NDTE Enterprises Belapur, Navi Mumbai, Maharashtra

We use Power LED as the light source for film illuminator unprecedentedly, and finalize our FI-BS as the word class super high intensity cold light Film viewer. With its help, you can see tiny cracks on 4.5 density film easily. Lower power consumption also means lower heat dissipation, which increases system stability, and less energy use. Density Up to 4.5 Density Dimensions 500 mm x 200 mm x 230 mm Viewing area 250 mm X 100 mm with 1 additional mask for 40 mm X 250 mm wide films Intensity control 5 % - 100 % Cooling facility 2 High speed fan Body Stainless steel Input Supply 230 V, 50 Hz NDTE Enterprises, Address: 316,Hilton center, Plot No.66, Sector � 11, CBD Belapur, Navi Mumbai � 400 614 . Mob No. 9892054624 Email Id: ndteent@gmail.com High Intensity X-Ray LED film illuminator
Lamp: Power LED
Intensity Controller for LED
Foot pedal Control
Life span up to more than 50,000 hr
Rugged Stainless steel frame
In built LED lamp for writing report
Lower power consumption Characteristic: Specification:

Acdc yoke model: ndte 7y p technical specification: salient features choice of constant level ac or variable intensity, pulsed h.w.d.c. For surface or sub-surface flaw detestability. Solid state circuit for infinitely variable (step less), potentiometric adjustment of dc magnetic field. Articulated legs to suit differing component contours. Interpole distance adjustable from 0 to 300 mm. Low power consumption. Current draw at 220v, 1 phase supply - only 2 amps. Extremely strong and intense magnetic field for superior sensitivity. Portable & light weight - only 3.5 kgs. Can be used for ac demagnetisation too. No risk of sparking or 'hot spots' on the job. No current flows through the component being tested. Pole distance 50 to 300mm cord length 3 meters input supply 220v, 50hz, 1phase max current drawn ac-2.2 amps dc-2.5 amps lifting capacity at 5 kg ac mode 100mm pole distance 27 kg dc mode yoke weight 3.5 kg controls solid state

AC/DC Yoke Model: NDTE 7Y P Technical Specification: Salient Features Choice of constant level AC or variable intensity, pulsed H.W.D.C. for surface or sub-surface flaw detestability. Solid state circuit for infinitely variable (step less), Potentiometric adjustment of DC magnetic field. Articulated legs to suit differing component contours. Interpole distance adjustable from 0 to 300 mm. Low power consumption. Current draw at 220V, 1 Phase supply - only 2 amps. Extremely strong and intense magnetic field for superior sensitivity. Portable & light weight - only 3.5 Kgs. Can be used for AC Demagnetisation too. No risk of sparking or 'hot spots' on the job. No current flows through the component being tested. Pole Distance 50 to 300mm Cord Length 3 meters Input Supply 220V, 50Hz, 1Phase Max Current Drawn AC-2.2 Amps DC-2.5 Amps Lifting capacity at 5 Kg AC Mode 100mm pole distance 27 Kg DC Mode Yoke Weight 3.5 Kg Controls Solid State
