Trinocular Co-axial Research Lcd Microscope
Get Price Quote
Observation Head
Trinocular 30˚, 360˚ rotatable, with interpupillary and diopter adjustment.
Magnification
40x to 1000x.
Stand
Sturdy and Durable pressure Die cast Aluminium stand.
Mechanical Stage
Co–axial low drive double plate mechanism system travel on ball bearing guide ways.
Focusing System
Co-axial coarse & fine mechanism system with ball bearing guide ways.
Illumination
The illuminator incorporated 3W LED lamp.
Quadruple Nose Piece
A precision mechanism ensures the accuracy and optical alignment of the system.
TECHNICAL SPECIFICATIONS OF LCD DIGITEL SCREEN
Camera Sensor
5MP color CMOS Camera sensor, size 1/2.5 inch (4:3)
Effective Resolution
2592 H x 1944 V
Video and Frame rate
640x480 @ 30fps , 1280x720@ 15fps
Pixel Size
2.2µm x 2.2µm
Color Depth
12-bit, on-chip
PAD Size
220*170*20mm
Software Function
Image, Video, Measurement
Shutter Type
Electronic Rolling Shutter
SD Card
Support
Power Supply
DC 5V 2A
Optional Output
HDMI
Features:
RADICON - DIGITAL TABLET is the smart digital microscope tablet camera equipped with 5MP color Camera and 9.7 Inches Tablet.
It is developed specifically for microscopy application.
