We are the most reliable manufacturer and supplier of Rotary Surface Grinding Machine. Our grinder has been made by use of high quality graded castings. These castings have been aged properly and are stress relieved by way of vibratory stress relieving equipments. This is done to cater to the seasonal effects on the castings. The rotary surface ensures smooth, vibration free rotary movements for superior job finishes. There is a hand pump that provides lubrication to every part of the machine. Based in Gujarat, India our grinder is equipped with special spindles that are duly assembled with high quality low vibration motors. as well as fitted with very high quality imported bearings which are greased packed for life, providing a very precise grinding action for best surface finishes as well as best flatness for jobs.
Coolant equipment is a standard feature for all the rotary grinders
Made of high quality graded castings, which are properly aged and stress relieved using vibratory stress relieving equipments, for taking care of any seasonal effects on castings. Thus enhancing the life of machines.
The rotary table is precisely mounted parallel with the vertical spindle for maximum removal of material accurately.
This machine tool is available with vertical grinding head and round eletro-magnetic work bench using emery wheel tile end face to grind the planes of work pieces.
The grinding head spindle is equipped with high precision bearings, with big power and excellent rigidity.
The magnetic force of sucking disc is smooth and adjustable and can be demagnetized automatically. By electromagnetic chuck
This machine tool is suitable for the industries such as automobiles and For grinding the planes of lot-sized parts.
The control system of machine is available p.l.c or a.c drive available as per requirement
Standard Accessories and Parts :
200 mm emery wheel
Wheel Flange
Control (p.l.c or a.c drive available as per requirement)
Coolant System
Leveling Screws and micro feeding
Coolant Nozzle
Operation automatic hydraulic
300 mm Electric Magnetic Chuck and control penal
2 h.p spindle electric motor
Hydraulic power pack
50 l.p.m coolant magnetic separator for the filtration system
35 liter coolant pump with 40 ltr coolant tank
½ hydraulic motor with power pack and oil tank capacity 40 ltr
For the centralizing lubricating system , lubricating hand pump
Below for protection of main slide
BenefitsReduces Water Consumption, Environmentally Sustainable, Removes Oil Particles
Care TipsCheck Delivery Time, Quality, Technical Specifications Before Purchase
The parts washer with rotating basket is a machine with special potential to promote cleaning industrial parts of economic and sustainable manner. To make a good purchase, there are some technical aspects that must be considered, that because each model meets certain industrial components.Parts Washer with Rotating Basket - Function and Benefits :The use of parts washer with rotating basket is recurring in the industrial area in various sectors, since it is extremely functional. The parts washer with rotating basket promotes the cleaning of industrial parts through the use of biodegradable detergent, thus, it aids in combating contamination. The way it works allows cleaning to be performed safely since the parts washer with rotating basket has a closed circuit.Considering its use, can be highlighted several benefits in using washer parts with rotating basket, such as reducing water consumption, as the economic use of it, be environmentally sustainable to use for washing only biodegradable detergent parts, successfully removes oil particles and other dirt during powerful washing.Washer with Rotating Basket - Needed Care :When thinking of buying a washer parts with rotating basket, have some care, in particular, review the questions on the form that the chosen company serves its customers. About it, search for the product delivery time, check quality issues and the delivery service availability if a problem occurs with washer parts with rotating basket. Another consideration is the technical characteristics of the parts washer with rotating basket, before investing, inquire pressure and pump power, load capacity, engine power, machine dimensions and basket diameter.Subra You Find in a Wide Variety of Industrial Washing Machines :The Subra, this for over thirty years in business, manufactures and distributes washing machines of different types for different segments industries, including parts washer with rotating basket. Delivering excellent quality products, it provides a good means for payment as the use of the BNDES Card, lease, own financing, Finame.The customer service is done through a specialized team focused to meet the demands of each project, so by contacting the call center, you will be served by friendly and willing attendants to collaborate in the search for their goals.Positioning of the Parts On the Rotary Basket :The parts are loaded onto a basket which is tailored to the parts to be washed. The basket can be loaded with different types of parts and, depending on their characteristics, they can be placed directly on to the basket, onto tools, special supports or into different compartments designed in accordance with their needs.
