Quadrant Scale Dealers in Roorkee

Quadrant scale is intended for measuring the basis weight very rapidly and accurately in grams per meter sq. of paper, board & corrugated fibre board or other sheet materials by weighing a small test sample of a certain dimension. SPECIFICATIONS: • Two graduated scales, Range: (0-250GSM), Graduation 1gm2 for sample size. 25x40 cm2 or 20x25 cm2. • Range :( 0-500 GSM), graduation: 2 gm2 for sample size 20x25 cm2. • Full-scale reading corresponds to 25 grams. • Indicating Scale radius 30 cm & 50cm. • Rigid strip pendulum with hardened bearing for suspension support. • Sample Basket of stainless steel wire or sample clip holder. OPTIONS AVAILABLE: Scale (0-125 GSM), Graduation 0.5 gm2 Scale (0-250 GSM), Graduation 1 gm2 Scale: (0-500 GSM), Graduation 2 gm2. Scale: (0-1000 GSM), Graduation 4 gm2 Tearing Template: 10x10 20x25 25x40 cm2.

• Feature: Premium quality, Flawless finish , Highly durable.
• Use: Used for measuring the basis weight

For measuring the basis weight GSM of paper and other sheet materials by weighing a small test Sample with given dimensions. The scales also have the grams weight graduations to calibrate the instruments. Range Available 0-125 GSM template 20x20/20 x 25/40 x 25 cm. Radius 30 cm. 0-250 GSM template 20x20/20 x 25/40 x 25 cm. Radius 30 cm. 0-350 GSM template 20x20/20 x 25/40 x 25 cm. Radius 30 cm. 0-500 GSM template 10x10/20 x 20/20 x 25/40x25 cm. Radius 30 cm. 0-1000 GSM template 10x10/20 x 20/20 x 25/40x25 cm. Radius 30 cm.   Template size can be selected any. With two ranges 0-175 & 0-350 GSM, Template 20x25x/20x50 cm. Radius 30 cm. With two ranges 0-500 & 0-1000 GSM, Template 20x25x/20x50 cm. Radius 30 cm. With two ranges 0-1000 & 0-2000 GSM, Template 10x15x/20x20/20x25x25x40 Radius 30 cm. With two ranges 0-500 & 0-1000 GSM, Template 20x25x/20x50 cm. Radius 50 cm.   0-500 GSM. Template 40x40 cm. Effective weight 0-80 gm. Radius 50 cm. 0-1000 GSM. Template 40x40 cm. Effective weight 0-160 gm. Radius 50 cm. With four range 0-175, 0-350, 0-500 & 0-1000 GSM, Template, 20x25 cm. Effective weight 0-50 & 0-17.5 Radius 30 cm.

We offer superior quality quadrant paper scale that is intended for measuring the basis weight very rapidly and accurately in grams per meter sq. The quadrant paper scale takes the measurement of paper, board & corrugated fiber board or other sheet materials by weighing a small test sample of a certain dimension. specifications one graduated scale range : 0-250 gm, graduation 1g/m for samplesize : 20x25cmrange : 0-500 g/m2, graduation : 2 g/m for sample size :20x25 cmfull scale reading corresponds to 25 gramsindicating scale radius 30 cm x 50 cm.rigid strip pendulum with hardened bearing for suspension supportsample basket of stainless steel wire or sample clip holder options available scale : 0-500 g/m, graduation 2 g/mscale : 0-1000 g/m, graduation 4 g/mtearing template : 20x25 / 40x25 cm
