We are Offering Industrial Motherboard. Our Latest Model Aimb-764 is a Full-sized Industrial Atx Motherboards Measure 305 X 244 Mm and Support Up to 7 Expansion Slots.
IEI offers industrial motherboards with different size that are compactible with Intel and AMD chipsets to meet various demands. IEI industrial motherboard is designed with rich IO ports, flexible expansions and support of wide range temperature to provide multiple automated applications, such as Kiosk, POS, gaming, factory, inspection, machine vision and IoT field.
10th Gen Intel® Xeon® W / Core™ / Pentium® / Celeron® with Intel® W480E/Q470E/H420E PCH Mini-ITX Motherboard
10th Gen Intel® Xeon® W / Core™ / Pentium® / Celeron® processors, up to 4.8GHz
2x DDR4 SO-DIMM, Max. 64GB, ECC compatible
Intel® Processor integrated graphics, supports DVI-D, HDMI, DisplayPort and 24-bit dual channel LVDS or eDP
Dual Intel® Gigabit LAN
6x USB3.2, 4x USB2.0, 4x COM, 4x SATA III
1x PCI-E (x16), 2x M.2 (E-key, M-Key)
Watchdog timer, Digital I/O, iAMT (14), TPM (2.0)
The MI999 is an industrial grade Mini-ITX motherboard based on Intel's latest Q470E, H420E, and W480E chipsets. The board is designed to accommodate 10th Gen Intel® Core™ processors (codename Comet Lake-S) in LGA 1200 package with a Thermal Design Power (TDP) of up to 80W. Supporting up to 64GB system RAM and 2666/2933 MHz memory speeds, the new MI999 enables smooth, responsive performance for faster multitasking and productivity to fit the needs of demanding applications such as AIoT industrial automation, intelligent transportation, machine vision, and modern smart factories.
Built to provide high performance and stability to satisfy the requirements in various environments, the IBASE MI999 offers a comprehensive set of I/O for fast data transfers and versatile peripheral connections. These include two Gigabit LAN, six USB 3.2 (Gen1), four USB 2.0, four COM, and four SATA III ports. Expansion and storage are available with one PCIe(x16) and two M.2 slots (E-Key, CNVi and M-Key, NVMe).
Four independent 4K displays can be projected with the Intel® processor integrated graphics via DVI-D, HDMI, DisplayPort and eDP or 24-bit LVDS interface for multi-screen scenarios. The MI999 series is divided into two groups, one with LVDS and the other with eDP support. In addition, the motherboard features iAMT (14) and TPM (2.0) technologies for remote management and computer platform integrity functions. Operating systems supported are Win10 (64-bit), Linux Ubuntu (64-bit) and Windows Server
