Digital Force Gauge Dealers in Thane

The Advanced Force Gauge (AFG) is the most versatile and fully-featured digital force gauge on the market. It can be used hand-held or fixed to a manual or motorised test stand to allow testing under controlled speed conditions. The AFG is fitted with a high-precision “internal” loadcell accurate to ±0.1% of full scale. For added flexibility the AFG is able to recognise data from a range of external ‘Smart’ force and torque sensors, so you can use it as a universal display for remote applications (see pages 5 to 10).   Key Features: Accuracy ±0.1% of full-scale 10 capacities - from 2.5 N to 2500 N Peak capture - Ultimate max + 1st peak Data output - RS232, digital and analogue Pass/Fail Alarms - audible and visual Overload warning with trend bar Wide range of grips and fixtures

Digital force gauge with compact size, high accuracy,easy carry out. Widely applied in electron, high & low voltage electrical appliance, hardware, automobile parts, lighter and ignition system, light industry, mechanical, textile, and so on industries for testing of pull or push load test, insertion force or pull and destructive experiment.       Built-in high sensitivity sensor, fast measurement speed and high precision. Support three different units display: Lb, Kg, N, one-button switching, easy to operate With 3.7V lithium battery, the theoretical working time can reach 15 hours. With a low battery reminder, no operation within 10 minutes can automatically shut down, do not worry about sudden power Large LCD display, reading data is clearer and more convenient The battery has short circuit, leakage, overload protection, and effectively protect the safety of the product 100% satisfactory & We Provide the Quality Assurance.   Model Name/Number SF-500 Accuracy +/-0.5% Humidity 15% to 80%RH Unit N & kg& Lb Power 3.7V lithium Battery Minimum Load 50N / 5kg Maximum Load 500N / 50kg / 110Lb Load Value / Resolution 0.1N / 0.01kg / 0.01Lb Minimum Order Quantity 1 Piece

• Power: AC or rechargeable battery. Multi-step low battery indicator is displayed
• Accuracy: ±0.2% of full scale
• Sampling rate: 3,000 Hz
• Battery Life: Backlight on
• Backlight off: up to 24 hours of continuous use
• Measurement units: lbF, ozF, gF, kgF, N, kN, mN (depending on model)
• Outputs: USB / RS-232
• Mitutoyo (Digimatic): Serial BCD suitable for all Mitutoyo SPC-compatible devices.
• Analog: ±1 VDC, ±0.25% of full scale at capacity,
• General purpose: Three open drain outputs, one input.
• Set points: Three open drain lines.
• Safe overload: 150% of full scale (display shows “OVER” at 110% and above)
•  :

We are offering professional digital force gauges. Series 7 professional digital force gauges are designed with a number of sophisticated features for the most demanding tension and compression measurement applications, up to 500 lbf (2500 n). The gauges feature ±0.1% accuracy and a blazingly fast, industry-leading sampling rate of 14,000 hz, producing reliable results for extremely quick-action tests. series 7 gauges include all the functions of series 5 gauges, with several additional features, including high speed continuous data capture and storage, with memory for up to 5,000 readings, at an acquisition rate of up to 14,000 hz. The gauges also feature programmable footswitch sequencing, break detection, and 1st / 2nd peak detection. Series 7 includes a coefficient of friction unit of measurement and user-defined unit of measurement. For productivity enhancement, the gauges also feature automatic data output, data storage, and zeroing functions upon the completion of break detection, averaging, external trigger, and 1st / 2nd peak detection. series 7 force gauges are directly compatible with mark-10 test stands, including the esm301, to permit functions such as break testing, tensile testing, compression testing, dynamic load holding, pc control capability, and many other applications. the gauges include mesurtm lite data acquisition software. Mesurtm lite tabulates continuous or single point data. One-click export to excel allows for further data manipulation.

Digital Force Gauge, Gloss Meters, Imada Force Gauge, Gloss Meter
