Level Switches Dealers in Mumbai (67 products available)

Side Mounted Magnetic Level Switch Linc Type Principle of Operation This system has a side mounted flange. Float is fabricated out of the material suiting the service or fluid in the vessel When the level rises above the actuation point The float buoys up along with the level rise and actuates the magnetic switch which is kept inside the stem. The closure of the switch can operate a contactor or relay to indicate the level rise or decrease.   Material specification Customized suiting to the service (fluid) and temperature. Available in SS 304/ SS 316/ pp/ pvc/ hdpe/ pvdf/ ptfe etc Material of the flange cs/ ss/ pp /pvc/ hdpe/ pvdf/ ptfeAvailable with flameproof and weatherproof enclosure

Float switches are designed as contactless magnetic switches. They are used to control level in containers tanks with non-flowing and or flowing liquids such as water, oils, caustic solutions etc. Float switches consist of a connection head, an immersion tube with one to four magnetic sensor elements and a float. Versions with straight or elbow immersion tube are available.

Be it refrigerator or any other type of cooling equipment, this Side Mounted Magnetic Level Switch is designed by applying the leading-edge technological concepts. Also, this Side Mounted Magnetic Level Switch finds use in diverse types of humidifiers. We are a credible name to get premium Side Mounted Magnetic Level Switch. Construction : Float mounted at one end of rigid rod moves with change in level, magnetic capsule at other end of rod moves accordingly within fixed limits Switches contacts across the face changes accordingly Advantages : Simple and proven DesignOperates in most liquidMinimum maintenance Trouble-free operationLow cost of ownership Applications : High Low level signals for alarm Annuciation Safety interlock circuits Automatic Pump Control Solenoid Value Control Prevention of tank overflows Pump safeguard against dry running Order Details : Minimum Order Quantity : 50 PiecesPrice Range : Ranging From 1500 INR to 50,000 INR

  We have established ourselves as leading name in the field of Liquid Magnetic Float Level Switch in the market . Switching is achieved with the unique magnet system, giving snap-action latch-on switching. A switch mechanism is mounted inside the enclosure adjacent to the pressure tube. Vertical movement of the float magnet in the pressure tube simultaneously actuates the secondary and tertiary magnets in the switch mechanism to operate the contacts. Features: Snap-action Accurate mechanism Easy to maintain Other Details: Single, Bilevel and multilevel sensing with potential free contacts Float : SS-316/PU Foam/Poly propylene/BUNA-N Mounting : Flange, Threaded in MS / SS or TC joint Terminations: cable / DIN connectors / RTD head / weather proof or flame proof junction box Suitable upto 90 degree Applications: Scientific laboratory Research centres Chemical industries Technical Specifications: Float : S.S.316 or Teflon Coated or PP / PVDF/Monel Flange : Mini 1” NB to Any Size in C.S. or S.S.304 or S.S.316 or S.S. Lined C.S. Etc Reed Switch with Rhodium Contact SPST / SPDT . Rating : 0.5 Amp @ 240 VAC Switch Housing : Die Cast Aluminium, Weather Proof IP 65( Enclosure ) ( IS – 2147 )  Flame Proof to II A, II B ( IS – 2148 CMRSDhanbad Approved ) Operating Pressure : 10 Kg / Cm2Operating Temp : Maxi. 1000 C. Cable Entry : ½” NPT ( F ) OR ¾” ET ( F ) No of Switches : As Per Customer Requirement Stem Length : Up to 5 Meters

Get in touch with us for excellent quality Bilge Level Switches! Our company is bracketed among the trusted Manufacturers, Suppliers and Exporters of Bilge Level Switches from Maharashtra. The self-draining, fully shrouded design of our Bilge Level Switches prevents interference of operation from obstructions or floating debris. Buyers are free to place bulk orders of Level Switches with us and expect their timely delivery.

• Switching Element: Micro switch
• Cable Insulation: Pvc Material
• Life of Switch: 1 Lac Operations
• Rated voltage: 250 VAC
• Pressure Rating: 2 Bar
• Float Material: Polypropylene

• Material: Stainless Steel
• Pole And Throw Specification: SPST
• Body Material: Stainless Steel
• Media Type: Liquid
• Mounting Options: Top Mount, Bottom Mount
• Process Temperature: 120
• DC Voltage: 24 VDC
• Accuracy: 0.5 %

• Mounting Options: Top Mount
• Media Type: Liquid
• Material: SS
• Pole And Throw Specification: SPST
• Brand Name: D B Instruments
• Country of Origin: Made in India
• Item Code: VMT-16-3-TC-AH
• Switching Voltage: 300 VAC / DC
• Switch Rating: 100 VA
• Maximum Working Pressure: 10 kg/cm2

• Material: Nylon
• Frequency (Hertz): 50HZ
• Float Diameter: 0-20mm
• Voltage: 200VDC
• Power: 0-5Amp
• Temperature: 0Dig C To + 60Dig C
• Setting Range: 0-1500pF

Top Mounted Level Switch Flow Point Introduced magnetically float operated Top Mounted Level Switch for controlling one or multi Levels by using reed Switch. The Unit Consists of Vertical Guide Pipe (Stem ), Reed Switches Are located, Magnetic Float Sliding over the Stem according to the level in the tank. After passing the float, the reed relay will retain their output state. Various materials of construction are available depending up on Service Condition. Maximum 4 Set points can be given in a Single Level Switch & Maximum stem length will be 3 Meters.

• Our Model No: CBF-LS
• Cable Range: 3 meters
• Cable material: neoprene
• Cable specification: 9 mm / 3 x 1.5 mm2
• Contact type: NO / C /NC
• Maximum load: 10 A – 250 VAC
• Contact life       : 10 million switches
• Switch angle: + - 45 deg
• Switching speed: max 600 / min
• Process temp: Upto 50’C
• Process pressure: Max – 0.1 mpa
• Liquid density: min – 0.8 g / cm 3
• Housing material: non – toxic polypropylene
• Protection: IP 68

• Mounting Options: Top Mount
• Current Rating: 0.5AMPS
• Media Type: Liquid
• DC Voltage: 24VDC
• Material Body: Plastic
• Size: M10
• Brand: NISHKA
•  :

• Application: Water Levelling
• Voltage: 200VDC
• Frequency: 50HZ
• Power: 0-5Amp
• Hole Diameter: 0-20mm
• Brand Name: Kcass, Aarpee

• Operating Temperature: 10dig C TO 55dig C
• Supply: 110 V or 220 V AC +/-10%; 50 Hz +/-2% or 24 V DC
• Accuracy: +-2 mm
• Delay: 1 Second factory set (optional adjustable)
• Humidity: 1% To 90% (Non Condensing)
• Sensor: Capacitance Type
• Reset: Manual
• Enclosure: Weatherproof or Flameproof IP 65, IIA - IIB OR IIC

.

SIGMA's External cage liquid level switches are very widely used for the petroleum and power industries. Anti vibration design ensures positive switch activation. Being highly versatile, cage mounted type extends to a wide range of other possible applications.A pivoted permanent magnet end is attached to a micro switch. As the float rises following the liquid level, it raises a Magnetic sleeve (isolated inside a non magnetic enclosure (barrier) tube) into the field of the magnet causing attraction and movement across the pivot, actuating the switch. The enclosure tube provides a static seal between the switch mechanism and the float, eliminating the need for a flexing bellows seal, packing gland or other failure prone sealing elements. When the liquid level falls, the float draws the magnetic sleeve below the magnetic field. The magnet swings out and re-actuates the switch to revert to the original position causing low level switch actuation .

The Top Mount Level Switches, which we deliver, are known for their quality and long service life. We have cemented our presence in the market by offering high quality lot that is prepared using the best grade material and modern work methodologies. Also, the material is sourced from the genuine vendors only. Timely delivery of the orders is assured with us as we are backed by one of the most sophisticated transportation facility.

Magnetic Float Operated Level Switches It is a reliable technique in Industry for point liquid level sensing and control in open or pressurized tank. MODEL NO. : FITZER / TLS / 50 Miniature Level Switches  Fitzer small size liquid switches features a small float displacement especially suitable for narrow or restricted area. SERIES : FITZER / LS / 10

This low-cost switch is used for a variety of applications such as control of submersible pumps. This can be used in fresh water , sea water, sewerage and industrial effluents.

We are a reliable name when it comes to manufacturing and exporting excellent quality Conductivity Type Level Switch. The demand for the Conductivity Type Level Switch offered by us is very high in the international market. We have also received appreciation from the clients for the superior quality and affordable cost of our Conductivity Type Level Switch. Features : ResilientEasy to installRust freeResistant to wear and tearEconomical Suitable for : Nonfuming conductive liquids like water, water bound solutionsCorrosive liquids like acids and alkalies with a wide choice of electrode / probe and the controller options In Demand By : Power plantsMunicipal water plantsRefineryPetrochemical plantsChemical plantsWater treatment plants

• Switch Type: Snap Acting 1SPDT/2SPDT Microswitch, 5A, 230VAC /0.5A, 24VDC
• Type: External Chamber Type
• Cable Entry: 1 no / 2 nos. of 3/4"ET(F), 1/2"NPT(F), M20x1.5(F)

Float level switch with application upto 100 bar and 350 deg cent application,Heavy walled floats for critical application, Tight sealing versions for float sensors with switch to enable correct application solutions, with sealing internals at 10(-3-4) mbar ltrsec available, Durability defined on sealing and pressure and temperature application, Improved reliability with dual opposed magnet design which provides snap action, Applicable with various versions of MOC's depending on pressure and temperature, versions with Stainless and steel, hastealloy, monel, PTFE, PP, Titanium available

Model MLS - 04 / MLS -16 magnetic level switches work on the principle of magnetic repulsion and therefore they are glandless and leak proof instruments. A permanent magnet fitted in the tail piece of the float repels another magnet inside the switch housing which in turn operates an SPDT microswitch. Microswitch contacts can be utilized for initiating audio-visual signals or pump control. SALIENT FEATURES : As our switches work on magnetic repulsion principle, they are glandless and leak proof. No power consumption. Internal assembly wirings are teflon insulated. Internal switch assembly bracket is of cast aluminium. Practically no maintenance is required except periodic cleaning. Suitable for 2.5" (65 mm) NB nozzle mounting, (for 63 mm dia float) and 2 " (51 MM) NB nozzle for 48 mm dia float. Maximum working temperature 250°C. (Process Temperature) Contact ratings of MICROSWITCH 5 AMPS at 230 VAC Resistive. Also available with Microswitich having current rating 10 A at 230 VAC Resistive. No of contacts : 1 change over as standard. Optional - 2 change over For high temperature upto 350°C (Process temperature) 1 number SPDT Reed switch with current rating 100 VA, max. switching current 5 Amps, max, switching voltage 230 VAC / 200 VDC Specific Gravity : Down to 0.75 CAUTION : Level Switches should not be used for direct starting / stopping of pumps. An external relay or contractor must always be used with the level switch. MLS-04/MLS-16 side mounted level switches must always be mounted horizontally with outgoing cable entry facing downwards. In case of high temperature Model MLS-04-92 HT/MLS-16-92HT and Low Temperature Models SMT-04-F82 and SMT-04-F92 arc suppressors/current limiting bias resistor must be provided depending on the load viz inductive or lamp load etc. to reduce the deteriorating effect of contacts due to surge voltages and high in-rush current TECHNICAL SPECIFICATION : Model (MLS-04-F82) or (MLS-04-F92S) side mounted magnetic Level Switch.Process connection- 82 or 92mm square flange with 4 bolt holes of 10/14mm dia on 82 or 92mm PCD respectively. Matenal of construction of flange, brackets, fulcrum screws, body and cover-SS 304(For wetted parts in SS 316 please denote by 16 instead of 04 in the Model). SS 316L float. 1 no SPDT microswitch having current rating 5 Amps at 230 VAC resistive. Differential between make and break-10mm approximately.Maximum working pressure 10 kg/sq.cm and temperature 250 deg C.Specific gravity down to 0.7.Cable entry neoprene gromet. Supplied with 1.5 Metre long 3-core PVC Cable. NB : In case of Model MLS-04-F92 flange size shall be 120 mm dia round flange with 4 bolt holes of 14 mm on 92 PCD. .

• Material: Non-toxic Polypropylene
• Brand Name: Radix
• Country of Origin: Made in India
• Cable Material: PVC
• Contact Type: Micro Switch with 1 C/O Contact
• Switch Speed: Max 60/min
• Usage/Application: Drinking/ Sewage Water, Failsafe Indication & Pump Control
• Model Name/Number: CFS201
• Liquid Density: Above 0.8gm/cc
• Pressure Range: 2 kg/cm
• Operating Pressure: 2 kg/cm
• Maximum Load: 10A, 230 VAC (Resistive)
• Contact Life: 10 Million Switches
• Operating Temperature Range: 0 DegreeC to 70 DegreeC
• Switch Angle: +-45 Degree

• Features: Low cost polypropylene level switch, Hermetically moulded, double chamber, Optimum performance

we are offering Level Switches Model TM-BUV Top Mounted Magnetic Level Switch Model SM-BUV Side Mounted Magnetic Level Switch

• Normal sensitivity: 40-45gm
• Membrane material: Neoprene / Silicon
• Max.Working Temperature: -20 deg C to +80 deg C
• Microswitch contacts: 15A, 250v, cos=1
• Max.cable size to be  connected: 2.5mm2
• Cable gland: PG 11/PG 7 (standard)
• Housing: LM6-CAST ALUMINIUM
• Weather protection: IP53
• Weight: 1.2kg (Approx

We are regarded as one of the topmost Mini-Size Level Switch Manufacturers from India. We offer high quality Mini Level Switches that are used in electrical, chemical, food machinery etc., due to its high performance and compact structure. These Mini Float Level Switches are available at the most competitive prices. Model No.: MI-016 Mini Level Switch

The Float level switch offered by Toshbro Controls is suitable for all kinds of liquid and is available in a unique 3 modular design. The 3 modules – switch, flange and float module – can be supplied in countless variants and provides problem solutions for any application.

• Type: Flowline Switch-Tek Vibration Level Switch
• Accuracy Of Depth Range: ± 1 mm in water
• Relay Output: SPST relay rated for 60 VA
• Wetted Material: Glass filled Ryton®, Viton®,
• Max Process Temperature (° C): 80
• Min Process Temperature (° F): -40
• Max Pressure (PSI): 150
• Power (VDC): 12 to 36
