A passive infrared sensor (PIR sensor) is an electronic sensor that measures infrared (IR) light radiating from objects in its field of view. They are most often used in PIR are commonly used in security alarms and automatic lighting applications. PIR sensors are commonly called simply "PIR ", or sometimes "PID ", for "passive infra term passive refers to the fact that PIR devices do not radiate energy for detection purposes. They work entirely by detecting infrared radiation (radiant heat) emitted by or reflected from objects. Applications of Integrated PIR Sensor: All outdoor Lights Lift Lobby Multi Apartment Complexes Common staircases For Basement or Covered Parking Area Shopping Malls
TerminationWIRES – I/P Blue (N), Brown (L), O/P- Red (A)
PCB TypeGlass Epoxy
AC Voltage110-130VAC / 220 – 240VAC
Temperature Test50 °C, 1 MONTH
Casing ShapeRectangular
Maximum Temp. Tc25°C
Ambient Light Setting3 OR 2000 LUX
A passive infrared sensor (PIR sensor) is an electronic sensor that measures infrared (IR) light radiating from objects in its field of view. They are most often used in PIR are commonly used in security alarms and automatic lighting applications.
PIR sensors are commonly called simply "PIR", or sometimes "PID", for "passive infra term passive refers to the fact that PIR devices do not radiate energy for detection purposes. They work entirely by detecting infrared radiation (radiant heat) emitted by or reflected from objects.
Applications of Integrated PIR Sensor:
All outdoor Lights
Lift Lobby
Multi Apartment Complexes
Common staircases
For Basement or Covered Parking Area
Shopping Malls
For garden lights
For Lighting Integration
Features of Integrated PIR Sensor:
Complete with PIR, Motion Detection.
Dual Element Sensor with Low Noise and High Sensitivity.
Delay Time Adjustable.
Standard TTL Output.
