Solar PV Module Dealers in Pune (11 products available)

Certification : IEC,UL,TUV applicable standards

Cell Material : Mono/Poly Crystalline, Amorphous

Protection Diode : Present

Cell Efficiency : >16%

Number of Cell Configuration : 60/72 as per demand

Special feature : +5 watt positive tolerance

warranty : 27 years

Resistant to : PID, Ammonia, Salt Mist Corrosion, scratch

Cell Type : 4BB/3BB

Degradation : <10% in 10 years

Cell Origin : Germany, Japan, Korea, Taiwan, USA

Shape : Rectangular

Feature : Attractive Design, Fine Finishing, High Quality

Application : Industrial and commercial

Power Source : Solar Power

Wattage Range : 50 to 310w

Number of Cell : 36, 60, 72 Cell

Features : 36, 60, 72 cell configuration with wattage ranging from 50 to 310w. High fill factor for improved energy conversion efficiency. Electro luminescence tested for micro-cracks. Torsion and corrosion resistant with anodized aluminum frame. Enhanced reliability through use of distinctive encapsulant and backsheet.

Brand Name : surya renewables INDIA

Application : ELECTRICITY GENRATION

Solar power : 1kw to As per use

Solar panel refers to a panel designed to absorb the sun's rays as a source of energy for generating electricity or heating. A photovoltaic (pv) module is a packaged, connect assembly of solar cells. Solar photovoltaic panels constitute the solar array of a photovoltaic system that generates and supplies solar electricity in commercial and residential applications. Each module is rated by its dc output power under standard test conditions.

We are offering solar pv modules (3wp-300wp). cells cells will be monocrystalline, polycrystalline, ribbon silicon, thin-film, or even multiple silicon layers, such as with sanyo�s hit module. Electrical characteristics, efficiencies, and appearance vary by cell type (see �a peek inside pv,� hp132). Modules can have variable numbers of cells (usually between 36 and 108) with each crystalline cell operating at around 0.5 vdc, wired in series or series-parallel configurations. For example, a 72-cell module with all cells in series will operate at a voltage of about 36 volts. But a72-cell module with two series strings of 36 cells paralleled will operate at about 18 v, perfect for charging a 12 v batteries.
