Mounted Switches Dealers in Noida

ICIR-360HD is a 360° ceiling mount passive infrared SenSwitch with 16A switching capacity for heavy duty control of commercial or industrial applications. By utilizing a specially designed omni-directional infrared sensor and fresnel lens, this SenSwitch is able to switch ON lights when people enter its extensive detection coverage from any direction. A built-in ambient light sensor with different threshold can be set to enable the control functions based on the ambient light level. Different light ON delay times can be selected by easy jumper head placement. Features: • Surface mount technology production • Built-in ambient light sensor• Second-to-none square detection range• Easy TIME delay and LUX level selection • Automatic temperature compensation• Omni-directional detection capability• Detection range mask label provided • Superior RFI/EMI immunity protection   Specifications: • Power supply: 110 / 230 VAC as unit rated• Maximum load      o IC-360: 5A      o IC-360HD: 16A• Delay time: 5\" / 30\" / 1\' / 3\' / 5\' / 20\'• Infrared sensor: Omni-directional, dual element• Photocell sensor: CdS• Detection speed: 0.1 ~ 3.0 m/sec.• Mounting height: 2.4 ~ 3.6 m (8 ~ 12 ft)• Op. humidity: Max 100% RH• Op. temperature: -20°C ~ 50°C (-4°F ~ 122°F)• Dimensions: 100 x 100 x 46 mm

Mountable Rotary Switc
