Temperature Range: 10°C above ambient to 60°CAccuracy: ≤ ± 0.2ºC
Uniformity: ≤ ± 1.0ºCAO/WI-400
40002000WX1000DX2000H
2160WX1630DX2200H2
10730WX625DX30H
2.5 KWAO/WI-600
60002000WX1500DX2000H
2160WX2130DX2200H4
20600WX625DX30H
2.75 KWAO/WI-800
80002000WX2000DX2000H
2160WX2630DX2200H4
20850WX625DX30H
2.75 KWAO/WI-1000
100002000WX2500DX2000H
2160WX3130DX2200H6
30720WX625DX30H
2.75 KWAO/WI-1200
120002000WX3000DX2000H
2160WX3630DX2200H6
30885WX625DX30H
2.75 KWAO/WI-1600
160002000WX4000DX2000H
2160WX4630DX2200H8
40905WX625DX30H
3.5 KWAO/WI-2000
200002000WX4000DX2500H
2160WX4630DX2700H8
48905WX625DX30H
4.0 KWAO/WI-2500
250002300WX4500DX2500H
2460WX5130DX2700H10
60815WX750DX30H
4.0 KWAO/WI-3000
300004000WX3000DX2500H
4160W X3630DX2700H12
72885WX625DX30H
5.0 KWAO/WI-4000
400004000W X4000DX2500H
4160W X4630DX2700H16
96905WX625DX30H
5.0 KWAO/WI-5000
500004500W X4500DX2500H
4660W X5130DX2700H20
120815WX725DX30H
Incubator Is a device in which the incubation process is done, an enclosure conditioned to a predetermined temperature to provide and maintain an artificially created optimal conditions for growth of microbial culture.
Incubation is a process -a period of time in which temperature and other environmental variables are provided at a desired temperature level for the growth and development of microbial culture.
Every organism has an incubation period for its growth and development. If incubation is not provided it will result in degenerated the growth of an organism, therefore incubation is an important aspect for the proper growth and development.
Incubator those works at low temperature are used for “incubation” of biochemical reactions
Industries like pharmaceutical, research laboratories, agriculture, Food & beverages requires a Cooling Incubators
Allyone’s top of the line Cooling Incubators are the most preferred choice to maintain accurate temperature & its uniformity throughout the chamber for incubation where high degree of constant temperature accuracy is required.
Incubators are mainly used for the growth & storage of bacterial cultures, Media Preparation, gentle incubation & conditioning and other purposes.
Measured with high accuracy data-logger at sample storage area with standard Set Point
*Custom built Chambers are available in any dimensions and capacities.
Standard Chamber Features & Provisions:
Construction: PCGI/SS 304/SS 316 Tongue & Groove Type Panels with PUF Density of 40Kg/m³ with thickness of 80 mm.
Sample Storage:
Racks: Heavy Duty SS 304 frame secured firmly to chamber inner walls for strength.
Trays: Perforated types (CNC punched). Strengthened with support rails to prevent deformations.
Door: PUF Insulated door with Full View double layered Toughened Glass, mounted with imported hinges & locks.
Door Operation: Passcode protected door operation – from software & HMI
Control System:
Ergonomically designed control panel.
Ferrule printed wiring.
3. Advanced PLC program with built in processor-based Auto Tuning.
4. 4.3″ HMI Color LCD Display.
5. Built in Redundancy & Safety.
6. Advanced High Accuracy “Transmitter based sensors” with output of 4-20 mA.
Temperature Control:
Efficient, Reliable, Time tested & Trustworthy refrigeration design.
Built in redundancy with PLC based Auto Change Over during power outage or component failure viz: Compressor.
PLC Controlled “U” Shaped SS Air Heater Banks.
Safety: Dedicated Thermostats for all key points: Chamber High Temperature, Utility High Temperature
PLC Safety Cut Off for Temperature: High, Higher & Low, Lower safety cut off.
Human Safety: “Person Trap” button provided inside the chamber, which triggers Audio Visual alarm. The button enables the trapped person to come out even if the door is physically locked from outside
Emergency Stop: button provided from outside.
