Agitator Dealers

Successful processes involve performance on many levels—from the design process through construction, commissioning and onto process operation—Electromechem is poised to consistently provide high quality products and services. Effective solutions for your mechanical and process specifications are accomplished using a solid range of Promix top, bottom and side entry mixers. Exceptional engineering capabilities also enable us to provide custom solutions for your mixing and mechanical challenges. Rapid response: Industry-leading, sophisticated process and mechanical design software quickly generates solutions complete with quotations, custom assembly/dimension drawings and design loads in paper or electronic formats..     Specifications Flexible configurations to meet your requirements Easy installation Low maintenance Direct or gear drive capability Diffrent Operating Speed flexibility

» Specially designed for heavy duty . » Seals and Bearing can be serviced and maintained with  the agitator remaining in the tank. » Two double spherical roller bearings with adapter sleeve with a theoretical operating life of 24 hours. » Standard type of  v- belt drive which is easily adjustable. » RPM 1440 » 240 RPM out put » Capacity : 150 M 3 /chest These are specially designed agitators in stock preparation machinery line having less maintenance problem.it is designed to agitator stock within the chest of various sizes and configurations. capacity-50 CU.M TO 150 cu.m

GRACE ™ [RANGOLI] is a leader in the field of design, manufacture, testing and supply of various types of Agitators for mixing of liquid-liquid and liquid-solid. GRACE ™ [RANGOLI] has the privilege of supplying critical Agitators to different process industries. We can design, manufacture and supply of Peddle, Propeller, Curved Turbine, Pitched Turbine, Anchor and Cowl types agitators for specialized applications suited to process and operating conditions. Material of Construction can be offered in various grades of thermo plastics such as PP. & HDPE. We also provide carbon Steel agitators with special type of coating and linings including, PP.,PPH., HDPE. & PVDF.

  Principle : The chest agitator consist of CI main body and CI bearing housing mounted to the main body. An EN-8 shaft on bearings inside the CI bearing housing is the drive shaft of the agitator. At the bearing housing end of the shaft flat belt pulley is provided for driving purpose. The other end of the shaft is provided with an SS 410 / CA 40 casted material. A GM bush and gland arrangement is provided on the main body for proper sealing of the shaft against leakage. A S.S. sleeve bush is provided on the shaft portion, which is coming in contact with the pulp as a measure to avoid corrosion. A MS ring is mounted to the main body which in turn can be fixed in the concrete. The agitator is driven by separately mounted electric motor Features : Maintenance Free Low Power Consumption Effective agitation at low power consumption. Bearings are accessible from out-side and can be replaced without draining the chest.

The Industrial Agitators, which we supply, are acclaimed for their sturdy make and long service life. We have parted our infrastructure into several units and one of them is storehouse. We update it on regular basis so as to meet stated industry standards. With the help of smart packaging system and a team of adroit professionals, we are offering customized packaging facility for the attainment of complete client contentment.
