Digital Process Controller Dealers

Digital PID Loops for both Dynamometer & Throttle Actuator Controller ensures automatic control of engine in various modes of operations.Control modes like– Constant Position, Constant Torque, Constant Speed are provided for both Engine & Dynamometer Control and can provide Power Law mode option on Demand.User interface with front panel digital encoders for Dynamometer & Engine demands (7” touch screen version also available).Interface facility for temperature & pressure channels available.

DPC 965M is 7 segment LED, 5 digit process value with 1/2 inch Display Size.It is intended to be used for indication and control application. Digital Indicator Controller accepts commonly used signal in process industry or 0 to 10VDC or RTD Pt100. In case of other inputs we can provide appropriate converters. Serial port RS 485 with MODBUS RTU protocol gives the user facility to connect the unit on all standard SCADA and DCS. 4-20mA Retransmission output for remote display or PLC can be provided for 4-20mA input type. 2 / 4 relays outputs are available. Ideal for SCADA applications.

Specifications:- Input: RTDThermocouple. Range: For thermocouple- 0 to +999 ºC, For RTD(Pt-100)- 0 to 800 ºC Accuracy: 0.3% ±1ºC Output: 2Relay Output. Control Mode: On-Off control mode, or PID control mode. Power Supply: 230 VAC 24 VDC ±10% Indication: Seven Segment 3.5Digit LED Display. Operating Temperature: -10 to +60 ºC, Humidity: 0 to 90 %Rh

Digital Indicating Controller Model series 4150xx employs the latest in the electronics world to make it powerful, flexible and capable to display and control vareity of physical parameters. These instruments are available from the simplest form of indicators to microprocessor based programmable indicators. This series can accept inputs from variety of sensors like all types of thermocouples, RTDs, Pressure Transducers, mV, mA, LVDTs, etc. The input can be either directly from the sensor or 4-20 mA transmitter, 3 ½ or 4 ½ digit, 0.5" Red 7 segment LED display and keyboard. Thumbwheel switches, or potentiometer to adjust setpoints and programmable decimal points are some of the salient features of these indicators.

We, being a prime Manufacturer, Supplier and Exporter in the industry, offer Massecuite Thickness Controller. It is craved for by our customers. We ensure to deliver within stipulated time frame. The striking features of this product are effectiveness and durability. The quality on offer is in compliance with the industry quality requirements. We offer this range to our customers at market leading prices. Additional Information:The pneumatic massecuite thickness controller developed by us is an innovative design, which offers many advantages over the conventional design currently available in the market. The system designed by us is unique sturdy design following the simple principle of mechanical displacement when it touches the rotating massecuite level. The system is pneumatically operated so that there is very less wear and tear as well as electrical hazards. The level adjustment is on the topside of monitor case only; such that it can be adjusted when machine is running.   Features: Pneumatic actuation hence no electrical hazards Compact and very sturdy design. Very positive sensing. Self lubricating PTFE bush gives less maintenance Sturdy sensing arm does not get damages by any massecuite condition. Broad sensor can easily sense any type of massecuite. Level adjustment is from top. Broad sensor requires very less pushing force, hence fast sensing.

The Digital Dyno Throttle Controller provides precise control on and operation for an Eddy Current dynamometer.   Precise operation through excellent torque and speed control stability     Bumpless transfer of modes with Digital PID control LCD display for indication of demand values, actual values of position, torque, speed and power, operating menus, parameter settings, and messages. Dyno & Throttle demand value setting via 2 incremental encoders Devoted push button switches for mode and other selections Interface to throttle actuator position control Accuracy for speed: ±1 rpm Accuracy for torque: better than ±0.25% F.S. including Dynamometer   Model: EDTC-8000V2Model HDTC-8000V2 available for operating Hydraulic Dynamometer.

96 x 48 x 125 a) Retransmission (4 – 20mA)b) 24 V Power Supply   •Process Indication using Temperature Sensor & various Transmitters

AUTO MANUAL STATION (Manual Loader) Series µCS 5500 Features Microcontroller based fully programmable Bumpless Transfer Separate Set-point Indication Field Calibration in percentage or in Engineering Unit Output Clamping provided Input Failure Detection Password protected parameters

Digital Flow Controller, Flow Meter, Flow Sensors, Digital Flow Transmitte

Variable Voltage Digital controler for vibratory Feeder LED Digital Display Soft Startup ONOFF Control ONOFF Delay

Digital Temperature Controller, Data Logger, High Temperature Transduce

Digital Impulse Heat Controller, Auto Blaine System, Free Lime Analyze

Digital Temperature Controller
