on the open truck which will move on a newly built road and the cement powder is spread uniformly. The Spreader Screw assembly moving on the truck ensures that there is even & equal distribution of the powder along the width & across the length of the road. The storage hopper holds the cement powder to be spread. It is connected to a screw conveyor. This screw conveyor extracts the cement from the storage hopper & conveys it to the Spreader Screw. The Butterfly Valve is installed below the hopper to isolate the hopper & the extraction screw conveyor. The Vibrators are installed on the hopper to ensure free flow of material. The Diesel Generator works as the Power source for all the equipment mounted on the truck. For more details on the working of this screw, please click on the Installation link below.

The Automatic Bag Slitting Machine is a versatile automatic emptying machine and earns it’s name owing to its ability to empty any type of bag be it paper, or HDPE of 25 - 50 kgs capacity. It is ideally suited to Indian conditions where the raw materials in bags are not properly sealed. The overall system comprises of : Feeding Conveyor Bag Emptying Machine Built-in Dust Extraction System Empty Bag Compactor Pneumatic Conveying System

the slide valves are generally used to adjust or fully stop the flow of bulk solid material inside silos, hoppers and similar closed volumes. our slide valves are available with square, rectangular and round sections. square sections are available from dia 100mm to 400mm round sections are available from dia 100mm to 400mm rectangular sections are available from dia 200mm to 300mm detailed specifications are available in our leaflet. special rubber paddings and wipers ensures tight sealing within the valves thus making it leak resistant.

We specialize in design, manufacture and supply of high efficiency Screw Feeders & Conveyors for conveyingfeeding various powders like Cement, Fly Ash, Micro Silica, Ice flakes and other dry powders. The Vertical Screw Assembly consists of the Horizontal Screw Feeder which is installed below a silo or a hopper and as the name appropriately suggests it takes the feed from it. This Horizontal Screw Feeder feeds the powder to a Vertical Screw Conveyor. The Vertical Screw Conveyor is a tubular screw mounted at 90 deg to the Horizontal Screw Feeder to convey & elevate load the powder to the required height for filling into a weigh hopper and or one or multiple silos with a Distribution Screw (which is another Horizontal Screw Feeder installed at the top of the Vertical Screw Conveyor).

Screw Feeders installed under a silo are usually connected/ bolted/ welded to a Dia 300mm butterfly valve. The reduction cone is a functional utility device that ensures smooth connection in case of the diameter of the screw being lesser than the butterfly valve. To get a better clarity, please do have a look at the product photo shown in the Slider above.

Vital safety component for silos to avoid any damage and casualties at site, while loading/unloading of material. Also known as Breather valve, as it balances the pressure inside the silo, breathing the air IN or OUT based on the requirement and safeguards the silo. Maintenance friendly. Salient Features Spring loaded design help controlling the pressure in the range of +1000 mm to -120 mm of H20. Body material stainless steel with fiber top cover. Light weight & compact design suitable for 25-250 Tons capacity Silo. Available Ex-Stock & Easy Interchangeability For more details on this product please send us an email on info@cosben.in or click here.

PLS-type Bin Level Indicators have been specially developed & designed for electric signalling by rotatory action of minimum or maximum material level inside bins, hoppers or silos. i.e. Paddle remains stationary till the time powder is in contact & starts no sooner powder level goes down the paddle radius. Salient Features Suitable for varity of powders having bulk density in the range of 0.6 to 2T/M3.Available in AC/DC voltage as per customer request. Ex-Stock delivery For more details on this product please send us an email on info@cosben.in or click here.

Compact, Space saving dosing, Low Maintenance, Direct Drive, Accurate feeding of powders & granular material. Internal geometry of the body gaunrantees smooth flow of different material. O'ring sealing in the line drive ensures dust-free operation. Quick & Easy cleaning due to less number of components. Built to handle stress of continuous operation.

Internal Screw consists of a continuous flight welded on the center pipe with variety of pitch, anti-wear coating with a bush coupling at the ends for seamless connection with the intermediate hanger bearings and/ or end bearings to ensure smooth rotation. The internal screws are available in multiple diameters and lengths. All our spares are interchangeable & compatible with your current screw conveyor/ feeder.

We offer a choice of cylindrical, rectangular OR ball socket type inlet or outlet connections with option of inclination angle adjustable between 0 – 45 deg. Diameters available for inlet & outlet: Dia 168 Dia 219 Dia 273 Dia 323

We specialize in design, manufacture and supply of high efficiency Screw Feeders & Conveyors for conveying/feeding various powders like Cement, Fly Ash, Micro Silica, Ice flakes and other dry powders. These screws are manufactured with state of the art technology and machines imported from Europe. Salient Features Continuous flight welded on center pipe with variety of pitch, anti-wear coating (For special applications) choice of cylindrical, rectangular OR ball socket type inlet or outlet connections with option of inclination angle adjustable between 0 – 45 deg and vertical. Available in different diameters to match the required capacities & lengths. Our screws are equipped with hanger bearings, end bearings with application specific sealing protection, in line drive mechanism with single or double stage flange mounted reduction gear box and TEFC 4 pole sq. cage induction motors which can be mounted either on inlet or outlet side.

Continuous flight welded on center pipe with variety of pitch, anti-wear coating (For special applications) choice of cylindrical, rectangular OR ball socket type inlet or outlet connections with option of inclination angle adjustable between 0 – 45 deg and vertical. Available in different diameters to match the required capacities & lengths. Our screws are equipped with hanger bearings, end bearings with application specific sealing protection, in line drive mechanism with single or double stage flange mounted reduction gear box and TEFC 4 pole sq. cage induction motors which can be mounted either on inlet or outlet side.

Number Of Flower : CBS 168

Hanger Bearings of a Screw Feeder/ Conveyor are the Intermediate connectors which ensures proper alignment and smooth rotation of the spiral inside the Screw. Cement Screw Hanger Bearings Diameters available for cement hanger bearing : Dia 168 Dia 219 Dia 273 Dia 323 Other Powder Material Hanger Bearings Diameters available for Special Type Hanger Bearing : Dia 168 Dia 219 Dia 273 Dia 323 Recommended for cement conveying & feeding Only

Hanger Bearings of a Screw Feeder Conveyor are the Intermediate connectors which ensures proper alignment and smooth rotation of the spiral inside the Screw. Cement Screw Hanger Bearings Diameters available for cement hanger bearing

Cosben provides all their Screw Feeders/ Conveyors with in line drive mechanism with single or double stage flange mounted reduction gear box and TEFC 4 pole sq. cage induction motors which can be mounted either on inlet or outlet side. All our gearboxes & motors are interchangeable/ compatible with your current screw conveyor/feeder.

COSBEN has introduced Eyelets that will be fitted at the flange for every section. These are for passing Electrical Cables. This will ensure that the Electrical cables do not hang down from the screw causing a safety hazard. The Eylets are wide enough to accommodate a PVC Pipe, if you decide to lay your cable through it. PVC Pipes are recommended for running the cables along the Screw Feeder / Conveyor so that the cables are protected by some degree against the weather.

Our screws are equipped with end bearings that can have application specific sealing protection. Diameters available for the End Bearings : Dia 168 Dia 219 Dia 273 Dia 323

Aluminium frame casting of LM6 alloy, light weight and strong in design Painted with epoxy for dust and all weather conditions giving a high quality finish Terminal box, epoxy coated with Ceramic terminals and non-compressible cable glands Low loss magnetic core with windings of Class H, insulation class F Stress resistant shaft of Ni-Cr alloy steel SKF Bearings for Long and trouble free maintenance Adjustable speed with use of variable voltage frequency drive IP 55 Ingress protection, suitable for dusty environment, Ip66 also available on request

Aluminium frame casting of LM6 alloy, light weight and strong in design Painted with epoxy for dust and all weather conditions giving a high quality finish Terminal box, epoxy coated with Ceramic terminals and non-compressible cable glands Low loss magnetic core with windings of Class H, insulation class F Stress resistant shaft of Ni-Cr alloy steel SKF Bearings for Long and trouble free maintenance Adjustable speed with use of variable voltage frequency drive IP 55/ Ingress protection, suitable for dusty environment, Ip66 also available on request

Dust Conditioner is used to mix powder, sand or other granulate materials with water in order to fix the dust. It is the most economic, advanced technology dust processing equipment that is very easy to install. The dust conditioner can mix and humidify the dust at the same time. The first part is a screw feeder, while the second part is a mixer. There are two sprinkler nozzles with valves to conveniently adjust the water flow. The mixer blades are specially designed to mix the powder and have a long life time.

Integral part of any batching plant NOT ONLY to keep pollution under check BUT ALSO to recover & recycle the dust/powder material back into the system. Available with 2 types of cleaning arrangement - air pulse jet cleaning OR vibratory cleaning in SILO TOP mounting or ground mounted version with fan, hopper and ducting (client scope) for cyclic de-dusting of more than 1 silo. Salient Features Compact design with weather & bird proof cover, easy interchangeability, easy operating height for maintenance as & when required. Unique design for venting of silo capacity of 25-250 Tons. Available with various filtering media suitable for different dust material. Available Ex-Stock & Easy Interchangeability Filter Hoppers Filter Hoppers are used under air filters as reservoirs for collected dust and are designed also to carry the filter itself. Filter hoppers are produced with a single inlet as standard and all inlets have a dust suppressing unit. The standard outlets have a flange for butterfly valve.
