Forged Steel Globe Valve Dealers in Ahmedabad (25 products available)

Size : 1/4″ To 2″ INCH

Material : Forged Steel

Application : Water Fitting

Feature : Blow-Out-Proof, Casting Approved

Pressure : High, Low, Medium

Structure : Double Half Shaft

Port Size : 0.1mm-5cm

Technics : Gear Operated

Number Of Way : 2way, 3way, 4way

Brand Name : Allines

Feature : High strength and durability

Type : Globe Valve

Place of Origin : Ahmedabad

Condition : New, Good

Packaging : Bulk

Our Forged Steel Globe Valve is demanded owing to its high strength and durability. Our Forged Steel Globe Valve has taper plug type disc and renewable seat rings with perfect matching type of mating parts to assure leak tightness (horizontal type). We can also provide Regulating Plug or Needle Type Plug on special request. We are dedicatedly engaged in manufacturing, exporting and supplying premium grade Forged Steel Globe Valve.

We are offering forged steel globe valve, jupiter controls valves forged steel globe valves are bolted bonnet, outside screw and yoke type, rising spindle construction. Jupiter controls forged valves body and bonnet made from high quality forgings. Jupiter controls offer forged steel globe valves in size 12” (dn15) to 2” (dn50) to suit various critical, non-critical applications and pressure rating in 800 class. Jupiter controls forged steel globe valve manufacturing range covers regular port and standard port both types of valve. Regular port globe valves have fast delivery or ready stock, for standard port globe valve do manufactuing on order basis. Jupiter controls offer forged steel globe valve in wide range of body materials like astm a 105 - forged carbon steel, astm a 182 f 304304l316316l - forgated stainless steel 304304l316316l, astm a 182 f 1122 - alloy steel to suit industrial application. Jupiter controls forged steel globe valves are available under any third party inspection also. For high pressure & temperature application stellited f6 face seat & disc available. Forged globe valve available is threaded end, socket weld end, butt weld end and flanged end connection. For flanged end forged steel globe valve flanges will be a welded with a valve body not integral forged manufacturer & exporter of wide range of industrial forged steel globe valves rising stem forged steel globe valve (regular port) rising hand wheel, bolted bonnet forged globe valve (regular port)

Brand Name : MVA

Manufacturing Std. : BS 5352

Testing & Inspection Std. : API 598

Socket Weld and Threaded To : ANSI B 16.11 / ANSI B 1.20.1

Flanged To : ANSI B 16.5

Flange to Flange Distance : ANSI B 16.10

Suitable For : Steam, Oil

Body Test Pressure : 3000 PSIG

Seat Test Pressure : 2000 PSIG

Air Test of Seat : AR 100 PSIG

Size : 1.1/2inch, 1.1/4inch, 1/2inch

Certification : ISI Certified, ISO 9001:2008 Certified

Feature : Casting Approved, Durable, Investment Casting

Port Size : 0.1mm-5cm, 6cm-20cm

Technics : Gear Operated, Hard Sealing

Country of Origin : India

As we have an efficient supply chain network, our company is able to fulfill bulk orders with ease and make deliveries on time. Our packing system is systematized in such a manner that we can handle even bulk packaging with ease. Moreover, our packing experts take care of the customized as well as standard packing demands of the clients.

Material : Forged Steel

Certification : API 602 I BS-5352

Type : “Y” Type Pattern

Material Grade : ASTM A 105 I F304 I F304L I F316 I F316L I F5 I F9 I F11 I F22

End Connections : Socket Weld I Screwed I Butt Weld I Flanged Ends I

Pressure Rating : Pressure Rating : ASA 800# I 1500# I 2500#

Size Range : 15mm to 50mm

Drop Forged Steel Globe Valve, Reduced Bore, Bolted Bonnet, Outside Screw & Yoke Type, Rising Stem, Backseat Arrangement, Stainless Steel Trim, Handwheel Operated.

Nivz Valves Forged Steel Globe Valves are Bolted Bonnet, outside screw and yoke type, Rising Spindle construction. Nivz Forged Valves Body and bonnet made from high quality forgings. Nivz Valves & Automation manufacturer and exporter Forged Steel Globe Valves in size 1/2” (DN15) to 2” (DN50) to suit various critical, non-critical applications and pressure rating in 800 and 1500 class. Nivz make Forged Steel Globe Valve manufacturing range covers Regular Port and Standard Port both types of Valve. Regular Port globe valves have fast delivery or ready stock, for Standard Port globe valve do manufactuing on order basis. Nivz manufacture Forged Steel Globe Valve in wide range of Body Materials like ASTM A 105 - Forged Carbon Steel, ASTM A 182 F 304/304L/316/316L - Forged Stainless Steel 304/304L/316/316L, ASTM A 182 F 11/22 - Alloy Steel to suit high temperature and pressure industrial application. Forged Steel Globe Valves are available under any Third party inspection also. For High Pressure & Temperature application Stellited F6 Face Seat & Disc available. Forged Globe Valve available in Threaded End (BSP / NPT Female), Socket Weld End, Butt Weld End, Weld Neck End and Flanged End Connection. For flanged end connection Forged Steel Globe Valve flanges will be a fabricated / welded with a valve body, flanges are not integral forged with body. A complete range of Forged Steel Globe Valve Manufacturer, A 105, F11, F22, F304L, F316L Material Forged Valve Exporter, Stockist, Supplier, Importer. Application Generaly fine controlling of flow Power Plants & Process Industries Petrochemical Plants & Refineries Fertilizers Plants Process & General Industries Sugar Industries & Distillery Plants Water, Steam, Gas, Oil & other Non-aggressive media Other application on request Salient Features of Globe Valve Body & Bonnet made from high quality forging. The Forgings are precision machined for high performance Leak Proof Body-Bonnet Joint With Spiral Wound Gasket Ground Finish Stem Self Aligning Two Piece Gland Back seating feature facilitates repacking of the stuffing box on line with the valve in fully open position.

AMTECH forged steel Globe Valves are made from Forged -A 105,Forged A 015N , F-11,F-22,F-304,F-316,F-304L and F-316L etc. We have 800#,1500# and 2500# rating valves. We manufacturers above 1500# rating valves sealweld design consider safety factor.   Specification

  Technical Data: Manufacturing Std : BS 5352 Face to Face, End to End : D N Bros. Std. End Connection : Screwed Ends to BSP/BSPT/NPT   : Socket Weld Ends to ANSI B16.11 Inspection and Testing Std : BS 6755 (Part-1)

Forged steel globe valve, All Globe Valve stem is made from solid one piece construction. The yoke bush of Globe Valve has a long thread engagement for accurate stem alignment.Body & Bonnet made from high quality forging. The Forgings are precision machined for high performance, Leak Proof Body-Bonnet Joint With Spiral Wound Gasket, Die moulded Graphite (Grafoil) Packing Rings, controlled clearance between stem, gland and bonnet bushing for guaranteed low emissions and also suitable for higher temperature.

Manufacturing Std: : BS 5352

Face to Face, End to End: : D N Bros. Std.

End Connection: : Screwed Ends to BSP/BSPT/NPT Socket Weld Ends to ANSI B16.11

Inspection and Testing Std: : BS 6755 (Part-1)

DESIGN & TESTING INTERNATIONAL STANDARD: Valve Design                           : BS 5352 Pressure Testing                     : BS 5146 Face To Face                         : ANSI B 16.10 Butt Weld End                         : ANSI B 16.25 Socket Weld End                    : ANSI B 16.11 Screwed End                         : ANSI B 1.20.1(BSP/NPT)   SALIENT FEATURES: Body & Bonnet made from high quality forging. The Forgings are precision machined for high performance Leak Proof Body-Bonnet Joint With Spiral Wound Gasket Rising Stem & Rising Hand Wheel Construction. Ground Finish Stem Self Aligning Two Piece Gland Die moulded Graphite (Grafoil) Packing Rings, controlled clearance between stem, gland and bonnet bushing for guaranteed low emissions and also suitable for higher temperature. Precision Stem Packing Chamber Deep stuffing box is providing for tightness and maximum long packing life. Swinging Eye Bolts facilitate easy access to the stuffing box. Back seating feature facilitates repacking of the stuffing box on line with the valve in fully open position. Stellited Disc, Seat Ring & Back Seat can also be offered on special request.

Forged steel globe valve fully welded bonnet. Spiral gasket is provided for the sealing of the bonnets. Along with all kinds of customized specifications,

Forged steel globe valve Memory Seal Seats Compensate automatically for wear and fluctuations of pressure and temperature. Solid cup and cone type PTFE Stem Seal- Adjustable. Stem bearing in Gland nut reduces Side thrust effect.

Material : Forged Steel

Size : 15 Mm To 100 Mm

Brand Name : MASQ

End Connection : Flanged

Temperature : Up to 350 Degree C

Forged Steel Globe Valve, Gate Valves, Globe Valves, Check Valves

Forged Steel Globe Valve, Swing Check Valves, Gate Valves, Butterfly Valves

Forged Steel Globe Valve, Swing Check Valves, Din Globe Valve

Forge Steel Globe Valve, Y Strainer, two way ball valves
