Halogen Free Cable Dealers in Alwar

H(St)H 300/500V   Cable Structure• Class 5 bare copper conductor as per IEC 60228 and IS 8130• ZHLS Insulation• Cores twisted• Polyester tape binded• Almylar and ATC drain wire shielded• ZHLS outer sheath, grey   Standard References BS EN 50525-3-11 BS EN 50288-7 Special Features Low bend diameter Flexible Space saving construction Excellent fire retardance Low halogen content Excellent electrical properties Good oil resistance Low smoke and toxicity Good EMI protection Application Range Industrial machinery and air conditioning systems For general purpose installations in dry environment subjected to low mechanical loads Areas where human or animals are present Tunnels and transportation Suitable for outdoor installations For installation near electro-magnetic noise – near power cables, medium power consuming machinery and appliances Measurement and control Data processing and signaling Technical Data Temperature Range  -15°C to +70°C Nominal Voltage  300/500V Test Voltage  1500V Insulation Resistance  Min. 200Mohm-km Min. Bending Radius  8 x cable dia Short Circuit Temperature  Upto 160°C Flame Retardance  As per IEC 60332-1

Cable Structure• Class 5 bare copper conductor as per IEC 60228 and IS 8130• ZHLS Insulation• Cores twisted• ZHLS outer sheath, grey   Standard References BS EN 50525-3-11 BS EN 50288-7 Special Features Low bend diameter Highly flexible Space saving construction Execllent fire retardance Low halogen content Excellent electrical properties Good oil resistance Low smoke and toxicity Application Range Industrial machinery and air conditioning systems For general purpose installations in dry environment subjected to low mechanical loads Areas where human or animals are present Tunnels and transportation Suitable for outdoor installations Technical Data Temperature Range  -15°C to +70°C Nominal Voltage  300/500V Test Voltage  1500V Insulation Resistance  Min. 200Mohm-km Min. Bending Radius  8 x cable dia Short Circuit Temperature  Upto 160°C Flame Retardance  As per IEC 60332-1
