Cutting Machine Dealers in Ahmedabad

Core Cutting and Grinding Machine (AIM 202)   This unit is designed for cutting and grinding cylindrical rock specimens upto NX size. The outfit includes 200 mm dia diamond impregnated cutter, a fine diamond impregnated grinding wheel, a water supply system and sample holder. A V-Vice, to hold the sample upto 55 mm dia x 140 mm long to be cut parallel and square to the longitudinal axis is provided. Cores longer than 140 mm can be prepared by reversing the specimen and holding the same vice. A hand feed arrangement is provided to facilitate the specimen with a uniform and smooth feeding motion.Suitable for operation on 415 V, three phase, AC supply   Application Sample preparation . Industry Civil Infrastructure Dams & Tunnels Geophysical/ Seismology Testing Geotechnical (soil/ rock) Testing Irrigation Mining Real Estate Roads, Highways & Bridges Education Architecture Building Technology Civil Department Geotechnical Science Colleges Traffic & Transportation Railways Roads, Highways & Bridges

Sheet metal cutting comes under the category of metal working. metalworking is craft and practice of working with metals to create individual parts, assemblies, or large scale structures. the term covers a wide range of work from large ships, bridges and oil refineries to delicate jewelry. it therefore includes a correspondingly wide range of skills and the use of many different types of metalworking processes and their related tools. the sheet metal cutting process is a main part of the all industries. normally the sheet metal cutting machine is manually hand operated one for medium and small scale industries. automation in the modern world is inevitable. any automatic machine aimed at the economical use of man, machine, and material worth the most. in our project is solenoid valve and control timing unit is used for automation. the sheet metal cutting machine works with the help of pneumatic double acting cylinder. the piston is connected to the moving cutting tool. it is used to cut the small size of the sheet metal. the machine is portable in size, so easy transportable automation can be achieved through computers, hydraulics, pneumatics, robotics, etc., of these sources, pneumatics form an attractive medium for low cost automation. the main advantages of all pneumatic systems are economy and simplicity. automation plays an important role in mass production.

Working on 440 volts, AC main supply with coolant tank of sufficient capacity. The chop type cut off wheel machine is suitable for quick and clean cutting of metallographic specimen from rods & tubes etc. Abrasive cutter is rugged , sturdy and designed to cut Metallurgical Samples to optimal quality consistently and safely . Cutting Wheel spindle is connected with motor shaft by pulley and belt mechanism. The movement of cutting wheel towards the specimen is applied by handle fixed with motor base pivot spindle and the cutter unit is balanced by springs for smooth chop type movement. Corrosion resistant window. Cooling by two high flow water jets to provide optimum cooling. Large (25mm) drain, re-circulation coolant tank with 30ltr. Capacity
