Cbro Incorporation Mumbra, Thane, Maharashtra

Medium : gas,liquid,vapor

1. High Accuracy 2. Output : 4-20mA 3. Batching 4. Media : Water, Diesel, Petrol , Air Turbine Flow Meters are useful for liquids & gases in general industrial application for measuring flow rate. Turbine Flowmeter (TFM-70 Series)   CBRO Turbine Flow Meters are useful for liquids & gases in general industrial application. They provide excellent performance with quality & reliability. Suitable for as hygienic application. The flowing media engages a vaned rotor causing it to rotate at an angular velocity proportional to flow rate. The pick -of coil senses the spinning motion of the rotor inside the pipe & converts it into a pulsating electrical signal. Summation of the pulsating electrical signal is directly related to the total flow. The frequency is linearly proportional to flow rate which is converted to mA signal by electronic circuitry. Flow rate Indicator / Totalizer / Transmitter and Controllers are available in Local/Remote and Panel Mounted

Specifications 1.Accuracy:+/-1.0% 2.Pipe range:DN2-DN300 3.Environmental temperature:-30C to 60C 4.Simple and durable construction Turbine Flow Meters are useful for liquids & gases in general industrial application for measuring flow rate. Turbine Flowmeter (TFM-70 Series)   CBRO Turbine Flow Meters are useful for liquids & gases in general industrial application. They provide excellent performance with quality & reliability. Suitable for as hygienic application. The flowing media engages a vaned rotor causing it to rotate at an angular velocity proportional to flow rate. The pick -of coil senses the spinning motion of the rotor inside the pipe & converts it into a pulsating electrical signal. Summation of the pulsating electrical signal is directly related to the total flow. The frequency is linearly proportional to flow rate which is converted to mA signal by electronic circuitry. Flow rate Indicator / Totalizer / Transmitter and Controllers are available in Local/Remote and Panel Mounted

Accuracy : +/-0.5% of Actual Flow Rate (+/- 0.3%, +/-0.2% on request)

Repeatability : +/- 0.2% F.S

Specifications Electromagnetic flow meters 1. High Quality 2. Water Treatment Flow meter 3. Dairy Industry. 4. Sugar Industry. CBRO Make Electromagnetic flowmeter of series DIGIMAG -250 accurately measures the flow rate of conducting liquids or slurries flowing in closed pipes. Due to simple and right design the flowmeter is an obstruction less & maintainence free instrument in place of conventional mechanical flow measuring device. The use of “Pulsed DC” technology offershighest ability & better measuring accuracy in form of 4-20mA DC linearly proportional to volumetric flow.   CONSTRUCTION DETAILS CERTIFICATIN                                       : CE CERTIFIED  METERINGTUBE                                  : S.S 304 ELECTRODE                                        : S.S 316 FLANGE                                              : C.S. LINING                                                 : PTFE END CONNECTION                               : ASA150#Flanged as per B 16.5. MOUNTING                                          : Inline ACCURACY                                          : +/-0.5% of Actual Flow Rate (+/- 0.3%, +/-0.2% on request) REPEATABILITY                                    : +/- 0.2% F.S MIN CONDUCTIVITY                              : 10 uS/cm MAX PROCESS TEMP.                         :0-60 deg C Normally ( Higher Temperature Available) PRESSURERATING                              :10 Bar ( Higher Pressuer Available) MAINSPOWER                                     : 230 V AC 50Hz /  24 V DC ENCLOSURE M.O.C.                           : Cast Aluminum IP65Signal Amplifier Box                                                              Size 220 X 120 X 85 mm with glass window. CABLE ENTRY                                    :PG-9 / PG-11 FLOW UNIT                                         : Selectable. EMPTY PIPEDETECTION                     : Available LOW CUTTOFF                                    : Available OUTPUT                                              : 4 – 20 Ma COMMUNICATION                                : RS 485 MODBUS DIRECTION                                           : Suitable for Bi- Directional PROGRAMMING                                   : Through Key/ Keypad on front facia. TERMINALS                                          : Shock – Hazard – Protected screwless terminals. SIGNAL CONVERTOR                           : Integral / Remote (with 3 meterCable) INTERCHANGE ABILITY                        :Fully interchangeable with all sizes of flow sensors. POWERFAILURE MODE                      :Provision of RAM/PROM to store parameter       entered and measured flow dataduring power failure   Features :  *DIN 10 TO DIN 1200 NB pipe line.   *High Accuracy better than +-0.5% of reading.   *Zero Pressure Drop.   *Suitable for High Viscosity Conductive Liquids.   *Digital Flow rate / Totalizer Indication.   *Isolated Transmitting Output 4-20 mA. *No Grounding Rings require.   *Minimum Upstream & Downstream Stright Length.   *Compact & Rugged, IP 65 protection.   *Remote Flow indication Totalizer / batching systems.       Applications :   1. Effluent Treatement Plants.   2. Sewage Treatement Plants.   3. Water Supply Schemes.   4. Steel & Aluminium.   5. Pulp & Paper.   6. Chemical & Fertilizers.   7. Food & Drug.   8. Pumps & Valve Calibration Lab.   9. Dairy Industry.   10. Corrosive Liquids.  11. Sugar Industry.

Specifications Low Cost Battery Operated Electromagnetic Flow Meter (ISO 9001) 1. Battery powered 2. High Accuracy 3. RS 485 / GPRS System Low Cost Battery Operated Electromagnetic Flow Meter (ISO 9001)   Applications :   1. Effluent Treatement Plants.   2. Sewage Treatement Plants.   3. Water Supply Schemes.   4. Steel & Aluminium.   5. Pulp & Paper.   6. Chemical & Fertilizers.   7. Food & Drug.   8. Pumps & Valve Calibration Lab.   9. Dairy Industry.   10. Corrosive Liquids.  11. Sugar Industry.   Features:    No pressure loss. No moving parts. High accuracy of 0.2%. Wide size range of 10~3000mm, adapt to different size of pipeline. Two-line LCD, able to display positive and negative instantaneous flow and accumulative flow. Measurement is not affected by the density, viscosity, temperature, pressure and electroconductibility of fluid; Multiple choices are available for the liner of converter and the material of electrode; Pulse and 4-20mA standard current output. Multiple choices of communications: RS232, RS485, HART, Modbus, Profibus, etc. Explosion-proof type can be used at relevant explosion-proof sites. IP68 remote type can be used underwater. Variable forms for different kinds of working conditions.Compact and remote form; flanged, flanged wafer, clamped, threaded, insertion end connection; DC/AC, battery power supply.

Accuracy : +/-0.03 m/Sec +/- 1% of velocity

Accuracy : +/-0.5% of Actual Flow Rate (+/- 0.3%, +/-0.2% on request)

Repeatability : +/- 0.2% F.S

Accuracy : +/-0.5% of Actual Flow Rate (+/- 0.3%, +/-0.2% on request)

Repeatability : +/- 0.2% F.S

Accuracy : +/-0.5% of Actual Flow Rate (+/- 0.3%, +/-0.2% on request)

Repeatability : +/- 0.2% F.S

Accuracy : +/-1%

Availability : 3 kg

End Connections : 1-1.5 inch

Output : PULSE (from Sensor ) / 4-20mA / RS 485 Modbus (Optional )

Display : 5 Digit LCD Flow Rate Indicator / 8 Digit Totaliser

CBRO make BTU-250 is a versatile compact energy totalizer extremely useful for measurement of energy convertion. It measures the thermal energy required for air conditioning. It accepts 3 inputs, each one from a flow meter for Chilled water, inlet temperature sensor and outlet temperature sensor. From this it calculates the thermal power and energy consumed in maintaining the temperature at given level. 9 digits are available for total energy and 4 digits Are available for instantaneous power reading. The engg. unit can be easily selectable by user, either as KW & KWH or BTU / HR & BTU   * Compact Wall Mounting Design with IP 65 Enclosure. *16 X 2 LCD Display For Total Energy As Well Instantaneous Power. * Display of Chilled Water Flow, Power Temperature Available. * Choice of Mounting Either on Inlet or Outlet As Per Site Conditions. * Choice of Engineering Units : KW or BU * Data Storage Upto 1 year With Hourly Storage facility With Realtime. * Storage Can Be Viewed By Scrolling Keys. * Serial Interface With Computer Through MODBUS RTU
