Water Treatment Plant Dealers in Warje, Pune

Owing to the expertise of our team of experienced professionals, we are able to introduce an exclusive range of Sewage Treatment Plant. This plant is designed compact effluent treatment system. It is a complete system, which combines with sedimentation tank, and biochemical tank.

REVERSE OSMOSIS:Reverse Osmosis is a well known process of Removal of TDS ( total Dissolved salts or Solids) from water.The Osmosis is very natural process  which everybody of us Knows.The Reverse Osmosis is achieved by applying ‘higher’ Pressure ( higher than Osmotic pressure Plus Losses and Backpressure of RO membranes) on feed water to so as to reverse the direction of natural osmosis (flow of water molecules from Low Concentration-Low Osmotic pressure side to Higher concentration- Higher Osmotic pressure side)The Osmotic pressure is directly proportional to the concentration of it ROT, 1000 ppm Concentration is 10 psig of osmotic pressure,We can visualize it as SUCTION pressure of relatively higher concentration Solution when two of them separated by Semipermeable Membrane. We make RO plants from 200LPH to 30,000 LPH and more.The general recovery of the brackish water RO plant is from 50% till 85%. Today RO is a keyword for most water purification applications from Domestic Drinking Water area to High Purity Boiler Water generation.

our oil filtration plants are used to remove impurities from transformer and switchgear oil such as moisture, dirt, air and other gases. This is a `low temperature and high vacuum` principle based equipment as per the international standards 6034 (1989) and its latest revision. We manufacture plants of variable capacities of 600 to 10000 lph which can be customized to special capacities if required by the clients. This plant takes the impure oil into the system through the inlet ball valve and then pumps it through by a positive displacement pump. A filter prior to this removes solid particles up to 1mm size and magnetic particles. After heating the oil up to 60°c it passes through the cartridge filters, where particles up to 5 microns are filtered. A specially designed vacuum chamber removes moisture, air and all the gases with the help of vacuum. The oil falls by way of gravity over the media inside forming a thin film of oil, exposing a larger surface area. The dissolved moisture and gases are evacuated and the oil is ready.

We are acknowledged among the leading manufacturers of packaged drinking water plant. Our products has high output ro system. We design and fabricate packaged drinking water plant as per the quality of untreated water of the location. Our packaged drinking water plant is available in two modes, namely fully automatic & semi-automatic.

We are Engaged in Offering Plc Controlled R.o. Plant To0 Our Customers. this Plant Has Compelled Us to Provide Solutions for Residential, Commercial and Industrial Water Treatment Plant. Plc Controlled Reverse Osmosis System Specifically Designed for the Removal of Tds from the Treated Waste Water from Textile, Leather, Chemical and other Process Industry. this Reverse Osmosis Plant is Ergonomically Designed to Serve the Purpose of Proper Water Treatment Solutions. the Ro Plant is Meant to Serve Brackish Water Applications Where More Output is Required.

Every swimming pool needs an efficient Filtration Plant, Filter Systems, Accessories & Equipment to keep the pool crystal clear and hygienic swimming pool water.We are leading manufacturer, importer and supplier of wide range of swimming pool filtration plant, filter systems, swimming pool accessories and equipment which include Sand Filter, Cartridge Filter, Pool pumps, Pool Skimmers, Pool Shell Equipment, Overflow Grating of different sizes and Color Shades etc. SWIMMING POOL FILTRATION PLANT & FILTER SYSTEMS The hygiene of pool water is the main concern of a pool owner and its users. Since many skin diseases can be contacted through the water it is ensured that regular filtration takes place by the filter systems. Comprehending the same requirement, we have in store for our clients a wide range of swimming pool filter systems, which are extremely instrumental in maintaining the hygiene and sanitation of the pool water. The distinguishing features of our range of swimming pool filters are as follows: Low maintenance Ideal filtration rate Low media migration Simple usage We are versed in all aspects of modern filtration vessels, matching them perfectly for the job required, within the design constraints of the plant room, and ensuring that the facility can still be operated in the event of planned maintenance or an unforeseen breakdown, with the plant operating at reduced capacity. Chemical control equipment is tested in our own workshops before being transferred to site to ensure a smooth, trouble-free installation without delays. We offer a range of monitoring options for our systems including remote on-site, remote off-site. A good filtration plant is necessary complement to every pool. Pool filter systems is used for capturing the coarse impurities in the water and its running helps to keep the water clean, and also extend the life of the pool.

We are involved in superior quality Sewage Treatment Plant to the valued clients. The internal controls of the Sewage Treatment Plants are adjusted during factory testing and do not require subsequent re-adjustments. We offer the Sewage Treatment Plant at competitive prices to clients.

OIL FILTRATION PLANTS CAN BE SUCCESSFULLY MODIFIED & AUTOMATED FOR VARIABLE FLOW RATE. A brief description is given for your reference.   INLET & OUTLET PUMPS : The pump will be driven by suitable sized AC drive to control the flow rate. By using these settings we can control the flow rate from i.e. If Plant is 6000 LPH then it will vary from 1000 LPH to 6000 LPH.   HEATER TANK : It is also necessary to select proper heat output for variable flow rates. This will avoid localized heating of oil for small flow rates.This section will incorporate PLC which will control the heaters.PLC will be used for control of heater groups, once certain flow rate has been selected, heaters will be configured automatically to suit that flow rate. This control panel will be designed for reliable & trouble free operation.By using the above system the major benefit is to have a single machine instead of different models for different capacities. In this case, flow rate can be kept variable from 1000 LPH to 6000 LPH. Power saving of 30% can be achievable by using this system as compared with traditional oil filter system designs.   OPERATIONAL & PROCESS AUTOMATION Press 'START' to start the oil filtration process. All airing valves, oil inlet & outlet valve will close. The rotary vacuum pump will start to achieve coarse vacuum. After achieving coarse vacuum level, which the 'Vacuum Switch' will sense. After achieve the desired level of fine vacuum in the plant, oil inlet valve & intermediate valve will open and the oil inflow will start due to vacuum inside the plant. The flow switch provided in the suction line of the plant will sense the oil flow & that signal will start the oil inlet pump. In case, the incoming oil flow is not there, HMI on the control panel will display 'LOSS OF OIL', with annunciation. One pressure release valve, provided across the inlet pump will control the excessive pressure rise in the plant. As oil is filled in the degassing chamber, the high level float switch will operate & that will put 'OFF' the inlet pump & start the outlet pump. The starting signal to the outlet pump will open the outlet valve. As the oil level in the degassing chamber comes down, the high level float switch will start the inlet pump, again. Thus the oil circulation through the filtration plant will start. After the continuous oil flow through the plant, the heaters will be 'ON'. Temperature of oil will be controlled by TIC (Temperature Indicating Controller) & one safety thermostat will control the accidental temperature rise. Thus the hot oil circulation through filters & degassing chamber will start resulting in the effective separation of solid impurities as well as dissolved moisture & gases from the oil. During the filtration process, the necessary interlocks provided will avoid malfunctioning of the plant, like   1. High level float switch will stop the inlet pump, to avoid flooding of the degassing chamber. 2. Unless the inlet pump is 'ON' the heaters will not be energized. 3. Low level float switch will stop the outlet pump to avoid dry running of the pump During the filtration process, the moisture meter, installed in the inlet line, will display the moisture content in PPM, continuously, on it's indicator, on the control panel. Once the desired PPM (moisture) content is achieved, the moisture meter installed in the inlet line, will shut down the plant, automatically. This plant will also run with Manual Interference means with Manual Operation.

The cooling system of the engine (V92S2 & V46) is of a closed, high temperature type, with forced circulation and ejection cooling radiators. The system provides for dissipation of heat from the engine parts containing hot gases and maintains their temperature within permissible limits. The coolant used is water.Used on : T90, T72 tanks.

Our oil filtration plants are used to remove impurities from transformer and switchgear oil such as moisture, dirt, air and other gases. This is a `low temperature and high vacuum` principle based equipment as per the International Standards 6034 (1989) and its latest revision. We manufacture plants of variable capacities of 1200 to 25,000 lph which can be customized to special capacities if required by the clients. This plant takes the impure oil into the system through the inlet ball valve and then pumps it through by a positive displacement pump. A filter prior to this removes solid particles up to 1mm size and magnetic particles. After heating the oil up to 60°c it passes through the cartridge filters, where particles up to 5 microns are filtered. A specially designed vacuum chamber removes moisture, air and all the gases with the help of vacuum. The oil falls by way of gravity over the media inside forming a thin film of oil, exposing a larger surface area. The dissolved moisture and gases are evacuated and the oil is ready.   Releted Links:  Transformer Oil Filtration PlantOil Filtration PlantMobile Transformer Oil Filtration PlantVacuum Impregnation PlantVacuum Drying AutoclaveAir Drying OvenB.D.V Testing KitCartridge FiltersBag FiltersOil Hoses O-Rings  High-Vacuum Transformer Oil Filtration and Dehydration Plants Our Oil Filtration Plants are used to remove impurities from transformer and switchgear oil such as moisture, dirt, air and other dissolved gases. This is a `Low Temperature and High Vacuum` principle based equipment as per the International Standards 6034 (1989) and its latest revision. We manufacture plants of variable capacities of 600 to 25000 LPH which can be customized to special capacities if required by the clients. This plant takes the impure oil into the system through the inlet ball valve and then pumps it through by a positive displacement pump. A filter prior to this removes solid particles up to 1mm size and magnetic particles. After heating the oil up to 60°C t passes through the cartridge filters, where particles up to 5 microns are filtered. A specially designed vacuum chamber removes moisture, air and all the gases with the help of vacuum. The oil falls by way of gravity over the media inside forming a thin film of oil, exposing a larger surface area. The dissolved moisture and gases are evacuated and the oil is ready.   Transformer Oil Filtration and Dehydration Plants / Purifiers are available for   Transformer and Capacitor Manufacturers – Skid mounted plants for preparation of new oils prior to apparatus filling and impregnation.   Transformer Repairers - Complete plants for preparation of new oils and regeneration of used oils for reuse. We can provide the purification system you need as well as vacuum storage tanks and transformer filling and emptying / pumping station.   Transformer Owners - Portable plants are available in a variety of trailer-types and sizes to allow on-site servicing of transformer oil right in the substation. Trailers are available with a wide variety of options including laboratory space, oil-testing equipment. Plants are designed for drying out of the transformer insulation and oil filling and impregnation under vacuum. Hot oil circulation and hot oil spray methods can also be used.   The filtration plant will be designed for high vacuum & low temperature of oil for achieving required results.The plant will be Mobile, to be mounted on your Vehicle or Skid Mounted, with or without enclosure, suitable for outdoor or indoor use.All components will have adequate strength & rigidity to withstand normal conditions of handling & transport.   The plant will consist of the following :   Inlet Pump   A 600 to 25000 LPH capacity positive displacement gear type pump will be provided. The pump will be suitable for vacuum & continuous trouble free operation. A pressure release valve will be provided across the gear pump, to control the accidental pressure rise in the plant.     Capacity – 600 to 25000 LPH   Operating Pressure - 2 Bar   Suction - 4-5 mtrs   By pass arrangement will be provided in between Inlet & Outlet     Heaters   Nicrome or Kanthal wire heater elements inserted in refractory formers will be provided in protection tubes to avoid localized overheating, hot spot formation & breaking of oil. Heaters will be capable of heating oil from 200 C. to 600 C., as recommended in IS 6034 – 1989. Total heater power will be 9 to 248 kW divided into two/three groups. Each group of heaters will be controlled by TIC. An additional thermostat will be provided as a safety to control the temperature during accidental temperature rise.The surface density of the heater pipes will not be more than 2.5 watts/cm2.A drain valve for the heater tank will be provided.     Indirect type, Wound elements placed in ceramic formers located in Protection Tubes.   Heater Power : 9 to 248 KW.   A Pressure Safety Valve & a Drain Valve will be provided.   A Control Thermostat and a Safety Thermostat will be provided.     Filtration System   Filtration system will consist of the following,   A Preliminary filter   This filter will be provided to prevent any damage to inlet pump by straining magnetic & all other particles above 1mm size. The cleaning of the filter is possible without dismantling the filter from the pipeline.   Cleanable without dismantling     Flow capacity – 600 to 25000 LPH   Rating - 50 mm   Arrests magnetic particles B Pre-Filter   Filters will be easily changeable. It will be suitable for removal of particles larger than 20 microns. It will be suitable for removal of sludge content in the used oil. This will enhance the life of fine filter. C Cartridge Filter (fine filter)   Throw away type, non-hygroscopic cartridge filter elements of one-micron rating will be provided. The cartridges are easy for replacement & have large dust holding capacity.   Cartridge Filter (fine) placed in a steel housing.     Flow capacity – 600 to 25000 LPH   Rating - 1 Micron     Ionic Reaction Column   An Ionic Reaction Column of 10 to 40 Kg activated alumina will be provided for reduce the acidity in the oil. A bypass arrangement will be provide for after first filling with IRC.     Degassing Chamber (Single Stage as well as Two Stage)   It will be of M.S. welded construction. The chamber will be designed to withstand the suitable vacuum. In the degassing chamber, dissolved gases & moisture from the oil will be removed. A specially designed media will be provided in the degassing chamber to offer maximum surface area, to form a thin film of oil, to achieve maximum possible removal of dissolved gases & moisture at the rated flow rate. One high level & one low level float switch will be provided to control the oil level in the degassing chamber.   Two stages will be separated by a siphon seal.Highly efficient Two Stage degasser packed with Raschig Rings & equipped with the following :     Totally Welded   Sight Glass & Lamp Shade   Raschig Ring Trays   Low Level and High Level Float Switches   Level Sensor will provided in Degassing Chamber     Outlet Pump   A centrifugal pump will be provided at the outlet. The capacity of the pump will be 12000 LPH and it will be suitable for sucking oil from degassing chamber, held under vacuum.     Capacity - 12000 LPH.   Discharge Head - 8 Mtrs     Vacuum Pumping System   A combination of roots & rotary vacuum pumps will be provided for evacuation of degassing chamber. An additional connection with an isolation valve will be provided in the system, to facilitate evacuation of transformer tank, simultaneously.The vacuum pumping system will be equipped with all-necessary accessories like Vapour trap, condenser, valves & gauges etc.The specifications of the vacuum pumps will be as follows:   Rotary Oil Sealed Pump Pumping speed (Minimum) Ultimate vacuum Make Indo Vacuum/Dicon/Tuthill/Leybold/Woo Sung/ Shinko Seiki/Reputed   Mechanical Booster (Roots) Pump   Pumping speed (Minimum) Ultimate vacuum Make Indo Vacuum/Dicon/Tuthill/Leybold/Woo Sung/ Shinko Seiki/Reputed   The Vacuum System will be equipped with the following :     Vacuum Gauge (Bourdon Type), Range: 0 to -760 mm of Hg   Vacuum Gauge (Digital Type), Range: 1 Torr   Airing Valve   Non return Valve     Cooling System   For cooling, a condenser will be provided in the vacuum line. A condenser will be provided, to maintain ambient temperature of the water which will be circulated through this condenser for collecting water in to the trap. One water tank will be provided in to the top of the mobile van having capacity to hold 100 liter water.     Non Return Valve   One non return valve will be provided at the inlet and one at the outlet, which will prevent mixing of filtered & unfiltered oil, in case of power failure.     Valve & Piping   Two airing valves will be provided for airing the vacuum system. All inline valves will be Ball Valve in case of Fully Automatic System then Valves will Solenoid Valves with carbon steel body & S.S. ball, suitable for vacuum application.     Oil & Vacuum Valves will be of Solenoid type or Ball Valve.   Piping will be of Normal Steel.   Mechanical Non Return Valves before Degassing Column & at Plant outlet   Oil Sampling Valve   Isolation Valve at Plant Inlet & Outlet   One pressure gauge at the inlet of the cartridge filter will be provided. One bourdon type vacuum gauge & one digital gauge (for measurement of fine vacuum) will be provided in the vacuum system.Independent electric drives will be provided for all pumps. Motors will confirm generally to is 325 (testing) & will be of CGL / Hindustan Motors / Siemens or any other reputed make. Starters will be of direct on line type.     Control Panel   The enclosure will be fabricated out of CRCA sheets & will be suitably coated to protect from weather. All electrical control gears, mains isolating arrangement, starters, contactors, pilot lamps, push buttons, HRC fuses, relays, indicating lamps and interlocking arrangements will be housed in the enclosure. All wiring will be neatly routed & all wire terminations will be suitably identified with ferrules.A tube light will be provided for plant illumination. The plant will be suitable for operation on 415 V, 3 Phase, 50 Hz. A.C. supply.Incoming Power Supply Cable for Control Panel is to be arranged by the Customer and is not included in scope of our supply.   Electrical Interlocks     The inlet pump will be interlocked with the heaters, in such a way that unless the oil is actually flowing in the system, the heaters cannot be energized. The electrical interlock between heater supply and motor supply will also be provided so that as soon as the inlet motor trip due to some fault in the drive/due to supply failure, the heater supply will also be automatically cut off.   In case of power failures, electro magnetically operated inlet and outlet solenoid valves will be closed and prevent oil from entering the degassing chamber. The moment oil inlet pump or discharge pump is switched on the corresponding valves will open automatically.   The suction pump and the level controller in the degassing chamber will be interlocked in such a way that when the oil/foam level in the degassing chamber increases beyond the desired level, the suction pump will be automatically cut off so that there is no further flow of oil in the degassing chamber.   The temperature indicator of digital type, together with thermostat provided will automatically switch on/off the heater elements in groups so that temperature of the oil during treatment will not be permitted to rise above the pre-set value.   A pre-set safety thermostat provided on the heater vessel will switch off all the heaters in case of any accidental temperature rise of the oil above safe temperature levels so that any likelihood of fire hazard is fully eliminated.   The inlet gear pump will be provided with built in relief valve to take care of accidental pressure increase at the outlet side of the gear pump.   An external relief valve will be provided on the heater vessel to take care of any accidental pressure rise above the safe level in the heater vessel.     Oil Hoses   Two numbers Nitrile Rubber Hoses each 10 to 15 Meters long with quick connect coupling end connection on both sides shall be provided. One is for inlet & one for outlet. Oil Hoses will be capable of handling the transformer oil at 135oC (max.) and hoses will be will be suitable for full vacuum operating conditions.     Lifting Hook   Lifting Hooks for Plant will be provided to facilitate ease of Plant Loading and unloading.     On Line Moisture Meter (As per clients requirement)   A panel mounted Digital Moisture (PPM) Meter will be provided in the outlet line to measure the moisture content in the oil.     Oil Flow Meter with Totalizer (As per clients requirement)   A panel mounted digital oil flow meter of Vatturkar / Inconel / reputed make will be provided in the outlet line to measure the oil flows.     Sleeping Arrangement (As per clients requirement)   A frame mounting arrangement for sleeping purpose of the operator will be provided in the mobile van on top of the heater tank. The bed will make from foam sheet and Rexene cover. Cooling fan will be provided in the rest room. Two persons easily sleep in to the rest bed.     Platform for Bike (As per clients requirement)   The platform will be provided for hanging bike in to the mobile van. The arrangement will be making as per your requirement and it will easy to handle in all situations.     Painting   A suitable anti rust primer will be applied on the interior and exterior surface of all steel parts, which shall followed by application of two coats of suitable durable paints to serve as base and binder for the finished coat. Under body of carriage will be painted with special black anti rust paint     Inspection Testing & Commissioning   Inspection & Testing of Transformer Oil Filtration Plant will be carried out by Consignee before dispatch.Commissioning will be done at site; our Engineer will be available on schedule date mutually decided by both parties.Our one person will be provided at your site to train and educate the operators for the period of one month. Site expenditure of the person will be at your scope.     Drawings & Manuals   One set of Schematic drawings & Guaranteed Technical Particulars of the Transformer Oil Filtration Plant will be provide with the offer and detail drawing with general arrangement of Filtration Plant, Electrical Wiring Diagram and User Manual will be provided at the time of supply.     Performance Guarantee   We give guarantee for performance of the Plant for a period of 12 months from the date of commissioning of the Plant or 18 months from the date of dispatch, whichever is earlier. During guarantee period we undertake upon written request of the purchaser to repair or replace at our discretion & as soon as possible any parts of goods delivered which can be proved to be damaged or unfit due to bad material, faulty design or poor workmanship. This guarantee does not cover damages resulting out of normal wear & tear, improper maintenance, failure to observe the operating instructions, incorrect operation, excessive loading, the use of unsuitable material, & other reasons beyond our control. This guarantee does not cover Consumables, Rubber Parts (including Oil/Vacuum Hoses) & Electrical Components-Motors.
