Tapping Machines Dealers in Pune

Drilling Cum Tapping Drilling cum tapping machine play a dual role drilling as well as tapping with the adjustment in the panel we can tap a job by hand wheel as well as by foot. This machine is very useful for the tapping in production with the help of electric panel we can tap very easily, too fast & accurate.

This machine is designed for drilling cooling hole in pet bottle mould. We can drill hole up to 400 mm with this machine. We can do drilling upto 19 mm.

Tapping cycle (Tap forward - dwell - Tap reverse to home) Spindle drive through stepped pulley. TEFC motors with F class insulation. Automatic tapping is driven by gear pair which provides standard pitch, accurate threads and consistent quality of tapping. Easy replacement of gear pair for different pitches, fitted externally. Inbuilt Safety clutch mechanism to prevent breakage in case of spindle overload. Machines also available in fabricated stand model. Machines can be equipped with multi spindle heads for mass production. Operation and maintenance manual. V Belts Intermediate Table with Rack & Pinion arrangement for lifting and lowering of Work Table. Spindle motor of reputed brand, TEFC, F class insulation, 3 Phase, 50 Hz, 6 Pole Induction Motor with all drive elements. Comprehensive electrical control panel without motor protection device.     Optional Accessories   Tool holders suitable for application. Coolant system consisting of reservoir tank with chip collection tray, separation baffles, coolant pump with 3 phases AC Induction motor, flexible piping & fittings, on/off valves, splash guards or chip collection tray etc. Machine lamp arrangement. Square work table. Jigs & Fixtures.

Jaycee Equipments Pvt. Ltd. offers Tool Loading Articulated Arm which allows for the full-range of motion required to complete any task efficiently and safety.

We are Maharashtra(India) based entity and have become a primary choice of the buyers owing to our timeliness. Since, we have a widespread supply chain network; we can satisfy buyers by catering to bulk requirements and making delivery within the stipulated time.

They allow you to work very smoothly without interruption. This avoids the risk of high torsional forces and the associated risk of cutting tool breakage. Benefits: High torque, high power motor for reliable results. Integrated reversing gear with rapid return action-significantly cuts time required to cut threads. Drill shaft conical holder guarantees maximum precision and concentricity. Infinitely variable electronic speed setting. Metal gear head. Barrel-type motor housing with aluminium support.  kinetic handle. Low width across corners. Superb service life. Collar for use with drill jig.

The air tapping machines by Sumake are dynamically useful and are fully automatic. These machines are carefully tested on various parameters before passing them for operation. They can be accessed in various sizes.

The gantry type taping machine for Diamond Shaped Coils is used to apply insulation tape on Diamond Shaped Coils. The machine is intended for taping ONLY STRAIGHT PORTION on the coil. Some types of adhesive tapes has peel off back-up. The machine offered has arrangement to collect the back-up released on a spool. Hence no mess. The taping head is suspended from overhead gantry structure which has linear and cross guides. The head is suspended with spring balancing assembly. The combination of gantry and suspended head provides facility to maneuver the head on the length of the coil. Skilled operator can take the head near to the neck of the coil. The machines are designed to wind diamond shaped coils of various sizes.

We are offering tapping machine. specification / model us-1 / us-1p/us-1d material mild steel 55kg/ mm2 cast iron metric threads m10x1.5 m12x1.75 bsw threads 3/8"x16 tpi 7/16"x14 tpi bsf threads 3/8"x 20 tpi 7/16"x18 tpi bsp threads 1/8"x 20 tpi 1/4"x19 tpi unc threads 3/8"x16 tpi 7/16" x14 tpi unf threads 3/8"x 24 tpi 7/16" x 20tpi note: 1. The above tapping capacities are for guidance only & subject to change depending on tensile strength, hardness, machinability & kind of tap used. 2. Tapping capacity for other type of threads to be decided on the bases of major diameter & pitch of threads. 3. Tapping capacity on other material to be decided on pro rata bases of tensile strength, hardness & machinability of material.

  Drilling & Tapping Machines 1 2 3 4 5 6 We supply a variety of drilling machines right from the basic, radial and box column to the advanced; all geared auto-feed which have electromagnetic clutch, integrated coolant system and inbuilt LED light fittings.
